Page 2937 of 5883
EM-290
< ON-VEHICLE REPAIR >[K9K]
ROCKER COVER
2. Apply liquid gasket on locations shown.
Use Genuine Liquid gasket or equivalent.
3. Tighten bolts in the numerical order as shown.
4. Installation is in the reverse order of removal.
MBIB0581E
: 12.0 N·m (1.2 kg-m, 9 ft-lb)
E1BIA0048ZZ
Page 2938 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TIMING BELT
EM-291
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
TIMING BELT
Exploded ViewINFOID:0000000001381499
Removal and InstallationINFOID:0000000001381500
CAUTION:
Apply new engi NISSAN TIIDA 2007 Service Repair Manual TIMING BELT
EM-291
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
TIMING BELT
Exploded ViewINFOID:0000000001381499
Removal and InstallationINFOID:0000000001381500
CAUTION:
Apply new engi](/manual-img/5/57395/w960_57395-2937.png)
TIMING BELT
EM-291
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
TIMING BELT
Exploded ViewINFOID:0000000001381499
Removal and InstallationINFOID:0000000001381500
CAUTION:
Apply new engine oil to parts marked in illustration before installation.
Replace any belt that has been removed.
Never turn the engine in the direction opposite to that of normal operation.
When replacing the timing belt, be sure to replace the timing belt tensioner.
Do not run the engine without the drive belts to avoid damaging the crankshaft pulley.
REMOVAL
1. Remove front wheel RH. Refer to WT-6, "Rotation".
2. Remove fender protector RH. Refer to EXT-22, "
Removal and Installation".
3. Remove engine cover.
4. Remove drive belt. Refer to EM-291, "
Removal and Installation".
5. Support the engine using suitable tool.
6. Remove RH engine torque rod.
7. Remove RH engine mounting support bracket and RH engine mounting insulator.
1. Timing belt inner cover 2. Timing belt 3. Camshaft sprocket
4. Camshaft sprocket stud bolt 5. Timing belt tensioner 6. Timing belt cover
7. Cylinder head suspended bracket 8. Crankshaft pulley 9. Crankshaft sprocket (timing belt)
10. Oil seal 11. Crankshaft cover 12. Gasket
A. 30.0 N·m (3.1 kg-m, 22 ft-lb) and 86 degrees
B. 120.0 N·m (12 kg-m, 89 ft-lb) and 95 degrees
E1BIA0022GB
Page 2939 of 5883
EM-292
< ON-VEHICLE REPAIR >[K9K]
TIMING BELT
8. Remove timing belt cover (upper).
9. Remove cylinder head suspended mounting bracket (1).
10. Remove timing belt cover (lower).
11. Remove the TDC pin plug.
12. Rotate the crankshaft clockwise, until the position (A) of the
camshaft pulley is opposite of the position (B) on the cylinder
head.
E1BIA0040ZZ
E1BIA0041ZZ
E1BIA0042ZZ
MBIB0392E
E1BIA0043ZZ
Page 2940 of 5883
TIMING BELT
EM-293
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
13. Insert TDC set pin [SST: KV113B0110 (Mot.1430)] (A) into the
camshaft sprocket and cylinder head hole.
14. Screw in the TDC set pin [SST: KV113 B0130 (Mot. 1439)].
15. Turn the engine clockwise (timing side) until the crankshaft
touches the TDC set pin.
16. The pin [SST: KV113B0110 (Mot.1430)] (A) must engage in the
camshaft pulley and cylinder head holes.
17. Remove crankshaft position sensor. Refer to EM-284,
"Exploded View".
18. Remove crankshaft pulley (1).
CAUTION:
Do not remove bolt. Keep loosened bolt in place to protect
removed crankshaft pulley from dropping.
NOTE:
Insert flat-bladed screwdriver into position of crankshaft position
sensor to hold crankshaft from moving and loosen crankshaft
pulley bolt.
E1BIA0044ZZ
MBIB0394E
MBIB0395E
E1BIA0044ZZ
E1BIA0045ZZ
Page 2941 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-294
< ON-VEHICLE REPAIR >[K9K]
TIMING BELT
19. Slacken the timing belt by loosening the bolt of tensioner (1),
then remove timing belt.
INSTALLATION
CAUTION:
It is essential to remove any dirt or g NISSAN TIIDA 2007 Service Repair Manual EM-294
< ON-VEHICLE REPAIR >[K9K]
TIMING BELT
19. Slacken the timing belt by loosening the bolt of tensioner (1),
then remove timing belt.
INSTALLATION
CAUTION:
It is essential to remove any dirt or g](/manual-img/5/57395/w960_57395-2940.png)
EM-294
< ON-VEHICLE REPAIR >[K9K]
TIMING BELT
19. Slacken the timing belt by loosening the bolt of tensioner (1),
then remove timing belt.
INSTALLATION
CAUTION:
It is essential to remove any dirt or grease from the end of the crankshaft, the bore of the crankshaft
sprocket and the bearing faces of the drive belt pulley to prevent any movement between the timing
sprockets and the crankshaft which would risk damaging the engine.
1. Install timing belt tensioner.
NOTE:
Put the timing belt tensioner tab (1) in the cylinder head groove.
2. Insert TDC set pin [SST: KV113B0110 (Mot. 1430)] (A) in the
camshaft pulley and cylinder head holes.
3. Check that high pressure supply pump sprocket mark (2) has
shifted one tooth to the right of vertical axle as shown.
4. Turn crankshaft to set TDC set pin [SST: KV113B0130 (Mot.
1489)] (the crankshaft groove (1) must be facing upwards).
5. Insert and tighten crankshaft pulley bolt with a spacer (1) (which
does not cover the timing sprocket mark).
E1BIA0046ZZ
E1BIA0060ZZ
E1BIA0061ZZ
E1BIA0059ZZ
Page 2942 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TIMING BELT
EM-295
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
6. Insert TDC set pin [SST: KV113B0130 (Mot.1489)] to crankshaft.
7. Remove one wheel bolt from camshaft sprocket, and the NISSAN TIIDA 2007 Service Repair Manual TIMING BELT
EM-295
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
6. Insert TDC set pin [SST: KV113B0130 (Mot.1489)] to crankshaft.
7. Remove one wheel bolt from camshaft sprocket, and the](/manual-img/5/57395/w960_57395-2941.png)
TIMING BELT
EM-295
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
6. Insert TDC set pin [SST: KV113B0130 (Mot.1489)] to crankshaft.
7. Remove one wheel bolt from camshaft sprocket, and then
loosen the other two bolts (1).
8. Install the timing belt, aligning the marks on the bolt with those
on the camshaft and high pressure supply pump sprockets (19
teeth spaces on the belt between the marks on the camshaft
and pump sprockets).
9. Using a 6 mm (0.24 in) Allen key, move the movable index (F) of
the timing belt tensioner into the position as shown, by turning
the key counterclockwise.
10. Tighten timing belt tensioner bolt.
11. Check that the camshaft sprocket bolts are not fully up against
the camshaft sprocket wheel.
12. Install and tighten camshaft sprocket wheel bolts.
13. Remove TDC set pin [SST: KV113B0130 (Mot. 1489)] and TDC set pin [SST: KV113B0110 (Mot. 1430)].
14. Turn the crankshaft two revolutions in a clockwise direction (tim-
ing side). Just before the hole (A) of the camshaft pulley is oppo-
site the cylinder head hole (B), insert TDC set pin [SST:
KV113B0130 (Mot. 1489)] into the cylinder block.
15. Then turn the crankshaft slowly and smoothly against TDC set
pin.
MBIB0395E
E1BIA0062ZZ
: 27.0 N·m (2.8 kg-m, 20 ft-lb)
: 14.0 N·m (1.4 kg-m, 10 ft-lb)
MBIB0509E
E1BIA0043ZZ
Page 2943 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-296
< ON-VEHICLE REPAIR >[K9K]
TIMING BELT
16. Insert TDC set pin [SST: KV113B0110 (Mot. 1430)] (A).
If the pin cannot be inserted, perform the following.
a. Remove TDC set pin [SST: KV113B0130 (Mo NISSAN TIIDA 2007 Service Repair Manual EM-296
< ON-VEHICLE REPAIR >[K9K]
TIMING BELT
16. Insert TDC set pin [SST: KV113B0110 (Mot. 1430)] (A).
If the pin cannot be inserted, perform the following.
a. Remove TDC set pin [SST: KV113B0130 (Mo](/manual-img/5/57395/w960_57395-2942.png)
EM-296
< ON-VEHICLE REPAIR >[K9K]
TIMING BELT
16. Insert TDC set pin [SST: KV113B0110 (Mot. 1430)] (A).
If the pin cannot be inserted, perform the following.
a. Remove TDC set pin [SST: KV113B0130 (Mot. 1489)].
b. Loosen camshaft sprocket wheel bolts.
c. Turn camshaft pulley to adjust.
d. Confirm that the crankshaft sprocket groove is facing upward.
e. Loosen timing belt tensioner bolt.
f. Move the movable index of the drive belt tensioner into the posi-
tion as shown, by turning the key clockwise.
g. Tighten timing belt tensioner bolt.
h. Install and tighten camshaft sprocket wheel bolts.
i. Turn the crankshaft two revolutions in a clockwise direction (tim-
ing side). Just before the hole (A) of the camshaft pulley is opposite the cylinder head hole (B), insert TDC
set pin [SST: KV113B0130 (Mot. 1489)] into the cylinder block.
j. Then turn the crankshaft slowly and smoothly against TDC set pin.
17. Install crankshaft pulley and tighten the bolt (1).
18. Turn bolt 95 degrees clockwise.
CAUTION:
Check and confirm the tightening angle by using the angle
wrench [SST: KV10112100 ( — )] or protractor. Avoid judg-
ment by visual inspection without the tool.
19. Remove TDC set pin [SST: KV113B0130 (Mot. 1489)] and TDC
set pin [SST: KV113B0110 (Mot. 1430)].
20. Apply liquid gasket to the thread of TDC pin plug.
21. Install TDC pin plug.
22. Install the cylinder head suspended bracket (1).
E1BIA0044ZZ
: 27.0 N·m (2.8 kg-m, 20 ft-lb)
: 14.0 N·m (1.4 kg-m, 10 ft-lb)
MBIB0511E
: 120 N·m (12 kg-m, 89 ft-lb)
: 20 N·m (2.0 kg-m, 15 ft-lb)
: 21 N·m (2.1 kg-m, 15 ft-lb)
E1BIA0045ZZ
E1BIA0042ZZ
Page 2944 of 5883
TIMING BELT
EM-297
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
23. Install the timing cover by positioning the tab (M) into the hole
(N) on the inner timing cover.
24. Installation is in the reverse order of removal.
MBIB0514E
