EM-82
< ON-VEHICLE REPAIR >[HR16DE]
CYLINDER HEAD
In this step, loosen bolts in reverse order of that indicated.
d. Tighten all bolts.
e. Turn all bolts 75 degrees clockwise (angle tightening).
CAUTION:
Check and confirm the tightening angle by using the angle
wrench [SST: KV10112100] (A) or protractor. Avoid judg-
ment by visual inspection without the tool.
f. Turn all bolts 75 degrees clockwise again (angle tightening).
3. Installation is in the reverse order of removal, for the remaining parts.
INSPECTION AFTER INSTALLATION
Inspection for Leaks
Before starting engine, check oil/fluid levels including engine coolant and engine oil. If less than required
quantity, fill to the specified level. Refer to MA-19, "
Fluids and Lubricants".
Use procedure below to check for fuel leakage.
- Turn ignition switch “ON” (with engine stopped). With fuel pressure applied to fuel piping, check for fuel leak-
age at connection points.
- Start engine. With engine speed increased, check again for fuel leakage at connection points.
Run engine to check for unusual noise and vibration.
Warm up engine thoroughly to make sure there is no leakage of fuel, exhaust gases, or any oil/fluids includ-
ing engine oil and engine coolant.
Bleed air from lines and hoses of applicable lines, such as in cooling system.
After cooling down engine, again check oil/fluid levels including engine oil and engine coolant. Refill to the
specified level, if necessary.
Summary of the inspection items:
*: Transmission/transaxle/CVT fluid, power steering fluid, brake fluid, etc.
Disassembly and AssemblyINFOID:0000000001381422
: 40.0 N·m (4.1 kg-m, 30 ft-lb)
PBIC3733E
Items Before starting engine Engine running After engine stopped
Engine coolant Level Leakage Level
Engine oil Level Leakage Level
Other oils and fluid* Level Leakage Level
Fuel Leakage Leakage Leakage
Exhaust gases — Leakage —
Page 2730 of 5883
![NISSAN TIIDA 2007 Service Repair Manual CYLINDER HEAD
EM-83
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
DISASSEMBLY
1. Remove spark plug with a spark plug wrench (commercial service tool).
2. Remove valve lifter.
Identif NISSAN TIIDA 2007 Service Repair Manual CYLINDER HEAD
EM-83
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
DISASSEMBLY
1. Remove spark plug with a spark plug wrench (commercial service tool).
2. Remove valve lifter.
Identif](/manual-img/5/57395/w960_57395-2729.png)
CYLINDER HEAD
EM-83
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
DISASSEMBLY
1. Remove spark plug with a spark plug wrench (commercial service tool).
2. Remove valve lifter.
Identify installation positions, and store them without mixing them up.
3. Remove valve collet.
Compress valve spring with the valve spring compressor, the
attachment and the adapter [SST: KV10116200] (A). Remove
valve collet with a magnet hand (B).
CAUTION:
Be careful not to damage valve lifter holes.
4. Remove valve spring retainer and valve spring.
5. Push valve stem to combustion chamber side, and remove valve.
Identify installation positions, and store them without mixing them up.
1. Spark plug 2. Valve collet 3. Valve spring retainer
4. Valve spring 5. Valve spring seat 6. Valve oil seal
7. Valve guide (EXH) 8. Valve guide (INT) 9. Cylinder head
10. Valve seat (EXH) 11. Valve (EXH) 12. Valve seat (INT)
13. Valve (INT)
A. Refer to EM-82
B. Refer to EM-82
PBIC3734E
PBIC3727E
Page 2731 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-84
< ON-VEHICLE REPAIR >[HR16DE]
CYLINDER HEAD
6. Remove valve oil seal with the valve oil seal puller [SST:
KV10107902] (A).
7. Remove valve spring seat.
8. Remove valve seat, if valve seat must b NISSAN TIIDA 2007 Service Repair Manual EM-84
< ON-VEHICLE REPAIR >[HR16DE]
CYLINDER HEAD
6. Remove valve oil seal with the valve oil seal puller [SST:
KV10107902] (A).
7. Remove valve spring seat.
8. Remove valve seat, if valve seat must b](/manual-img/5/57395/w960_57395-2730.png)
EM-84
< ON-VEHICLE REPAIR >[HR16DE]
CYLINDER HEAD
6. Remove valve oil seal with the valve oil seal puller [SST:
KV10107902] (A).
7. Remove valve spring seat.
8. Remove valve seat, if valve seat must be replaced.
Bore out old seat until it collapses. Boring should not continue beyond the bottom face of the seat
recess in cylinder head. Set the machine depth stop to ensure this.
CAUTION:
Never bore excessively to prevent cylinder head from scratching.
9. Remove valve guide, if valve guide must be replaced.
a. To remove valve guide, heat cylinder head to 110 to 130°C (230
to 266°F) by soaking in heated oil (A).
b. Drive out valve guide with a press [under a 20 kN (2 ton, 2.2 US
ton, 2.0 lmp ton) pressure] or a hammer and the valve guide drift
(commercial service tool).
WARNING:
Cylinder head contains heat. Wear protective equipment to
avoid getting burned.
INSPECTION AFTER DISASSEMBLY
Valve Dimensions
Check the dimensions of each valve. For the dimensions, refer to EM-125, "Cylinder Head".
If dimensions are out of the standard, replace valve and check valve seat contact. Check “VALVE SEAT
CONTACT”.
Valve Guide Clearance
Valve Stem Diameter
PBIC3728E
JPBIA0184ZZ
SEM931C
Page 2732 of 5883
![NISSAN TIIDA 2007 Service Repair Manual CYLINDER HEAD
EM-85
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Measure the diameter of valve stem with micrometer (A).
Valve Guide Inner Diameter Measure the inner diameter of va NISSAN TIIDA 2007 Service Repair Manual CYLINDER HEAD
EM-85
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Measure the diameter of valve stem with micrometer (A).
Valve Guide Inner Diameter Measure the inner diameter of va](/manual-img/5/57395/w960_57395-2731.png)
CYLINDER HEAD
EM-85
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Measure the diameter of valve stem with micrometer (A).
Valve Guide Inner Diameter Measure the inner diameter of valve guide with bore gauge.
Valve Guide Clearance (Valve guide clearance) = (Valve guide inner diameter) – (Valve
stem diameter)
If the calculated value exceeds the limit, replace valve and/or valve guide. When valve guide must be
replaced, use “VALVE GUIDE REPLACEMENT”.
Valve Seat Contact
After confirming that the dimensions of valve guides and valves are
within the specifications, perform this procedure.
Apply prussian blue (or white lead) onto contacting surface of valve
seat to check the condition of the valve contact on the surface.
Check if the contact area band is continuous all around the circum-
ference.
If not, grind to adjust valve fitting and check again. If the contacting
surface still has “NG” conditions even after the re-check, replace
valve seat. Refer to EM-82, "
Disassembly and Assembly".
Valve Spring Squareness
Set a try square (A) along the side of valve spring and rotate
spring. Measure the maximum clearance between the top of spring
and try square.
If it exceeds the limit, replace valve spring.
Valve Spring Dimensions and Valve Spring Pressure Load
Check the valve spring pressure at specified spring height.
If the installation load or load with valve open is out of the stan-
dard, replace valve spring.
ASSEMBLY
1. When valve guide is removed, install it.
CAUTION:
Replace with oversize [0.2 mm (0.008 in)] valve guide.Standard : Refer to EM-125, "
Cylinder Head".
Standard : Refer to EM-125, "
Cylinder Head".
Standard and Limit : Refer to EM-125, "
Cylinder Head".
PBIC3213J
A: OK
B: NGJPBIA0187ZZ
B: Contact
Limit : Refer to EM-125, "Cylinder Head".
PBIC3219J
Standard : Refer to EM-125, "Cylinder Head".
SEM113
Page 2733 of 5883
EM-86
< ON-VEHICLE REPAIR >[HR16DE]
CYLINDER HEAD
a. Using the valve guide reamer (commercial service tool) (A),
ream cylinder head valve guide hole.
b. Heat cylinder head to 110 to 130°C (230 to 266°F) by soaking in
heated oil (A).
c. Using the valve guide drift (commercial service tool), press valve
guide (1) from camshaft side to the dimensions as shown.
WARNING:
Cylinder head (2) contains heat. Wear protective equipment
to avoid getting burned.
d. Using the valve guide reamer (commercial service tool) (A),
apply reamer finish to valve guide.
2. When valve seat is removed, install it.
CAUTION:
Replace with oversize [0.5 mm (0.020 in)] valve seat.For service parts: Oversized [0.2 mm (0.008 in)]
Refer to EM-125, "
Cylinder Head".
PBIC3215J
PBIC3214J
Projection “H”: Refer to EM-125, "Cylinder Head".
PBIC3217J
Standard: Refer to EM-125, "Cylinder Head".
PBIC3215J
Page 2734 of 5883
![NISSAN TIIDA 2007 Service Repair Manual CYLINDER HEAD
EM-87
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
a. Ream cylinder head recess diameter (a) for service valve seat.
Be sure to ream in circles concentric to valve gui NISSAN TIIDA 2007 Service Repair Manual CYLINDER HEAD
EM-87
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
a. Ream cylinder head recess diameter (a) for service valve seat.
Be sure to ream in circles concentric to valve gui](/manual-img/5/57395/w960_57395-2733.png)
CYLINDER HEAD
EM-87
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
a. Ream cylinder head recess diameter (a) for service valve seat.
Be sure to ream in circles concentric to valve guide center.
This will enable valve to fit correctly.
b. Heat cylinder head to 110 to 130°C (230 to 266°F) by soaking in
heated oil (A).
c. Provide valve seats cooled well with dry ice. Force fit valve seat into cylinder head.
WARNING:
Cylinder head contains heat. Wear protective equipment to avoid getting burned.
CAUTION:
Avoid directly touching cold valve seats.
d. Using the valve seat cutter set (commercial service tool) or valve
seat grinder, finish seat to the specified dimensions. Refer to
EM-125, "
Cylinder Head".
CAUTION:
When using the valve seat cutter, firmly grip cutter handle
with both hands. Then, press on the contacting surface all
around the circumference to cut in a single drive. Improper
pressure on with cutter or cutting many different times may
result in stage valve seat.
e. Using compound, grind to adjust valve fitting.
f. Check again for normal contact. Refer to EM-82, "
Disassembly and Assembly".
3. Install valve oil seal.
Install with the valve oil seal drift [SST: KV10115600] (A) to
match dimension as shown.
4. Install valve spring seat.
5. Install valve.
Install larger diameter to intake side.For service parts: Oversize [0.5 mm (0.020 in)]
Refer to EM-125, "
Cylinder Head".
JPBIA0188ZZ
PBIC3214J
SEM934C
Height “H” : 13.2 - 13.8 mm (0.520 - 0.543 in)
PBIC3211J
Page 2735 of 5883
EM-88
< ON-VEHICLE REPAIR >[HR16DE]
CYLINDER HEAD
6. Install valve spring.
NOTE:
It can be installed in either direction.
7. Install valve spring retainer.
8. Install valve collet.
Compress valve spring with the valve spring compressor, the
attachment and the adapter [SST: KV10116200] (A). Install
valve collet with a magnet hand (B).
CAUTION:
Be careful not to damage valve lifter holes.
Tap valve stem edge lightly with a plastic hammer after instal-
lation to check its installed condition.
9. Install valve lifter.
10. Install spark plug with a suitable tool.
PBIC3727E
Page 2736 of 5883
ENGINE ASSEMBLY
EM-89
< REMOVAL AND INSTALLATION >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
REMOVAL AND INSTALLATION
ENGINE ASSEMBLY
Exploded ViewINFOID:0000000001381424
Removal and InstallationINFOID:0000000001381425
WARNING:
Situate the vehicle on a flat and solid surface.
Place chocks at front and back of rear wheels.
Attach proper slingers and bolts described in PARTS CATALOG if engine slingers are not equipped.
CAUTION:
Always be careful to work safely, avoid forceful or uninstructed operations.
Never start working until exhaust system and coolant are cool enough.
1. Engine mounting insulator (LH) 2. Engine mounting bracket (LH) 3. Mass damper
4. Dynamic damper 5. Engine mounting insulator (RH) 6. Engine mounting stay
7. Engine mounting bracket (RH) 8. Rear engine mounting bracket 9. Rear torque rod
10. Washer 11. Engine mounting bracket (LH)
A. Front mark B. M/T models
PBIC3736E
