Page 4289 of 5883

NISSAN TIIDA 2007 Service Repair Manual ENGINE MAINTENANCE (K9K)
MA-49
< ON-VEHICLE MAINTENANCE >
C
D
E
F
G
H
I
J
K
L
MB
MAN
OA
5. Apply engine oil to the oil seal contact surface of the new oil fil-
ter.
6. Install the oil filter until it

Page 4290 of 5883

NISSAN TIIDA 2007 Service Repair Manual MA-50
< ON-VEHICLE MAINTENANCE >
CHASSIS AND BODY MAINTENANCE
CHASSIS AND BODY MAINTENANCE
Air Conditioner FilterINFOID:0000000001730893
1. Remove the instrument lower finisher and instrument lower co

Page 4291 of 5883

NISSAN TIIDA 2007 Service Repair Manual CHASSIS AND BODY MAINTENANCE
MA-51
< ON-VEHICLE MAINTENANCE >
C
D
E
F
G
H
I
J
K
L
MB
MAN
OA
2. Remove filler plug (1) and check oil level at filler plug hole as
shown.
CAUTION:
Do not start engine wh

Page 4292 of 5883

NISSAN TIIDA 2007 Service Repair Manual MA-52
< ON-VEHICLE MAINTENANCE >
CHASSIS AND BODY MAINTENANCE
d. Remove A/T fluid level gauge and wipe clean with lint-free cloth.
CAUTION:
When wiping the A/T fluid level gauge, always use lint-free

MA-52
< ON-VEHICLE MAINTENANCE >
CHASSIS AND BODY MAINTENANCE
d. Remove A/T fluid level gauge and wipe clean with lint-free cloth.
CAUTION:
When wiping the A/T fluid level gauge, always use lint-free
cloth.
e. Re-insert A/T fluid level gauge into A/T fluid charging pipe as far
as it will go.
CAUTION:
Firmly fix the A/T fluid level gauge to the A/T fluid charging
pipe using the stopper attached.
f. Remove A/T fluid level gauge and note reading. If reading is at
low side of range, add A/T fluid to the A/T fluid charging pipe.
CAUTION:
Do not overfill.
4. Drive vehicle for approximately 5 minutes.
5. Re-check A/T fluid level at A/T fluid temperatures of 50 to 80°C (122 to 176°F) using “HOT” range on A/T
fluid level gauge.
CAUTION:
When wiping the A/T fluid level gauge, always use lint-free cloth.
Firmly fix the A/T fluid level gauge to the A/T fluid charging pipe using the stopper attached.
6. Check A/T fluid condition and make any necessary repairs. Refer to TM-171, "
Checking A/T Fluid" (TYPE
1) or TM-473, "
Checking A/T Fluid" (TYPE 2). If the A/T fluid contains frictional material (clutches, bands,
etc.), or if the A/T is repaired, overhauled, or replaced, inspect and clean the A/T fluid cooler mounted in
the radiator. Refer to TM-172, "
A/T Fluid Cooler Cleaning" (TYPE 1) or TM-474, "A/T Fluid Cooler Clean-
ing" (TYPE 2).
7. Install the removed A/T fluid level gauge into the A/T fluid charging pipe.
CAUTION:
Firmly fix the A/T fluid level gauge to the A/T fluid charging pipe using the stopper attached.
Changing A/T Fluid: RE4F03BINFOID:0000000001730902
1. Warm up A/T fluid.
2. Stop engine.
3. Drain A/T fluid by removing the drain plug. Reinstall the drain plug to the specified torque.
CAUTION:
Do not reuse drain plug gasket.
4. Refill the transaxle with new specified A/T fluid through the A/T fluid charging pipe. Always refill the tran-
saxle with the same volume of A/T fluid that was drained out.
5. Run engine at idle speed for 5 minutes.
6. Check A/T fluid level and condition. Refer to TM-171, "
Checking A/T Fluid" (TYPE 1) or TM-473, "Check-
ing A/T Fluid" (TYPE 2).
Checking A/T Fluid: RSF91RINFOID:0000000001730929
Changing A/T Fluid: RS9F94RINFOID:0000000001730930
DRAINING
1. Start engine and let it run to warm up transaxle.
SMA051D
Drain plug: Refer to TM-210, "Exploded View"
(TYPE 1) or TM-503, "
Exploded
View" (TYPE 2).
Fluid grade and capacity: Refer to MA-19, "
Fluids and Lubricants" .

Page 4293 of 5883

NISSAN TIIDA 2007 Service Repair Manual CHASSIS AND BODY MAINTENANCE
MA-53
< ON-VEHICLE MAINTENANCE >
C
D
E
F
G
H
I
J
K
L
MB
MAN
OA
2. Stop engine. Remove drain plug (1) and drain oil.
3. Set a new gasket on drain plug (1) and install it to

Page 4294 of 5883

NISSAN TIIDA 2007 Service Repair Manual MA-54
< ON-VEHICLE MAINTENANCE >
CHASSIS AND BODY MAINTENANCE
Checking Brake Fluid Level and Leaks
INFOID:0000000001730905
Make sure the fluid level in the reservoir tank is within the standard
(bet

Page 4295 of 5883

NISSAN TIIDA 2007 Service Repair Manual CHASSIS AND BODY MAINTENANCE
MA-55
< ON-VEHICLE MAINTENANCE >
C
D
E
F
G
H
I
J
K
L
MB
MAN
OA
2. Depress the brake pedal, loosen the bleed valve, and gradually
remove the brake fluid.
3. Clean inside of

Page 4296 of 5883

NISSAN TIIDA 2007 Service Repair Manual MA-56
< ON-VEHICLE MAINTENANCE >
CHASSIS AND BODY MAINTENANCE
Check the brake pads for wear or damage. Refer to BR-24,
"Removal and Installation of Brake Pad" .
Axle and Suspension PartsINFOID:0000000

Load next 8 pages
