Page 2737 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-90
< REMOVAL AND INSTALLATION >[HR16DE]
ENGINE ASSEMBLY
If items or work required are not covered by the engine section, follow the procedures in the applica-
ble sections.
Always use the suppo NISSAN TIIDA 2007 Service Repair Manual EM-90
< REMOVAL AND INSTALLATION >[HR16DE]
ENGINE ASSEMBLY
If items or work required are not covered by the engine section, follow the procedures in the applica-
ble sections.
Always use the suppo](/manual-img/5/57395/w960_57395-2736.png)
EM-90
< REMOVAL AND INSTALLATION >[HR16DE]
ENGINE ASSEMBLY
If items or work required are not covered by the engine section, follow the procedures in the applica-
ble sections.
Always use the support point specified for lifting.
Use either 2-pole lift type or separate type lift as best you can. If board-on type is used for unavoid-
able reasons, support at the rear axle jacking point with a transmission jack or similar tool before
starting work, in preparation for the backward shift of center of gravity.
For supporting points for lifting and jacking point at rear axle, refer to GI-48, "
Garage Jack and
Safety Stand and 2-Pole Lift".
REMOVAL
Outline
Remove the engine and the transaxle assembly from the vehicle downward. Separate the engine and the tran-
saxle.
Preparation
1. Remove the hood assembly. Refer to DLK-214, "Removal and Installation".
2. Remove the cowl top cover and cowl top extension assembly. Refer to EXT-20, "
Removal and Installa-
tion".
3. Release fuel pressure. Refer to EC-377, "
Inspection" (EURO-OBD), EC-681, "Inspection" (WITHOUT
EURO-OBD).
4. Drain engine coolant from radiator. Refer to CO-11, "
Changing Engine Coolant".
CAUTION:
Perform this step when the engine is cold.
Never spill engine coolant on drive belt.
5. Drain the transmission fluid. Refer to TM-628, "
Draining" (M/T models), TM-171, "Changing A/T Fluid" (A/
T models).
6. Remove the following parts.
Engine undercover
Front road wheels and tires: Refer to WT-6, "
Rotation".
Front fender protector (RH and LH): Refer to EXT-22, "
Removal and Installation".
Battery and battery tray: Refer to PG-6, "
Removal and Installation".
Drive belt: Refer to EM-16, "
Removal and Installation".
Air duct and air cleaner case assembly: Refer to EM-27, "
Exploded View".
Radiator hose (upper and lower): Refer to CO-16, "
Component".
Disconnect cooling fan controller wiring harness.
Remove coolant reservoir tank.
Remove fan shroud and cooling fan assembly. Refer to CO-16, "
Component".
Engine Room LH
1. Disconnect all connections of engine harness around the engine mounting insulator (LH), and then tem-
porarily secure the engine harness into the engine side.
CAUTION:
Protect connectors using a resin bag against foreign materials.
2. Remove ground cable at transaxle side.
3. Disconnect fuel feed hose at engine side. Refer to EM-35, "
Exploded View".
4. Disconnect EVAP purge hose and brake booster vacuum hose.
5. Disconnect heater hoses, and install plugs them to prevent engine coolant from draining. Refer to CO-24,
"Exploded View".
6. Disconnect control linkage from transaxle. Refer to TM-189, "
Exploded View" (A/T), TM-630, "Exploded
View" (M/T).
7. Disconnect the clutch tube at transmission side. Refer to CL-12, "
Removal and Installation".
Engine Room RH
1. Remove ground cable between front cover and vehicle.
2. Remove generator and generator bracket; Refer to CHG-15, "
Removal and Installation".
3. Remove A/C compressor with piping connected from the engine. Temporarily secure it on the vehicle side
with a rope to avoid putting load on it. (with A/C models) Refer to HA-34, "
Removal and Installation of
Compressor - HR16DE".
Page 2738 of 5883
![NISSAN TIIDA 2007 Service Repair Manual ENGINE ASSEMBLY
EM-91
< REMOVAL AND INSTALLATION >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O Vehicle Underbody
1. Remove front wheel sensor (LH and RH) for ABS from steering knuckle. Refer to BRC-83, "R NISSAN TIIDA 2007 Service Repair Manual ENGINE ASSEMBLY
EM-91
< REMOVAL AND INSTALLATION >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O Vehicle Underbody
1. Remove front wheel sensor (LH and RH) for ABS from steering knuckle. Refer to BRC-83, "R](/manual-img/5/57395/w960_57395-2737.png)
ENGINE ASSEMBLY
EM-91
< REMOVAL AND INSTALLATION >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O Vehicle Underbody
1. Remove front wheel sensor (LH and RH) for ABS from steering knuckle. Refer to BRC-83, "Removal and
Installation".
2. Remove brake caliper assembly with piping connected from steering knuckle. Temporarily secure it on the
vehicle side with a rope to avoid load on it. Refer to BR-24, "
Component".
3. Remove drive shafts (LH and RH) from steering knuckle. Refer to FAX-7, "
Removal and Installation".
4. Remove exhaust front tube. Refer to EX-5, "
Component".
5. Remove rear torque rod.
NOTE:
A/T models shown.
6. Remove A/T cooler hoses from transmission (A/T models).
7. Preparation for the separation work of transaxle is as follows:
Remove transaxle joint bolts which pierce at oil pan (upper) lower rear side. Refer to EM-89, "
Exploded
View".
Removal
1. Install engine slinger to cylinder head front left side (A) and rear
right side (B) and support the engine with a hoist.
2. Lift with a hoist and secure the engine in appropriate position.
3. Use a suitable tool to securely support bottom of the engine and
the transaxle assembly and simultaneously adjust hoist tension.
CAUTION:
Put a piece of wood or something similar as the supporting
surface, secure a completely stable condition.
PBIC3737E
PBIC3738E
PBIC3223J
Page 2739 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-92
< REMOVAL AND INSTALLATION >[HR16DE]
ENGINE ASSEMBLY
4. Remove engine mounting insulator (RH) (1), engine mounting
bracket (RH) (2) and engine mounting stay (3).
5. Remove engine mounting throug NISSAN TIIDA 2007 Service Repair Manual EM-92
< REMOVAL AND INSTALLATION >[HR16DE]
ENGINE ASSEMBLY
4. Remove engine mounting insulator (RH) (1), engine mounting
bracket (RH) (2) and engine mounting stay (3).
5. Remove engine mounting throug](/manual-img/5/57395/w960_57395-2738.png)
EM-92
< REMOVAL AND INSTALLATION >[HR16DE]
ENGINE ASSEMBLY
4. Remove engine mounting insulator (RH) (1), engine mounting
bracket (RH) (2) and engine mounting stay (3).
5. Remove engine mounting through bolt-securing nut (A).
6. Carefully lower jack, or raise lift to remove the engine and the transaxle assembly.
CAUTION:
Make sure that no part interferes with the vehicle side.
Before and during this lifting, always check if any harnesses are left connected.
During the removal, always be careful to prevent the vehicle from falling off the lift due to
changes in the center of gravity.
If necessary, support the vehicle by setting jack or suitable tool at the rear.
Separation
1. Remove starter motor. Refer to STR-13, "Removal and Installation".
2. Lift with a hoist and separate the engine from the transaxle assembly. Refer to EM-89, "
Exploded View".
INSTALLATION
Installation is in the reverse order of removal.
Do not allow engine oil to get on engine mounting insulator. Be careful not to damage engine mounting insu-
lator.
Make sure that each mounting insulator is seated properly, and tighten mounting nuts and bolts.
Tighten engine mounting insulator (RH) bolts in the numerical
order shown.
InspectionINFOID:0000000001381426
INSPECTION AFTER INSTALLATION
Inspection for Leaks
Before starting engine, check oil/fluid levels including engine coolant and engine oil. If less than required
quantity, fill to the specified level. Refer to MA-19, "
Fluids and Lubricants".
Use procedure below to check for fuel leakage.
- Turn ignition switch “ON” (with engine stopped). With fuel pressure applied to fuel piping, check for fuel leak-
age at connection points.
- Start engine. With engine speed increased, check again for fuel leakage at connection points.
Run engine to check for unusual noise and vibration.
Warm up engine thoroughly to make sure there is no leakage of fuel, exhaust gases, or any oil/fluids includ-
ing engine oil and engine coolant.
Bleed air from lines and hoses of applicable lines, such as in cooling system.
After cooling down engine, again check oil/fluid levels including engine oil and engine coolant. Refill to the
specified level, if necessary.
4 : Engine mounting insulator (LH)
JPBIA0512ZZ
: Vehicle front
JPBIA0280ZZ
Page 2740 of 5883
ENGINE ASSEMBLY
EM-93
< REMOVAL AND INSTALLATION >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Summary of the inspection items:
*: Transmission/transaxle/CVT fluid, power steering fluid, brake fluid, etc.Items Before starting engine Engine running After engine stopped
Engine coolant Level Leakage Level
Engine oil Level Leakage Level
Other oils and fluid* Level Leakage Level
Fuel Leakage Leakage Leakage
Exhaust gases — Leakage —
Page 2741 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-94
< DISASSEMBLY AND ASSEMBLY >[HR16DE]
ENGINE STAND SETTING
DISASSEMBLY AND ASSEMBLY
ENGINE STAND SETTING
SettingINFOID:0000000001381427
NOTE:
Explained here is how to disassemble with engine stan NISSAN TIIDA 2007 Service Repair Manual EM-94
< DISASSEMBLY AND ASSEMBLY >[HR16DE]
ENGINE STAND SETTING
DISASSEMBLY AND ASSEMBLY
ENGINE STAND SETTING
SettingINFOID:0000000001381427
NOTE:
Explained here is how to disassemble with engine stan](/manual-img/5/57395/w960_57395-2740.png)
EM-94
< DISASSEMBLY AND ASSEMBLY >[HR16DE]
ENGINE STAND SETTING
DISASSEMBLY AND ASSEMBLY
ENGINE STAND SETTING
SettingINFOID:0000000001381427
NOTE:
Explained here is how to disassemble with engine stand supporting transmission surface. When using differ-
ent type of engine stand, note with difference in steps and etc.
1. Remove the engine and the transaxle assembly from the vehicle, and separate the transaxle from the
engine. Refer to EM-89, "
Exploded View".
2. Remove clutch cover and clutch disc. Refer to CL-13, "
Removal and Installation".
3. Remove flywheel.
Secure flywheel with a stopper plate [SST: KV11105210], and remove mounting bolts.
CAUTION:
Never disassemble flywheel.
Never place flywheel with signal plate facing down.
When handling signal plate, take care not to damage or scratch it.
Handle signal plate in a manner that prevents it from becoming magnetized.
4. Lift the engine with a hoist to install it onto widely use engine stand.
CAUTION:
Use the engine stand that has a load capacity [approximately 135 kg (298 lb) or more] large
enough for supporting the engine weight.
If the load capacity of stand is not adequate, remove the following parts beforehand to reduce the poten-
tial risk of overturning stand.
- Intake manifold: Refer to EM-29, "
Exploded View".
- Exhaust manifold: Refer to EM-32, "
Exploded View".
- Rocker cover: Refer to EM-47, "
Exploded View".
NOTE:
The figure shows an example of widely use engine stand that
can support mating surface of transaxle with flywheel removed.
CAUTION:
Before removing the hanging chains, make sure the engine
stand is stable and there is no risk of overturning.
5. Drain engine oil. Refer to LU-7, "
Draining".
6. Drain engine coolant by removing water drain plug (1) from
inside of the engine.
Use Genuine Liquid Gasket or equivalent.
PBIC0085E
: Engine front
PBIC3742E
Page 2742 of 5883
ENGINE UNIT
EM-95
< DISASSEMBLY AND ASSEMBLY >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
ENGINE UNIT
DisassemblyINFOID:0000000001381428
1. Remove intake manifold. Refer to EM-29, "Exploded View".
2. Remove exhaust manifold. Refer to EM-32, "
Exploded View".
3. Remove oil pan (lower). Refer to EM-40, "
Exploded View".
4. Remove ignition coil, spark plug and rocker cover. Refer to EM-47, "
Exploded View".
5. Remove fuel injector and fuel tube. Refer to EM-35, "
Exploded View".
6. Remove timing chain. Refer to EM-50, "
Exploded View".
7. Remove camshaft. Refer to EM-59, "
Exploded View".
8. Remove cylinder head. Refer to EM-80, "
Removal and Installation".
AssemblyINFOID:0000000001381429
Assembly is the reverse order of disassembly.
Page 2743 of 5883
EM-96
< DISASSEMBLY AND ASSEMBLY >[HR16DE]
OIL PAN (UPPER)
OIL PAN (UPPER)
Exploded ViewINFOID:0000000001381430
Removal and InstallationINFOID:0000000001381431
NOTE:
The oil strainer and oil pump are included in the oil pan (upper). Individual disassembly is prohibited.
REMOVAL
1. Remove the oil pan (lower). Refer to EM-40, "Exploded View".
2. Remove front cover and timing chain. Refer to EM-50, "
Exploded View".
3. Remove oil pump sprocket and crankshaft sprocket together with oil pump drive chain. Refer to EM-50,
"Exploded View".
4. Remove oil pan (upper) with the following procedure.
1. Rear oil seal 2. O-ring 3. Oil pan (upper)
4. Chain tensioner 5. Oil pump drive chain 6. Crankshaft sprocket
7. Oil pump sprocket 8. Oil pan drain plug 9. Washer
10. Oil pan (lower) 11. Oil filter stud bolt 12. Oil filter
13. Oil level sensor
A. Refer to EM-50
B. Refer to LU-9C. Oil pan side
JPBIA0553GB
Page 2744 of 5883
![NISSAN TIIDA 2007 Service Repair Manual OIL PAN (UPPER)
EM-97
< DISASSEMBLY AND ASSEMBLY >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
a. Loosen oil pan (upper) mounting bolts in the reverse of the order
shown in the figure.
b. Insert a flat-bl NISSAN TIIDA 2007 Service Repair Manual OIL PAN (UPPER)
EM-97
< DISASSEMBLY AND ASSEMBLY >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
a. Loosen oil pan (upper) mounting bolts in the reverse of the order
shown in the figure.
b. Insert a flat-bl](/manual-img/5/57395/w960_57395-2743.png)
OIL PAN (UPPER)
EM-97
< DISASSEMBLY AND ASSEMBLY >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
a. Loosen oil pan (upper) mounting bolts in the reverse of the order
shown in the figure.
b. Insert a flat-bladed offset screwdriver into the arrow ( ) in the
figure and open up a crack between the oil pan (upper) cylinder
block.
c. Insert the seal cutter [SST: KV10111100] between remove the oil
pan (upper) and cylinder block. Slide seal cutter by tapping on
the side of tool with a hammer.
CAUTION:
Be careful not to damage the mating surface.
A more adhesive liquid gasket is applied compared to pre-
vious types when shipped, so it should not be forced off using a screwdriver, etc. outside the
indicated location.
Never remove oil pump and oil strainer from oil pan (upper).
5. Remove oil level sensor, if necessary.
6. Remove rear oil seal from crankshaft.
INSTALLATION
1. Install the oil pan (upper) in the following procedure.
a. Use scraper to remove old liquid gasket from mating surfaces.
Also remove the old liquid gasket from mating surface of cylinder block.
Remove old liquid gasket from the bolt holes and threads.
CAUTION:
Never scratch or damage the mating surfaces when cleaning off old liquid gasket.
b. Install O-ring to the cylinder block.
: Engine front
MBIB1374E
: Engine front
MBIB1375E
