BRC-64
< ECU DIAGNOSIS >[ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
RR RH OUT SOL Operation status of each solenoid valve Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT-III) or actua-
tor relay is inactive (in fail-safe mode)ON
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON)OFF
RR LH IN SOL Operation status of each solenoid valve Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT-III) or actua-
tor relay is inactive (in fail-safe mode)ON
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON)OFF
RR LH OUT SOL Operation status of each solenoid valve Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT-III) or actua-
tor relay is inactive (in fail-safe mode)ON
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON)OFF
MOTOR RELAY Motor and motor relay operationWhen the motor relay and motor are op-
eratingON
When the motor relay and motor are not
operatingOFF
ACTUATOR RLY Actuator relay operationWhen the actuator relay is operating ON
When the actuator relay is not operating OFF
ABS WARN LAMPABS warning lamp
(Note 3)When ABS warning lamp is ON ON
When ABS warning lamp is OFF OFF
OFF LAMPVDC OFF indicator lamp
(Note 3)When VDC OFF indicator lamp is ON ON
When VDC OFF indicator lamp is OFF OFF
SLIP LAMPSLIP indicator lamp
(Note 3)When SLIP indicator lamp is ON ON
When SLIP indicator lamp is OFF OFF
4WD FAIL REQ
(Note 2)Transfer control unit fail-safe signalWhen transfer control unit is in fail-safe
modeON
When transfer control unit is normal OFF
BST OPER SIG Not applied but displayed — OFF
EBD SIGNAL EBD operationEBD is active ON
EBD is inactive OFF
ABS SIGNAL ABS operationABS is active ON
ABS is inactive OFF
TCS SIGNAL TCS operationTCS is active ON
TCS is inactive OFF
VDC SIGNAL VDC operationVDC is active ON
VDC is inactive OFF
EBD FAIL SIG EBD fail-safe signalIn EBD fail-safe ON
EBD is normal OFF
ABS FAIL SIG ABS fail-safe signalIn ABS fail-safe ON
ABS is normal OFF Monitor item Display contentData monitor
ConditionReference value in
normal operation
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
BRC-65
< ECU DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
TCS FAIL SIG TCS fail-safe signalIn TCS fail-safe ON
TCS is normal OFF
VDC FAIL SIG VDC fail-safe signalIn VDC fail-safe ON
VDC is normal OFF
CRANKING SIG Crank operationCrank is active ON
Crank is inactive OFF
CV1 VDC switch-over valveWhen actuator (switch-over valve) is ac-
tive (“ACTIVE TEST” with CONSULT-III)
or actuator relay is inactive (when in fail-
safe mode)ON
When actuator (switch-over valve) is not
active and actuator relay is active (igni-
tion switch ON)OFF
CV2 VDC switch-over valveWhen actuator (switch-over valve) is ac-
tive (“ACTIVE TEST” with CONSULT-III)
or actuator relay is inactive (when in fail-
safe mode)ON
When actuator (switch-over valve) is not
active and actuator relay is active (igni-
tion switch ON)OFF
SV1 VDC switch-over valveWhen actuator (switch-over valve) is ac-
tive (“ACTIVE TEST” with CONSULT-III)
or actuator relay is inactive (when in fail-
safe mode)ON
When actuator (switch-over valve) is not
active and actuator relay is active (igni-
tion switch ON)OFF
SV2 VDC switch-over valveWhen actuator (switch-over valve) is ac-
tive (“ACTIVE TEST” with CONSULT-III)
or actuator relay is inactive (when in fail-
safe mode)ON
When actuator (switch-over valve) is not
active and actuator relay is active (igni-
tion switch ON)OFF
DECEL G-SENLongitudinal acceleration detected by Decel
G-SensorVehicle stopped Approx. 0 G
Vehicle running -1.7 to 1.7 G
EBD WARN LAMPEBD warning lamp
(Note 3)When EBD warning lamp is ON ON
When EBD warning lamp is OFF OFF
N POSI SIG PNP switch signal ON/OFF conditionA/T shift position = N position ON
A/T shift position = other than N position OFF
P POSI SIG PNP switch signal ON/OFF conditionA/T shift position = P position ON
A/T shift position = other than P position OFF
R POSI SIG PNP switch signal ON/OFF conditionA/T shift position = R position ON
A/T shift position = other than R position OFF
2WD/4WD Drive axle2WD model 2WD
4WD model 4WD
PRESS SEN2Brake fluid pressure detected by rear pres-
sure sensorWith ignition switch turned ON and brake
pedal releasedApprox. 0 bar
With ignition switch turned ON and brake
pedal depressed–40 to 300 bar Monitor item Display contentData monitor
ConditionReference value in
normal operation
BRC-66
< ECU DIAGNOSIS >[ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
NOTE:
1: Confirm tire pressure is normal.
2: Only 4WD models.
3: On and off timing for warning lamp and indicator lamp.
- ABS warning lamp: Refer to BRC-60, "
Description".
- Brake warning lamp: Refer to BRC-61, "
Description".
- VDC OFF indicator lamp: Refer to XX-XX, "*****"
.
- SLIP indicator lamp: Refer to XX-XX, "*****"
.
TERMINAL LAYOUT
DELTA S SEN Value detected by delta stroke sensorWhen brake pedal is depressed 1.05 - 1.80 mm
When brake pedal is released 0.00 mm (+0.6/-0.4)
RELEASE SWITCH
NO Active booster signal statusWhen brake pedal is depressed ON
When brake pedal is released OFF
RELEASE SWITCH
NC Active booster signal statusWhen brake pedal is depressed OFF
When brake pedal is released ON Monitor item Display contentData monitor
ConditionReference value in
normal operation
AWFIA0032ZZ
BRC-70
< ECU DIAGNOSIS >[ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Fail-Safe
INFOID:0000000001731341
CAUTION:
If the Fail-Safe function is activated, perform Self Diagnosis for ABS/TCS/VDC system.
ABS/EBD SYSTEM
ALFWA0020GB
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
BRC-71
< ECU DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
In case of an electrical malfunction with the ABS, the ABS warning lamp, VDC OFF indicator lamp and SLIP
indicator lamp will turn on. In case of an electrical malfunction with the EBD system, the BRAKE warning lamp,
ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp will turn on.
The system will revert to one of the following conditions of the Fail-Safe function.
1. For ABS malfunction, only the EBD is operative and the condition of the vehicle is the same condition of
vehicles without ABS/TCS/VDC system.
2. For EBD malfunction, the EBD and ABS become inoperative, and the condition of the vehicle is the same
as the condition of vehicles without ABS/TCS/VDC or EBD system.
VDC/TCS SYSTEM
In case of TCS/VDC system malfunction, the VDC OFF indicator lamp and SLIP indicator lamp are turned on
and the condition of the vehicle is the same as the condition of vehicles without TCS/VDC system. In case of
an electrical malfunction with the TCS/VDC system, the ABS control continues to operate normally without
TCS/VDC control.
DTC No. IndexINFOID:0000000001731342
DTC Items (CONSULT screen terms) Reference
C1101 RR RH SENSOR-1
BRC-30, "
Description"C1102 RR LH SENSOR-1
C1103 FR RH SENSOR-1
C1104 FR LH SENSOR-1
C1105 RR RH SENSOR-2
BRC-33, "
Description"C1106 RR LH SENSOR-2
C1107 FR RH SENSOR-2
C1108 FR LH SENSOR-2
C1109 BATTERY VOLTAGE [ABNORMAL]BRC-36, "
Description"
C1110 CONTROLLER FAILUREBRC-38, "DTC Logic"
C 1111 P U M P M O T O RBRC-39, "Description"
C1113 G-SENSORXX-XX, "*****"
C1115 ABS SENSOR [ABNORMAL SIGNAL]BRC-41, "Description"
C1116 STOP LAMP SWBRC-44, "Description"
C1120 FR LH IN ABS SOLBRC-46, "Description"
C1121 FR LH OUT ABS SOLBRC-49, "Description"
C1122 FR RH IN ABS SOLBRC-46, "Description"
C1123 FR RH OUT ABS SOLBRC-49, "Description"
C1124 RR LH IN ABS SOLBRC-46, "Description"
C1125 RR LH OUT ABS SOLBRC-49, "Description"
C1126 RR RH IN ABS SOLBRC-46, "Description"
C1127 RR RH OUT ABS SOLBRC-49, "Description"
C1130 ENGINE SIGNAL 1
BRC-52, "
Description"
C1131 ENGINE SIGNAL 2
C1132 ENGINE SIGNAL 3
C1133 ENGINE SIGNAL 4
C1136 ENGINE SIGNAL 6
C1140 ACTUATOR RLYBRC-54, "
Description"
C1142 PRESS SEN CIRCUITXX-XX, "*****"
C1143 ST ANG SEN CIRCUIT
XX-XX, "*****"
C1144 ST ANG SEN SIGNAL
