2007 NISSAN TIIDA Service Repair Manual

brake pads replacement ABS fuse box apple carplay hood open warning

Load previous 8 pages

Page 4401 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI-94
< ON-VEHICLE REPAIR >
COMBINATION METER
ON-VEHICLE REPAIR
COMBINATION METER
Removal and InstallationINFOID:0000000001569484
COMBINATION METER
Removal
NOTE:
LH drive shown RH drive similar.
1. P

Page 4402 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI
COMBINATION METER
MWI-95
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
L
MB A
O
P
9. Insert suitable tool into the bottom gap of side ventilator assem-
bly after removing the instrument side mask, push

Page 4403 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI-96
< ON-VEHICLE REPAIR >
COMBINATION METER
17. Remove screws (A) and metal clip (B), and remove combination
meter.
Installation
Installation is in the reverse order of removal.
PKIC0703E

Page 4404 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI
COMBINATION METER
MWI-97
< DISASSEMBLY AND ASSEMBLY >
C
D
E
F
G
H
I
J
K
L
MB A
O
P
DISASSEMBLY AND ASSEMBLY
COMBINATION METER
Disassembly and AssemblyINFOID:0000000001716785
COMBINATION METER
Disa

Page 4405 of 5883

NISSAN TIIDA 2007 Service Repair Manual PB-1
BRAKES
C
D
E
G
H
I
J
K
L
M
SECTION PB
A
B
PB
N
O
P
CONTENTS
PARKING BRAKE SYSTEM
PRECAUTION ...............................................2
PRECAUTIONS ..........................................

Page 4406 of 5883

NISSAN TIIDA 2007 Service Repair Manual PB-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000001716772
The Supplemental Restraint Sy

Page 4407 of 5883

NISSAN TIIDA 2007 Service Repair Manual PREPARATION
PB-3
< PREPARATION >
C
D
E
G
H
I
J
K
L
MA
B
PB
N
O
P
PREPARATION
PREPARATION
Commercial Service ToolINFOID:0000000001716773
Tool nameDescription
Power toolRemoving nuts, bolts and screws
P

Page 4408 of 5883

NISSAN TIIDA 2007 Service Repair Manual PB-4
< ON-VEHICLE MAINTENANCE >
PARKING BRAKE CONTROL
ON-VEHICLE MAINTENANCE
PARKING BRAKE CONTROL
On-Vehicle ServiceINFOID:0000000001716774
INSPECTION
When parking brake lever is operated with a forc

PB-4
< ON-VEHICLE MAINTENANCE >
PARKING BRAKE CONTROL
ON-VEHICLE MAINTENANCE
PARKING BRAKE CONTROL
On-Vehicle ServiceINFOID:0000000001716774
INSPECTION
When parking brake lever is operated with a force of 196 N (20 kg-f,
44 lb-f), make sure parking brake lever stroke is within the specified
number of notches. (Check it by listening and counting ratchet
clicks.)
COMPONENTS INSPECTION
Make sure that the mounting conditions (looseness, backlash, etc.) of each component are normal.
Check the following:
- Device assembly for bends, damage and cracks. Replace if any damage is noted.
- Cables and equalizer for wear and damage. Replace if any damage is noted.
- Parking brake switch. Replace if it does not work correctly.
ADJUSTMENT
1. Remove console mask cover. Refer to IP-11, "Removal and Installation".
2. Engage parking brake lever, then lift up the end of the trim on
the lever to access the adjusting nut.
3. Insert a deep socket wrench onto adjusting nut. Rotate adjusting
nut to fully loosen cable, and then release parking brake lever.
4. Depress the foot brake about 10 times and adjust the rear shoe clearance.
CAUTION:
Be sure to securely depress the foot brake.
5. Rotate brake drum to make sure that there is no drag.
6. Adjust parking brake cable with the following procedure.
a. When replace parking brake cable, operate parking brake lever with a force of 490 N (50 kg-f, 110 lb-f)
about 10 times.
b. Engage parking brake lever, then lift up the end of the trim on the lever to access the adjusting nut.
c. Rotate adjusting nut to adjust parking brake lever stroke using a deep socket wrench.
d. Operate parking brake lever with a force of 196 N (20 kg-f, 44 lb-f), make sure the parking brake lever
stroke is within the specified number of notches. (Check it by listening and counting ratchet clicks.)
e. Make sure that there is no drag on rear brake with parking brake lever completely released.
7. Install console mask. Refer to IP-11, "
Removal and Installation". Number of notches : 8 - 9
WFIA0508E
SFIA2453E
