NISSAN TIIDA 2007 Service Repair Manual EC-404 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] MULTIPORT FUEL INJECTION SYSTEM Component Parts Location INFOID:0000000001693465 1. Ignition coil (with power transistor) and spark plug2. Int

Page 1754 of 5883

NISSAN TIIDA 2007 Service Repair Manual MULTIPORT FUEL INJECTION SYSTEM EC-405 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC N P O 1. Mass air flow sensor (with intake air temperature sensor)2. Engine coolant t

Page 1755 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-406 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] MULTIPORT FUEL INJECTION SYSTEM 1. ECM harness connectors 2. ECM 3. IPDM E/R 4. Fuel pump fuse (15A) 5. Intake valve timing control solenoid v

Page 1756 of 5883

NISSAN TIIDA 2007 Service Repair Manual MULTIPORT FUEL INJECTION SYSTEM EC-407 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC N P O 1. Exhaust manifold 2. Heated oxygen sensor 1 3. Heated oxygen sensor 2 4. Heat

Page 1757 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-408 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] MULTIPORT FUEL INJECTION SYSTEM 1. Cooling fan motor harness connec- tor2. Crankshaft position sensor 3. Stop lamp switch 4. Brake pedal 5. Acc

Page 1758 of 5883

NISSAN TIIDA 2007 Service Repair Manual MULTIPORT FUEL INJECTION SYSTEM EC-409 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC N P O Component DescriptionINFOID:0000000001693466 1. ASCD steering switch 2. MAIN sw

Page 1759 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-410 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] ELECTRIC IGNITION SYSTEM ELECTRIC IGNITION SYSTEM System DiagramINFOID:0000000001693467 System DescriptionINFOID:0000000001693468 INPUT/OUTPUT

Page 1760 of 5883

NISSAN TIIDA 2007 Service Repair Manual ELECTRIC IGNITION SYSTEM EC-411 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC N P O operate under normal driving conditions. If engine knocking occurs, the knock sensor m
