Page 1561 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-212
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P0444 EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
6. Touch “Qd” and “Qu” on CONSULT-III screen to adjust “PURG
VOL CONT/V” open

Page 1562 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0500 VSS
EC-213
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P0500 VSS
DescriptionINFOID:0000000001670975
The vehicle speed signal is sent to the combination meter

P0500 VSS
EC-213
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P0500 VSS
DescriptionINFOID:0000000001670975
The vehicle speed signal is sent to the combination meter from the “ABS actuator and electric unit (control
unit)” by CAN communication line. The combination meter then sends a signal to the ECM by CAN communi-
cation line.
DTC LogicINFOID:0000000001670976
DTC DETECTION LOGIC
NOTE:
If DTC P0500 is displayed with DTC U1000 or U1001, first perform the trouble diagnosis for DTC
U1000, U1001.Refer to EC-128, "
DTC Logic".
If DTC P0500 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer
to EC-129, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.INSPECTION START
Do you have CONSULT-III?
Do you have CONSULT-III?
YES >> GO TO 2.
NO >> GO TO 5.
2.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
>> GO TO 3.
3.CHECK VEHICLE SPEED SENSOR FUNCTION
NOTE:
This procedure may be conducted with the drive wheels lifted in the shop or by driving the vehicle. If a
road test is expected to be easier, it is unnecessary to lift the vehicle.
With CONSULT-III
1. Start engine.
2. Read “VHCL SPEED SE” in “DATA MONITOR” mode with CONSULT-III. The vehicle speed on CON-
SULT-III should exceed 10 km/h (6 mph) when rotating wheels with suitable gear position.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Go to EC-214, "
Diagnosis Procedure".
4.PERFORM DTC CONFIRMATION PROCEDURE
1. Select “DATA MONITOR” mode with CONSULT-III.
2. Warm engine up to normal operating temperature.
3. Maintain the following conditions for at least 50 consecutive seconds.
CAUTION:
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0500 Vehicle speed sensorThe almost 0 km/h (0 MPH) signal from
vehicle speed sensor is sent to ECM even
when vehicle is being driven. Harness or connectors
(The CAN communication line is open or short-
ed)
Harness or connectors
(The vehicle speed signal circuit is open or
shorted)
Wheel sensor
Combination meter
ABS actuator and electric unit (control unit)

Page 1563 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-214
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P0500 VSS
Always drive vehicle at a safe speed.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-214, "Diagnosis Procedure".
NO >

Page 1564 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0605 ECM
EC-215
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P0605 ECM
DescriptionINFOID:0000000001670979
The ECM consists of a microcomputer and connectors for sig

Page 1565 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-216
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P0605 ECM
Diagnosis Procedure
INFOID:0000000001670981
1.INSPECTION START
With CONSULT-III
1. Turn ignition switch ON.
2. Select “SELF-DIAG RESU

Page 1566 of 5883

NISSAN TIIDA 2007 Service Repair Manual P1065 ECM
EC-217
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1065 ECM
DescriptionINFOID:0000000001161270
ECM has the memory function of the DTC memory, the air-fue

Page 1567 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-218
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P1065 ECM
NO >> INSPECTION END
2.REPLACE ECM
1. Replace ECM.
2. Go to EC-25, "
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Re

Page 1568 of 5883

NISSAN TIIDA 2007 Service Repair Manual P1111 IVT CONTROL SOLENOID VALVE
EC-219
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1111 IVT CONTROL SOLENOID VALVE
DescriptionINFOID:0000000001670983
Intake valve

P1111 IVT CONTROL SOLENOID VALVE
EC-219
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1111 IVT CONTROL SOLENOID VALVE
DescriptionINFOID:0000000001670983
Intake valve timing control solenoid valve is activated by ON/OFF
pulse duty (ratio) signals from the ECM.
The intake valve timing control solenoid valve changes the oil
amount and direction of flow through intake valve timing control unit
or stops oil flow.
The longer pulse width advances valve angle.
The shorter pulse width retards valve angle.
When ON and OFF pulse widths become equal, the solenoid valve
stops oil pressure flow to fix the intake valve angle at the control
position.
DTC LogicINFOID:0000000001670984
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
>> GO TO2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-219, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001670985
1.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect intake valve timing control solenoid valve harness connector.
3. Turn ignition switch ON.
4. Check the voltage between intake valve timing control solenoid valve harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTION PART
PBIB1842E
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1111Intake valve timing control
solenoid valve circuitAn improper voltage is sent to the ECM
through intake valve timing control solenoid
valve. Harness or connectors
(Intake valve timing control solenoid valve
circuit is open or shorted.)
Intake valve timing control solenoid valve
IVT control solenoid valve
Ground Voltage
Connector Terminal
F23 1 Ground Battery voltage

Load next 8 pages
