INSPECTION
Pistons, Retainers and Piston Stem
Check the sliding surfaces for damage or excessive wear. Replace if necessary.
Return Springs
Check each return spring for damage or deformation. Also mea-
sure free length. Refer to TM-323, "
Band Servo".
Replace springs if deformed or fatigued.
ASSEMBLY
1. Install D-rings to band servo piston.
2. Install band servo thrust washer (4), band servo piston (3), OD
servo return spring (2) and spring retainer (1) to band servo pis-
ton stem (5).
3. Place band servo piston stem (1) on a wooden block, and install
E-ring (2) to band servo piston stem (1) while pressing spring
retainer (3) downward.
SAT138D
SCIA3688E
SCIA7054E
SCIA7056E
Page 5530 of 5883
TM-584
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
REPAIR FOR COMPONENT PARTS
4. Install O-rings to servo piston retainer
5. Install band servo piston assembly to servo piston retainer by
pushing it inward.
6. Install D-ring (1) to OD servo piston (2).
7. Install O-rings (1), (2) and (3) to OD servo piston retainer (4).
(1): O-ring (small diameter)
(2): O-ring (medium diameter)
(3): O-ring (large diameter)
8. Install OD servo piston (1) to OD servo piston retainer (2) as
shown.
SCIA3671E
SAT303D
SCIA7053E
SCIA6492J
SCIA7057E
Page 5531 of 5883
REPAIR FOR COMPONENT PARTS
TM-585
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
9. Install 2nd servo return spring (2) and band servo piston assem-
bly (3) to transaxle case (1).
10. Install OD servo piston assembly (2) to transaxle case (1).
11. Push in OD servo piston assembly using suitable tool (A) and-
suitable tool (B), and install snap ring (1) to transaxle case using
suitable tool (C).
Final DriveINFOID:0000000001731447
COMPONENTS
SCIA6310J
SCIA6010J
SCIA7050E
SCIA7184E
Page 5532 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TM-586
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
REPAIR FOR COMPONENT PARTS
DISASSEMBLY
1. Remove final gear from differential case.
2. Remove differential side bearings according to the fol NISSAN TIIDA 2007 Service Repair Manual TM-586
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
REPAIR FOR COMPONENT PARTS
DISASSEMBLY
1. Remove final gear from differential case.
2. Remove differential side bearings according to the fol](/manual-img/5/57395/w960_57395-5531.png)
TM-586
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
REPAIR FOR COMPONENT PARTS
DISASSEMBLY
1. Remove final gear from differential case.
2. Remove differential side bearings according to the following procedures.
a. Set suitable tool (A) on differential case (1), and remove differ-
ential side bearing (RH side) (2) from differential case (1) using
suitable tool (B) and suitable tool (C).
b. Set suitable tool (A) on differential case (1), and remove differ-
ential side bearing (LH side) (2) from differential case (1) using
suitable tool (B).
3. Remove pinion mate gear and side gear according to the following procedures.
a. Drive out lock pin from differential case (1) using Tool (A).
1. Pinion mate gear thrust washer 2. Pinion mate gear 3. Pinion mate shaft
4. Side gear 5. Side gear thrust washer 6. Lock pin
7. Differential side bearing 8. Differential case 9. Final gear
10. Differential side bearing adjusting
shim
SCIA0286J
SCIA7059E
SCIA7060E
Tool number: KV32101000
SCIA7034E
Page 5533 of 5883
![NISSAN TIIDA 2007 Service Repair Manual REPAIR FOR COMPONENT PARTS
TM-587
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
b. Remove pinion mate shaft from differential case.
c. Rotate pinion mate gears an NISSAN TIIDA 2007 Service Repair Manual REPAIR FOR COMPONENT PARTS
TM-587
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
b. Remove pinion mate shaft from differential case.
c. Rotate pinion mate gears an](/manual-img/5/57395/w960_57395-5532.png)
REPAIR FOR COMPONENT PARTS
TM-587
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
b. Remove pinion mate shaft from differential case.
c. Rotate pinion mate gears and pinion mate gear thrust washers
to remove.
d. Remove side gears and side gear thrust washers from differen-
tial case.
INSPECTION
Gears, Washers, Pinion Mate Shaft and Differential Case
Check the sliding surfaces for wear, seizure, crack or damage.
Replace if necessary.
Bearings
Make sure bearings roll freely and are free from noise, cracks, pitting
or wear. Replace if necessary.
ASSEMBLY
1. Install pinion mate gears and side gears according to the following procedures.
a. Attach side gear thrust washers to side gears, then install pinion
mate gear thrust washers and pinion mate gears in place.
CAUTION:
Apply plenty of ATF to each sliding / rotating surface before
assembly.
b. Set 2 pinion mate gears and thrust washers on the same axis,
and while rotating them simultaneously, align them with the
insert hole of pinion mate shaft on differential case to insert pin-
ion mate shaft.
CAUTION:
After aligning 2 pinion mate gears with side gear teeth and
centering with pinion mate shaft, take pinion mate shaft out
and move pinion mate gears in place while rotating the them simultaneously.
2. Select side gear thrust washers according to the following procedures.
SAT316D
MTK0135D
SPD715
SAT318D
Page 5534 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TM-588
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
REPAIR FOR COMPONENT PARTS
a. Place differential case in the upright position so that the side
gear to be measured is at the top.
(A): Locati NISSAN TIIDA 2007 Service Repair Manual TM-588
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
REPAIR FOR COMPONENT PARTS
a. Place differential case in the upright position so that the side
gear to be measured is at the top.
(A): Locati](/manual-img/5/57395/w960_57395-5533.png)
TM-588
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
REPAIR FOR COMPONENT PARTS
a. Place differential case in the upright position so that the side
gear to be measured is at the top.
(A): Location for inserting feeler gauge
(B): Side gear tooth
(C): The center line of differential case
b. In order to maximize the back clearance, rotate side gears so
that a tooth on side gears at the top and bottom will align at the
same position as shown.
c. Adjust the back clearance of side gear according to the following
procedures.
i. Insert feeler gauges (A) of the same thickness to the back of
side gear from both sides, preventing side gear from falling, to
measure the clearance.
Measure clearance 3 times by rotating side gears and take the
average.
CAUTION:
In all 3 measurements, maximize the clearance by aligning
teeth on side gears at the top and bottom at the same posi-
tion.
ii. Select side gear thrust washer so that the clearance will fall
within the standard.
iii. Turn differential case upside down, and measure the back clear-
ance of the other side gear in the same manner.
NOTE:
Adjust the clearance to approx. 0.1 mm (0.004 in) for used differ-
ential [driven approx. 3,000 km (1864 mile) or more].
3. Install lock pin (1) to pinion mate shaft using Tool (A).
CAUTION:
Make sure that lock pin (1) flush with differential case.
4. Set Tool (A) on differential side bearing (RH side) (1), and press
differential side bearing (RH side) (1) to differential case (2).
CAUTION:
Set Tool (A) on differential side bearing inner race.
SCIA7064E
Differential side gear clearance:
Refer to TM-323, "
Final Drive".
SCIA7061E
Tool number: KV32101000
SCIA7228E
Tool number: ST33200000
SCIA7062E
Page 5535 of 5883
REPAIR FOR COMPONENT PARTS
TM-589
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
5. Set Tool (A) on differential side bearing (LH side) (1), and press
differential side bearing (LH side) (1) to differential case (2).
CAUTION:
Set Tool (A) on differential side bearing inner race.
6. Install final gear on differential case, and tighten bolts to the
specified torque in the numerical order as shown.Tool number: ST33200000
SCIA7063E
SCIA0294J
Page 5536 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TM-590
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
ASSEMBLY
ASSEMBLY
Assembly (1)INFOID:0000000001731448
1. Drive transaxle case side oil seal (1) using Tools, and converter
housing side oil s NISSAN TIIDA 2007 Service Repair Manual TM-590
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
ASSEMBLY
ASSEMBLY
Assembly (1)INFOID:0000000001731448
1. Drive transaxle case side oil seal (1) using Tools, and converter
housing side oil s](/manual-img/5/57395/w960_57395-5535.png)
TM-590
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
ASSEMBLY
ASSEMBLY
Assembly (1)INFOID:0000000001731448
1. Drive transaxle case side oil seal (1) using Tools, and converter
housing side oil seal (2) using suitable tool, to the dimensions as
shown
(A): Transaxle case side
(B): Converter housing side
NOTE:
Differential side oil seal pulling direction is used as the reference.
2. Install O-ring on governor cap.
CAUTION:
Do not reuse O-ring.
Apply ATF to O-ring.
3. Install governor cap in transaxle case.
4. Install snap ring in transaxle case.
5. Install parking actuator support (1) on transaxle case.
(A): Inside
(B): Outside
CAUTION:
Be careful with the direction of parking actuator support (1).
6. Tighten parking actuator support bolts to the specified torque.
7. Install parking pawl (2) on transaxle case, and secure it with
parking shaft (1).Tool numbers : ST35325000 ( — )
: KV31103000 ( — )
Dimension "C" : 0 ±±
Dimension "D" : 1.1 ± 0.5 mm (0.043 ± 0.020 in)
SCIA7226E
SCIA5910J
SCIA6997E
