STR-26
< BASIC INSPECTION >[K9K]
DIAGNOSIS AND REPAIR WORKFLOW
NOTE:
If any malfunction is found, immediately disconnect the battery cable from the negative terminal.
1.CHECK ENGINE START
Crank the engine and check that the engine starts.
Does the engine start?
YES >> GO TO 2
NO >> GO TO 3
2.CHECK THAT THE STARTER MOTOR STOPS
Check that the starter motor stops after starting the engine.
Does the starter motor stop?
YES >> INSPECTION END.
NO >> Replace starter motor.
3.CHECK THE ENGINE SPEED WITH CRANKING
Check that the engine runs at cranking.
Does engine turn by cranking?
YES >> GO TO 4
NO >> GO TO 5
4.CHECK THE ENGINE SPEED WITH CRANKING
Check that the engine speed is not low at cranking.
Does engine turn normally?
YES >> Check ignition/fuel system.
NO >> Check charge condition, corrosion and connection condition of the battery. Refer to STR-25,
"Work Flow".
5.CHECK STARTER MOTOR ACTIVATION
Check that the starter motor runs at cranking.
Does starter motor turn?
YES >> GO TO 6
NO >> GO TO 7
6.ENGINE ROTATION STATUS
Check that the engine can be rotated by hand.
Does engine turn freely by hand?
YES >> Replace starter motor.
NO >> Perform further diagnosis of engine mechanical or powertrain mechanism. Refer to EM, TM or CL
sections.
7.CHECK POWER SUPPLY CIRCUIT
Check the following conditions.
Fuse and fusible link
Charge condition, corrosion and connection condition of the battery. Refer to STR-25, "
Work Flow".
Are these inspection results normal?
YES >> GO TO 8
NO >> Repair as needed.
8.CHECK STARTING SYSTEM WIRING
Check the following.
“B” terminal circuit. Refer to STR-30, "
Description"
“S” terminal circuit. Refer to STR-31, "Description"
Are these inspection results normal?
YES >> GO TO 9
NO >> Repair as needed.
Page 4938 of 5883
DIAGNOSIS AND REPAIR WORKFLOW
STR-27
< BASIC INSPECTION >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
STR
N
P O
9.CHECK MAGNETIC SWITCH OPERATION SOUND
Check that a magnetic switch operation sound can be heard when the ignition switch is set at the starting posi-
tion.
Does magnetic switch operation sound occur?
YES >> GO TO 10
NO >> Replace starter motor.
10.PINION AND RING GEAR ENGAGEMENT CHECK
Check condition of pinion and ring gear mesh.
Is the inspection result normal?
YES >> Replace starter motor.
NO >> GO TO 11
11 .CHECK STARTER MOTOR UNIT
Check the following.
Check pinion moving mechanism.
Check ring gear.
Are these inspection results normal?
YES >> INSPECTION END.
NO >> Repair or replace, if necessary.
Page 4939 of 5883
STR-28
< FUNCTION DIAGNOSIS >[K9K]
STARTING SYSTEM
FUNCTION DIAGNOSIS
STARTING SYSTEM
System DiagramINFOID:0000000001728574
System DescriptionINFOID:0000000001728575
The starter motor plunger closes and provides a closed circuit between the battery and the starter motor. The
starter motor is grounded to the cylinder block. With power and ground supplied, the starter motor operates.
Component Parts LocationINFOID:0000000001728576
ALBIA0473GB
1. IPDM E/R E44, E45, E46 2. BCM M18 (view with glove box re-
moved)
ALBIA0475GB
Page 4940 of 5883
STARTING SYSTEM
STR-29
< FUNCTION DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
STR
N
P O
Component DescriptionINFOID:0000000001728577
Component part Description
BCMBCM sends a starter request signal to the CPU of the IPDM E/R
over the CAN communication lines.
IPDM E/RCPU inside IPDM E/R operates the starter relay at the request of
the BCM over the CAN communication lines.
Starter motorThe starter motor plunger closes and the motor is supplied with
battery power, which in turn cranks the engine, when the “S” ter-
minal is supplied with electric power.
Page 4941 of 5883
![NISSAN TIIDA 2007 Service Repair Manual STR-30
< COMPONENT DIAGNOSIS >[K9K]
B TERMINAL CIRCUIT
COMPONENT DIAGNOSIS
B TERMINAL CIRCUIT
DescriptionINFOID:0000000001728578
Terminal "2" (B) is constantly supplied with battery power.
Diagnosis P NISSAN TIIDA 2007 Service Repair Manual STR-30
< COMPONENT DIAGNOSIS >[K9K]
B TERMINAL CIRCUIT
COMPONENT DIAGNOSIS
B TERMINAL CIRCUIT
DescriptionINFOID:0000000001728578
Terminal "2" (B) is constantly supplied with battery power.
Diagnosis P](/manual-img/5/57395/w960_57395-4940.png)
STR-30
< COMPONENT DIAGNOSIS >[K9K]
B TERMINAL CIRCUIT
COMPONENT DIAGNOSIS
B TERMINAL CIRCUIT
DescriptionINFOID:0000000001728578
Terminal "2" (B) is constantly supplied with battery power.
Diagnosis ProcedureINFOID:0000000001728579
CAUTION:
Perform diagnosis under the condition that the engine cannot start by the following procedure.
1. Remove fuel pump fuse.
2. Crank or start the engine (where possible) until the fuel pressure is depleted.
1.CHECK TERMINAL 2 POWER SUPPLY VOLTAGE
1. Turn ignition switch OFF.
2. Make sure that starter motor connector F27 terminal 2 connection is clean and tight.
3. Check voltage between starter motor connector F27 terminal 2
and ground.
Is there battery voltage present?
YES >> GO TO 2
NO >> Check harness between battery and starter motor for
open circuit.
2.CHECK BATTERY CABLE (VOLTAGE DROP TEST)
1. Shift the transmission into park or neutral.
2. Check voltage between battery positive terminal and starter
motor connector F27 terminal 2 while cranking the engine.
Is the voltage drop less than 0.2V?
YES >> GO TO 3
NO >> Check harness between the battery and the starter
motor for high resistance.
3.CHECK GROUND CIRCUIT STATUS (VOLTAGE DROP TEST)
Check voltage between starter motor case and battery negative ter-
minal while cranking the engine.
Is the voltage drop less than 0.2V?
YES >> Terminal 2 circuit is OK. Further inspection necessary.
Refer to STR-25, "
Work Flow".
NO >> Check the starter motor case to engine mounting for
high resistance.
(+)
(-) Condition Voltage
Connector Terminal
F27 2 GroundWhile cranking the
engineBattery voltage
AWBIA0122GB
(+)
(-) Condition Voltage
Connector Terminal
F27 2Battery (+)
terminalWhile cranking the
engineLess than 0.2V
AWBIA0123GB
(+) (-) Condition Voltage
Starter motor
caseBattery (-) terminalWhile cranking the
engineLess than 0.2V
AWBIA0124GB
Page 4942 of 5883
![NISSAN TIIDA 2007 Service Repair Manual S CONNECTOR CIRCUIT
STR-31
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
STR
N
P O
S CONNECTOR CIRCUIT
DescriptionINFOID:0000000001728580
Terminal "1" (S) is the power supply for the starter mot NISSAN TIIDA 2007 Service Repair Manual S CONNECTOR CIRCUIT
STR-31
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
STR
N
P O
S CONNECTOR CIRCUIT
DescriptionINFOID:0000000001728580
Terminal "1" (S) is the power supply for the starter mot](/manual-img/5/57395/w960_57395-4941.png)
S CONNECTOR CIRCUIT
STR-31
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
STR
N
P O
S CONNECTOR CIRCUIT
DescriptionINFOID:0000000001728580
Terminal "1" (S) is the power supply for the starter motor magnetic switch. Terminal 1 is supplied with power
when the ignition switch is turned to the START position while the selector lever is in the P or N position.
Diagnosis ProcedureINFOID:0000000001728581
CAUTION:
Perform diagnosis under the condition that engine cannot start by the following procedure.
1. Remove fuel pump fuse.
2. Crank or start the engine (where possible) until the fuel pressure is released.
1.CHECK STARTER MOTOR MAGNETIC SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect starter motor connector F28.
3. Shift transmission into park or neutral.
4. Check voltage between starter motor harness connector F28
terminal 1 and ground with the ignition in START.
Is battery voltage present?
YES >> Magnetic switch circuit is OK. Further inspection necessary. Refer to STR-25, "Work Flow".
NO >> GO TO 2
2.CHECK CONNECTOR
1. Turn ignition switch OFF.
2. Check the IPDM E/R harness connector E44 and starter motor harness connector F28 for damage, bent
pins and loose connections.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair the terminal and connector.
3.CHECK HARNESS CONTINUITY (OPEN CIRCUIT)
1. Disconnect IPDM E/R connector E44 and starter motor connec-
tor F28.
2. Check continuity between starter motor harness connector F28
(A) terminal 1 and IPDM E/R harness connector E44 (B) termi-
nal 19.
3. Check continuity between starter motor harness connector F28
(A) terminal 1 and ground.
Are the continuity test results as specified?
YES >> Further inspection necessary. Refer to STR-25, "Work Flow".
NO >> Repair the harness.
(+)
(-) Condition Voltage
Connector Terminal
F28 1 GroundWhile cranking the
engineBattery voltage
AWBIA0125GB
AB
Continiuty
Connector Terminal Connector Terminal
F28 1 E44 19 Yes
A
— Continiuty
Connector Terminal
F28 1 Ground No
AWBIA0126GB
Page 4943 of 5883
STR-32
< COMPONENT DIAGNOSIS >[K9K]
STARTING SYSTEM
STARTING SYSTEM
Wiring DiagramINFOID:0000000001728582
AWBWA0020GB
Page 4944 of 5883
STARTING SYSTEM
STR-33
< SYMPTOM DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
STR
N
P O
SYMPTOM DIAGNOSIS
STARTING SYSTEM
Symptom TableINFOID:0000000001728583
Symptom Reference
No normal cranking
Refer to STR-25, "
Work Flow".
Starter motor does not rotate
