NISSAN TIIDA 2007 Service Repair Manual EC-436 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] COOLING FAN CONTROL 1. Mass air flow sensor (with intake air temperature sensor)2. Engine coolant temperature sensor 3. Electric throttle contr

Page 1786 of 5883

NISSAN TIIDA 2007 Service Repair Manual COOLING FAN CONTROL EC-437 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC N P O 1. ECM harness connectors 2. ECM 3. IPDM E/R 4. Fuel pump fuse (15A) 5. Intake valve timing

Page 1787 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-438 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] COOLING FAN CONTROL 1. Exhaust manifold 2. Heated oxygen sensor 1 3. Heated oxygen sensor 2 4. Heated oxygen sensor 2 harness connector Vehicl

Page 1788 of 5883

NISSAN TIIDA 2007 Service Repair Manual COOLING FAN CONTROL EC-439 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC N P O 1. Cooling fan motor harness connec- tor2. Crankshaft position sensor 3. Stop lamp switch 4

Page 1789 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-440 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] COOLING FAN CONTROL Component Description INFOID:0000000001693483 1. ASCD steering switch 2. MAIN switch 3. CANCEL switch 4. SET/COAST switch 5

Page 1790 of 5883

NISSAN TIIDA 2007 Service Repair Manual EVAPORATIVE EMISSION SYSTEM EC-441 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC N P O EVAPORATIVE EMISSION SYSTEM System DiagramINFOID:0000000001693484 EVAPORATIVE EMISS

Page 1791 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-442 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] EVAPORATIVE EMISSION SYSTEM 1. Intake manifold collector 2. EVAP canister purge volume con- trol solenoid valve3. EVAP purge resonator :Vehicle

Page 1792 of 5883

NISSAN TIIDA 2007 Service Repair Manual EVAPORATIVE EMISSION SYSTEM EC-443 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC N P O NOTE: Do not use soapy water or any type of solvent while installing vacuum hose or
