SEC-16
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
DATA MONITOR
ACTIVE TEST
THEFT ALM
THEFT ALM : CONSULT-III Function (BCM - THEFT ALM)INFOID:0000000001404048
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
DATA MONITOR
ACTIVE TEST
WORK SUPPORT
Diagnosis mode Function Description
DATA MONITOR The BCM input/output signals are displayed.
ACTIVE TEST The signals used to activate each device are forcibly supplied from Intelligent Key unit.
Monitor item Content
IGN ON SW Indicates [ON/OFF] condition of ignition switch in ON position.
KEY ON SW Indicates [ON/OFF] condition of key switch.
PUSH SW Indicates [ON/OFF] condition of ignition knob switch.
Test item Description
THEFT IND This test is able to check security indicator operation [ON/OFF].
Diagnosis mode Function Description
WORK SUPPORT Changes the setting for each system function.
DATA MONITOR The BCM input/output signals are displayed.
ACTIVE TEST The signals used to activate each device are forcibly supplied from BCM.
Monitor Item Condition
IGN ON SW Indicates [ON/OFF] condition of ignition switch in ON position.
ACC ON SW Indicates [ON/OFF] condition of ignition switch in ACC position.
PUSH SW Indicates [ON/OFF] condition of ignition knob switch.
KEY ON SW Indicates [ON/OFF] condition of key switch.
I-KEY LOCK Indicates [ON/OFF] condition of lock signal from Intelligent Key.
I-KEY UNLOCK Indicates [ON/OFF] condition of unlock signal from Intelligent Key.
DOOR SW-DR Indicates [ON/OFF] condition of front door switch (driver side).
DOOR SW-AS Indicates [ON/OFF] condition of front door switch (passenger side).
DOOR SW-RR Indicates [ON/OFF] condition of rear door switch RH.
DOOR SW-RL Indicates [ON/OFF] condition of rear door switch LH.
BACK DOOR SW Indicates [ON/OFF] condition of back door switch.
CDL LOCK SW Indicates [ON/OFF] condition of door lock and unlock switch.
CDL UNLOCK SW Indicates [ON/OFF] condition of door lock and unlock switch.
Test item Description
THEFT IND This test is able to check security indicator operation [ON/OFF].
FLASHER This test is able to check flasher operation [LH/RH/OFF].
Page 4642 of 5883
DIAGNOSIS SYSTEM (BCM)
SEC-17
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
Test item Description
SECURITY ALARM SETVehicle security function mode can be changed in this mode.
ON: Vehicle security function is ON.
OFF: Vehicle security function is OFF.
THEFT ALM TRGThe switch which triggered vehicle security system is recorded. This mode can be able to con-
firm and erase the record of vehicle security system.
Page 4643 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SEC-18
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (INTELLIGENT KEY UNIT)
DIAGNOSIS SYSTEM (INTELLIGENT KEY UNIT)
CONSULT-III Function (INTELLIGENT KEY)INFOID:0000000001404049 NISSAN TIIDA 2007 Service Repair Manual SEC-18
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (INTELLIGENT KEY UNIT)
DIAGNOSIS SYSTEM (INTELLIGENT KEY UNIT)
CONSULT-III Function (INTELLIGENT KEY)INFOID:0000000001404049](/manual-img/5/57395/w960_57395-4642.png)
SEC-18
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (INTELLIGENT KEY UNIT)
DIAGNOSIS SYSTEM (INTELLIGENT KEY UNIT)
CONSULT-III Function (INTELLIGENT KEY)INFOID:0000000001404049
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with Intelligent Key unit.
WORK SUPPORT
SELF-DIAG RESULT
Refer to SEC-71, "DTCIndex".
DATA MONITOR
Diagnosis mode Function Description
WORK SUPPORT Changes the setting for each system function.
SELF-DIAG RESULTS Displays the diagnosis results judged by Intelligent Key unit.
CAN DIAG SUPPORT MNTR Monitors the reception status of CAN communication viewed from Intelligent Key unit.
DATA MONITOR The Intelligent Key unit input/output signals are displayed.
ACTIVE TEST The signals used to activate each device are forcibly supplied from Intelligent Key unit.
ECU IDENTIFICATION The Intelligent Key unit part number is displayed.
Support item Description Selection item Condition
CONFIRM KEY FOB IDIt can check whether Intelligent Key ID code
is registered or not.——
TAKE OUT FROM WINDOW WARNTake away warning chime (from window)
mode can be changed.ON Active
OFF Inactive
LOW BATT OF KEY FOB WARNIntelligent Key low battery warning mode can
be changed.ON Active
OFF Inactive
KEYLESS FUNCTIONDoor lock function with Intelligent Key can be
changed.ON Active
OFF Inactive
ANSWER BACK FUNCTION Buzzer reminder operation can be changed.ON Active
OFF Inactive
SELECTIVE UNLOCK FUNCTION Anti-hijack mode can be changed.ON Active
OFF Inactive
HAZARD ANSWER BACKHazard reminder operation mode can be
changed.Refer to XX-XX, "*****"
.
ANSWER BACK WITH I-KEY LOCKBuzzer reminder operation (lock operation)
mode by each door request switch can be
changed. BUZZER Active
OFF Inactive
ANSWER BACK WITH I-KEY UNLOCKBuzzer reminder operation (unlock operation)
mode by each door request switch can be
changed.BUZZER Active
OFF Inactive
AUTO RELOCK TIMERAuto door lock operation mode can be
changed.OFF Inactive
2 min Active
ENGINE START BY I-KEYEngine start function (by Intelligent Key)
mode can be changed. ON Active
OFF Inactive
LOCK/UNLOCK BY I-KEYDoor lock function by door request switch can
be changed. ON Active
OFF Inactive
Page 4644 of 5883
![NISSAN TIIDA 2007 Service Repair Manual DIAGNOSIS SYSTEM (INTELLIGENT KEY UNIT)
SEC-19
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
ACTIVE TEST
Monitor Item Condition
PUSH SW Indicates [ON (pressed)/O NISSAN TIIDA 2007 Service Repair Manual DIAGNOSIS SYSTEM (INTELLIGENT KEY UNIT)
SEC-19
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
ACTIVE TEST
Monitor Item Condition
PUSH SW Indicates [ON (pressed)/O](/manual-img/5/57395/w960_57395-4643.png)
DIAGNOSIS SYSTEM (INTELLIGENT KEY UNIT)
SEC-19
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
ACTIVE TEST
Monitor Item Condition
PUSH SW Indicates [ON (pressed)/OFF (released)] condition of ignition knob switch.
KEY SW Indicates [ON (inserted)/OFF (removed)] condition of key switch.
DR REQ SW Indicates [ON (pressed)/OFF (released)] condition of door request switch (driver side).
AS REQ SWIndicates [ON (pressed)/OFF (released)] condition of door request switch (passenger
side).
BD/TR REQ SW Indicates [ON (pressed)/OFF (released)] condition of door request switch (back door).
IGN SWIndicates [ON (ON or START position)/OFF (other than ON and START position)] con-
dition of ignition switch ON position.
ACC SW Indicates [ON/OFF] condition of ignition switch ACC position.
STOP LAMP SW Indicates [ON/OFF] condition of stop lamp switch.
DOOR LOCK SIG Indicates [ON/OFF] condition of LOCK signal from Intelligent Key.
DOOR UNLOCK SIG Indicates [ON/OFF] condition of UNLOCK signal from Intelligent Key.
DOOR SW DRIndicates [OPEN/CLOSE] condition of front door switch (driver side) from BCM via CAN
communication.
DOOR SW ASIndicates [OPEN/CLOSE] condition of front door switch (passenger side) from BCM via
CAN communication.
DOOR SW RRIndicates [OPEN/CLOSE] condition of rear door switch (RH) from BCM via CAN com-
munication.
DOOR SW RLIndicates [OPEN/CLOSE] condition of rear door switch (LH) from BCM via CAN com-
munication.
DOOR BK SWIndicates [OPEN/CLOSE] condition of back door switch from BCM via CAN communi-
cation.
VEHICLE SPEEDDisplays the vehicle speed signal received from combination meter by numerical value
[km/h].
Test item Description
DOOR LOCK/UNLOCKThis test is able to check door lock/unlock operation.
ALL UNLK: All door lock actuators are unlocked.
DR UNLK: Door lock actuator (driver side) is unlocked.
AS UNLK: Door lock actuator (passenger side) is unlocked.
BK UNLK: This item is indicated, but inactive.
LOCK: All door lock actuator is locked.
ANTENNAThis test is able to check Intelligent Key antenna operation.
When the following condition are met, hazard warning lamps flash.
ROOM ANT1: Inside key antenna (console) detects Intelligent Key, when “ROOM
ANT1” is selected.
ROOM ANT2: Inside key antenna (instrument center/rear seat) detects Intelligent
Key, when “ROOM ANT2”is selected.
DRIVER ANT: Outside key antenna (driver side) detects Intelligent Key, when “DRIV-
ER ANT” is selected.
ASSIST ANT: Outside key antenna (passenger side) detects Intelligent Key, when
“ASSIST ANT” is selected.
BK DOOR ANT: Outside key antenna (rear bumper) detects Intelligent Key, when “BK
DOOR ANT” is selected.
OUTSIDE BUZZERThis test is able to check Intelligent Key warning buzzer operation.
ON
OFF
INSIDE BUZZERThis test is able to check warning chime in combination meter operation.
TAKE OUT: Take away warning chime sounds.
KNOB: Ignition knob switch warning chime sounds.
KEY: Key warning chime sounds.
OFF
Page 4645 of 5883
SEC-20
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (INTELLIGENT KEY UNIT)
*1: The item is only for M/T model.INDICATORThis test is able to check warning lamp operation.
BLUE ON: Key warning lamp (green) illuminates.
RED ON: Key warning lamp (red) illuminates.
KNOB ON: Lock warning lamp illuminates.
BLUE IND: Key warning lamp (green) flashes.
RED IND: Key warning lamp (red) flashes.
KNOB IND: Lock warning lamp flashes.
OFF
KEY LOCK SOLENOID
*1This test is able to check key interlock operation.
LOCK: Key interlock is active.
UNLOCK: Key interlock is inactive. Test item Description
Page 4646 of 5883
![NISSAN TIIDA 2007 Service Repair Manual U1000 CAN COMM CIRCUIT
SEC-21
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
COMPONENT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000001404050
CAN (C NISSAN TIIDA 2007 Service Repair Manual U1000 CAN COMM CIRCUIT
SEC-21
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
COMPONENT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000001404050
CAN (C](/manual-img/5/57395/w960_57395-4645.png)
U1000 CAN COMM CIRCUIT
SEC-21
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
COMPONENT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000001404050
CAN (Controller Area Network) is a serial communication line for real time applications. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Modern
vehicle is equipped with many electronic control unit, and each control unit shares information and links with
other control units during operation (not independent). In CAN communication, control units are connected
with 2 communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less
wiring. Each control unit transmits/receives data but selectively reads required data only.
CAN Communication Signal Chart, refer to XX-XX, "*****"
.
DTC LogicINFOID:0000000001404051
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000001404052
1.PERFORM SELF DIAGNOSTIC
1. Turn ignition switch ON and wait for 2 seconds or more.
2. Check “Self Diagnostic Result”.
Is
“CAN COMM CIRCUIT” displayed?
YES >> Refer to XX-XX, "*****".
NO >> Refer to XX-XX, "*****"
.
DTCCONSULT-III display
descriptionDTC Detection Condition Possible cause
U1000 CAN COMM CIRCUITWhen Intelligent Key unit cannot communi-
cate CAN communication signal continuous-
ly for 2 seconds or more.In CAN communication system, any item (or items)
of the following listed below is malfunctioning.
Transmission
Receiving (BCM)
Receiving (ECM)
Receiving (METER/M&A)
Page 4647 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SEC-22
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
U1010 CONTROL UNIT (CAN)
U1010 CONTROL UNIT (CAN)
DescriptionINFOID:0000000001404053
CAN (Controller Area Network) is a serial communication NISSAN TIIDA 2007 Service Repair Manual SEC-22
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
U1010 CONTROL UNIT (CAN)
U1010 CONTROL UNIT (CAN)
DescriptionINFOID:0000000001404053
CAN (Controller Area Network) is a serial communication](/manual-img/5/57395/w960_57395-4646.png)
SEC-22
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
U1010 CONTROL UNIT (CAN)
U1010 CONTROL UNIT (CAN)
DescriptionINFOID:0000000001404053
CAN (Controller Area Network) is a serial communication line for real time applications. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Modern
vehicle is equipped with many electronic control unit, and each control unit shares information and links with
other control units during operation (not independent). In CAN communication, control units are connected
with 2 communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less
wiring. Each control unit transmits/receives data but selectively reads required data only.
CAN Communication Signal Chart, refer to XX-XX, "*****"
.
DTC LogicINFOID:0000000001404054
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000001404055
1.REPLACE INTELLIGENT KEY UNIT
When DTC [U1010] is detected, replace Intelligent Key unit.
>> Replace Intelligent Key unit.
Special Repair RequirementINFOID:0000000001404056
1.REQUIRED WORK WHEN REPLACING INTELLIGENT KEY UNIT
Initialize control unit. Refer to CONSULT-III Operation Manual.
>> Work end.
DTCCONSULT-III display de-
scriptionDTC Detection Condition Possible cause
U1010 CONTROL UNIT (CAN)When detecting error during the initial diagnosis of CAN control-
ler of Intelligent Key unit.Intelligent Key unit
Page 4648 of 5883
![NISSAN TIIDA 2007 Service Repair Manual B2013 ID DISCORD I-KEY-STRG
SEC-23
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2013 ID DISCORD I-KEY-STRG
DescriptionINFOID:0000000001404057
Intelligent Key NISSAN TIIDA 2007 Service Repair Manual B2013 ID DISCORD I-KEY-STRG
SEC-23
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2013 ID DISCORD I-KEY-STRG
DescriptionINFOID:0000000001404057
Intelligent Key](/manual-img/5/57395/w960_57395-4647.png)
B2013 ID DISCORD I-KEY-STRG
SEC-23
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2013 ID DISCORD I-KEY-STRG
DescriptionINFOID:0000000001404057
Intelligent Key unit performs the ID verification with the steering lock unit and releases the steering lock if both
Intelligent Key unit and steering lock unit ID are same. Intelligent Key unit starts the communication with the
steering lock unit when Intelligent Key is carried into the vehicle and the ignition knob switch is pressed.
DTC LogicINFOID:0000000001404058
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Press the ignition knob switch
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Refer to XX-XX, "*****".
NO >> INSPECTION END.
Diagnosis ProcedureINFOID:0000000001532028
1.CHECK STEERING LOCK SOLENOID POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect steering lock solenoid connector.
3. Check voltage between steering lock solenoid and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace steering lock solenoid power supply
circuit.
2.CHECK STEERING LOCK SOLENOID GROUND CIRCUIT
Check continuity between steering lock solenoid and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 6.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2013 STRG COMM 1The ID verification results between Intelligent Key
unit and steering control unit are NG. The registra-
tion is necessary.Steering lock unit
Te r m i n a l s
Voltage (V)
(Approx.) (+)
(–)
Steering lock sole-
noidTe r m i n a l
M6 1 Ground Battery voltage
PIIB6632E
Steering lock solenoid connector Terminal
GroundContinuity
M6 4 Yes
PIIB6633E
