Page 1409 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-60 < FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)] AIR CONDITIONING CUT CONTROL Component Description INFOID:0000000001161153 1. ASCD steering switch 2. MAIN switch 3. CANCEL switch 4. SET/COAST swi

Page 1410 of 5883

NISSAN TIIDA 2007 Service Repair Manual AUTOMATIC SPEED CONTROL DEVICE (ASCD) EC-61 < FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)] C D E F G H I J K L MA EC N P O AUTOMATIC SPEED CONTROL DEVICE (ASCD) System DiagramINFOID:0000000001161154 S

Page 1411 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-62 < FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)] AUTOMATIC SPEED CONTROL DEVICE (ASCD) When any of following conditions exist, cruise operation will be canceled.  CANCEL switch is pressed  More

Page 1412 of 5883

NISSAN TIIDA 2007 Service Repair Manual AUTOMATIC SPEED CONTROL DEVICE (ASCD) EC-63 < FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)] C D E F G H I J K L MA EC N P O Component Parts LocationINFOID:0000000001677955 1. Ignition coil (with power

Page 1413 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-64 < FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)] AUTOMATIC SPEED CONTROL DEVICE (ASCD) 1. Mass air flow sensor (with intake air temperature sensor)2. Engine coolant temperature sensor 3. Electric

Page 1414 of 5883

NISSAN TIIDA 2007 Service Repair Manual AUTOMATIC SPEED CONTROL DEVICE (ASCD) EC-65 < FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)] C D E F G H I J K L MA EC N P O 1. ECM harness connectors 2. ECM 3. IPDM E/R 4. Fuel pump fuse (15A) 5. Intak

Page 1415 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-66 < FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)] AUTOMATIC SPEED CONTROL DEVICE (ASCD) 1. Exhaust manifold 2. Heated oxygen sensor 1 3. Heated oxygen sensor 2 4. Heated oxygen sensor 2 harness co

Page 1416 of 5883

NISSAN TIIDA 2007 Service Repair Manual AUTOMATIC SPEED CONTROL DEVICE (ASCD) EC-67 < FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)] C D E F G H I J K L MA EC N P O 1. Cooling fan motor harness connec- tor2. Crankshaft position sensor 3. Stop
