Page 4929 of 5883
STR-18
< FUNCTION DIAGNOSIS >[MR18DE]
STARTING SYSTEM
Component Description
INFOID:0000000001728566
Component part Description
PNP switchPNP switch supplies power to the starter relay when the selector
lever is shifted to the P or N position.
BCMBCM sends a starter request signal to the CPU of the IPDM E/R
over the CAN communication lines.
IPDM E/RCPU inside IPDM E/R operates the starter relay at the request of
the BCM over the CAN communication lines.
Starter motorThe starter motor plunger closes and the motor is supplied with
battery power, which in turn cranks the engine, when the “S” ter-
minal is supplied with electric power.
Page 4930 of 5883
![NISSAN TIIDA 2007 Service Repair Manual B TERMINAL CIRCUIT
STR-19
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
STR
N
P O
COMPONENT DIAGNOSIS
B TERMINAL CIRCUIT
DescriptionINFOID:0000000001728567
Terminal "2" (B) is constantly supp NISSAN TIIDA 2007 Service Repair Manual B TERMINAL CIRCUIT
STR-19
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
STR
N
P O
COMPONENT DIAGNOSIS
B TERMINAL CIRCUIT
DescriptionINFOID:0000000001728567
Terminal "2" (B) is constantly supp](/manual-img/5/57395/w960_57395-4929.png)
B TERMINAL CIRCUIT
STR-19
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
STR
N
P O
COMPONENT DIAGNOSIS
B TERMINAL CIRCUIT
DescriptionINFOID:0000000001728567
Terminal "2" (B) is constantly supplied with battery power.
Diagnosis ProcedureINFOID:0000000001728568
CAUTION:
Perform diagnosis under the condition that the engine cannot start by the following procedure.
1. Remove fuel pump fuse.
2. Crank or start the engine (where possible) until the fuel pressure is depleted.
1.CHECK TERMINAL 2 POWER SUPPLY VOLTAGE
1. Turn ignition switch OFF.
2. Make sure that starter motor connector F27 terminal 2 connection is clean and tight.
3. Check voltage between starter motor connector F27 terminal 2
and ground.
Is there battery voltage present?
YES >> GO TO 2
NO >> Check harness between battery and starter motor for
open circuit.
2.CHECK BATTERY CABLE (VOLTAGE DROP TEST)
1. Shift the transmission into park or neutral.
2. Check voltage between battery positive terminal and starter
motor connector F27 terminal 2 while cranking the engine.
Is the voltage drop less than 0.2V?
YES >> GO TO 3
NO >> Check harness between the battery and the starter
motor for high resistance.
3.CHECK GROUND CIRCUIT STATUS (VOLTAGE DROP TEST)
Check voltage between starter motor case and battery negative ter-
minal while cranking the engine.
Is the voltage drop less than 0.2V?
YES >> Terminal 2 circuit is OK. Further inspection necessary.
Refer to STR-14, "
Work Flow".
NO >> Check the starter motor case to engine mounting for
high resistance.
(+)
(-) Condition Voltage
Connector Terminal
F27 2 GroundWhile cranking the
engineBattery voltage
AWBIA0122GB
(+)
(-) Condition Voltage
Connector Terminal
F27 2Battery (+)
terminalWhile cranking the
engineLess than 0.2V
AWBIA0123GB
(+) (-) Condition Voltage
Starter motor
caseBattery (-) terminalWhile cranking the
engineLess than 0.2V
AWBIA0124GB
Page 4931 of 5883
![NISSAN TIIDA 2007 Service Repair Manual STR-20
< COMPONENT DIAGNOSIS >[MR18DE]
S CONNECTOR CIRCUIT
S CONNECTOR CIRCUIT
DescriptionINFOID:0000000001728569
Terminal "1" (S) is the power supply for the starter motor magnetic switch. Terminal 1 NISSAN TIIDA 2007 Service Repair Manual STR-20
< COMPONENT DIAGNOSIS >[MR18DE]
S CONNECTOR CIRCUIT
S CONNECTOR CIRCUIT
DescriptionINFOID:0000000001728569
Terminal "1" (S) is the power supply for the starter motor magnetic switch. Terminal 1](/manual-img/5/57395/w960_57395-4930.png)
STR-20
< COMPONENT DIAGNOSIS >[MR18DE]
S CONNECTOR CIRCUIT
S CONNECTOR CIRCUIT
DescriptionINFOID:0000000001728569
Terminal "1" (S) is the power supply for the starter motor magnetic switch. Terminal 1 is supplied with power
when the ignition switch is turned to the START position while the selector lever is in the P or N position.
Diagnosis ProcedureINFOID:0000000001728570
CAUTION:
Perform diagnosis under the condition that engine cannot start by the following procedure.
1. Remove fuel pump fuse.
2. Crank or start the engine (where possible) until the fuel pressure is released.
1.CHECK STARTER MOTOR MAGNETIC SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect starter motor connector F28.
3. Shift transmission into park or neutral.
4. Check voltage between starter motor harness connector F28
terminal 1 and ground with the ignition in START.
Is battery voltage present?
YES >> Magnetic switch circuit is OK. Further inspection necessary. Refer to STR-14, "Work Flow".
NO >> GO TO 2
2.CHECK CONNECTOR
1. Turn ignition switch OFF.
2. Check the IPDM E/R harness connector E44 and starter motor harness connector F28 for damage, bent
pins and loose connections.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair the terminal and connector.
3.CHECK HARNESS CONTINUITY (OPEN CIRCUIT)
1. Disconnect IPDM E/R connector E44 and starter motor connec-
tor F28.
2. Check continuity between starter motor harness connector F28
(A) terminal 1 and IPDM E/R harness connector E44 (B) termi-
nal 19.
3. Check continuity between starter motor harness connector F28
(A) terminal 1 and ground.
Are the continuity test results as specified?
YES >> Further inspection necessary. Refer to STR-14, "Work Flow".
NO >> Repair the harness.
(+)
(-) Condition Voltage
Connector Terminal
F28 1 GroundWhile cranking the
engineBattery voltage
AWBIA0125GB
AB
Continiuty
Connector Terminal Connector Terminal
F28 1 E44 19 Yes
A
— Continiuty
Connector Terminal
F28 1 Ground No
AWBIA0126GB
Page 4932 of 5883
STARTING SYSTEM
STR-21
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
STR
N
P O
STARTING SYSTEM
Wiring DiagramINFOID:0000000001728571
AWBWA0019GB
Page 4933 of 5883
STR-22
< SYMPTOM DIAGNOSIS >[MR18DE]
STARTING SYSTEM
SYMPTOM DIAGNOSIS
STARTING SYSTEM
Symptom TableINFOID:0000000001728572
Symptom Reference
No normal cranking
Refer to STR-14, "
Work Flow".
Starter motor does not rotate
Page 4934 of 5883
![NISSAN TIIDA 2007 Service Repair Manual PRECAUTIONS
STR-23
< PRECAUTION >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
STR
N
P O
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:000 NISSAN TIIDA 2007 Service Repair Manual PRECAUTIONS
STR-23
< PRECAUTION >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
STR
N
P O
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:000](/manual-img/5/57395/w960_57395-4933.png)
PRECAUTIONS
STR-23
< PRECAUTION >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
STR
N
P O
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000001689455
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-
ness connectors.
Page 4935 of 5883
STR-24
< ON-VEHICLE REPAIR >[MR18DE]
STARTER MOTOR
ON-VEHICLE REPAIR
STARTER MOTOR
Removal and InstallationINFOID:0000000001689442
REMOVAL
1. Disconnect the battery cable from the negative terminal.
2. Disconnect the oil pressure switch connector.
3. Remove “B” terminal nut and “B” terminal harness.
4. Remove “S” terminal nut and “S” terminal harness.
5. Remove starter motor bolts.
6. Remove starter motor upward from the vehicle.
CAUTION:
Never damage oil pressure switch when removing starter motor.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Be sure to tighten “B” terminal nut carefully.
1. "S" terminal harness 2. "B" terminal harness 3. Starter motor
4. Cylinder block Engine front
WKIA5611E
Page 4936 of 5883
DIAGNOSIS AND REPAIR WORKFLOW
STR-25
< BASIC INSPECTION >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
STR
N
P O
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORKFLOW
Work FlowINFOID:0000000001728601
OVERALL SEQUENCE
DETAILED FLOW
JSBIA0008GB
