Page 1113 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-524 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] UNLOCK SENSOR UNLOCK SENSOR DescriptionINFOID:0000000001530834 Detects door lock condition of driver door. Component Function CheckINFOID:00

Page 1114 of 5883

NISSAN TIIDA 2007 Service Repair Manual UNLOCK SENSOR DLK-525 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] C D E F G H I J L MA B DLK N O P 3. Check continuity between BCM connector (A) M19 terminal 58 and front door lock actuator (d

Page 1115 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-526 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] UNLOCK SENSOR 2. Check signal between BCM connector and ground with oscillo- scope. Is the inspection result normal? YES >> GO TO 5 NO >> Re

Page 1116 of 5883

NISSAN TIIDA 2007 Service Repair Manual UNLOCK SENSOR DLK-527 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] C D E F G H I J L MA B DLK N O P Is the inspection result normal? YES >> INSPECTION END. NO >> Replace front lock assembly (dr

Page 1117 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-528 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] DOOR LOCK ACTUATOR DOOR LOCK ACTUATOR DRIVER SIDE DRIVER SIDE : DescriptionINFOID:0000000001530646 Locks/unlocks the door with the signal fr

Page 1118 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR LOCK ACTUATOR DLK-529 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] C D E F G H I J L MA B DLK N O P 2. Check continuity between BCM connector (A) M20 terminals 76, 77 and front door lock a

Page 1119 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-530 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] DOOR LOCK ACTUATOR 2. Check voltage between BCM connector M20 terminals 67, 77 and ground. Is the inspection result normal? YES >> GO TO 2.

Page 1120 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR LOCK ACTUATOR DLK-531 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] C D E F G H I J L MA B DLK N O P 2. Check continuity between BCM connector M19 terminals 67, 77 and ground. Is the inspec
