Page 385 of 5883
![NISSAN TIIDA 2007 Service Repair Manual BRC-152
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C1179 ABS DELTA S SEN NG
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness or connector.
3.DELTA STROKE SENSOR INSPECTION
1. NISSAN TIIDA 2007 Service Repair Manual BRC-152
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C1179 ABS DELTA S SEN NG
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness or connector.
3.DELTA STROKE SENSOR INSPECTION
1.](/manual-img/5/57395/w960_57395-384.png)
BRC-152
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C1179 ABS DELTA S SEN NG
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness or connector.
3.DELTA STROKE SENSOR INSPECTION
1. Reconnect the delta stroke sensor and ABS actuator and electric unit (control unit) connectors.
2. Use “DATA MONITOR” to check if the status of “DELTA S SEN” is normal.
Is the inspection result normal?
YES >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-184, "Removal and Instal-
lation".
NO >> Replace the delta stroke sensor.
Component InspectionINFOID:0000000001731174
1.CHECK DATA MONITOR
Use “DATA MONITOR” to check if the status of “DELTA S SEN” is normal.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to diagnosis procedure. Refer to BRC-151, "
Diagnosis Procedure".
Special Repair RequirementINFOID:0000000001731175
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the steering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-90, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replacing the ABS actuator and electric unit (control unit).
Refer to BRC-91, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
ABS actuator and electric unit (control
unit)
—Continuity
Connector Terminal
A: E12526
Ground No 39
40
ConditionDELTA S SEN
(DATA MONITOR)
When brake pedal is depressed. 1.05–1.80 mm
When brake pedal is released. 0.00 mm (+0.6/-0.4)
ConditionDELTA S SEN
(DATA MONITOR)
When brake pedal is depressed. 1.05–1.80 mm
When brake pedal is released. 0.00 mm (+0.6/-0.4)
Page 386 of 5883
![NISSAN TIIDA 2007 Service Repair Manual U1000 CAN COMM CIRCUIT
BRC-153
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000001731176
CAN (Controller Area Network) is a serial NISSAN TIIDA 2007 Service Repair Manual U1000 CAN COMM CIRCUIT
BRC-153
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000001731176
CAN (Controller Area Network) is a serial](/manual-img/5/57395/w960_57395-385.png)
U1000 CAN COMM CIRCUIT
BRC-153
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000001731176
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
DTC LogicINFOID:0000000001731177
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000001731178
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn ignition switch OFF, disconnect the ABS actuator and electric unit (control unit) connector, and check
the terminals for deformation, disconnection, looseness, and so on. If there is a malfunction, repair or
replace the terminal.
2. Reconnect connector and perform self-diagnosis.
Is
“CAN COMM CIRCUIT” displayed in self-diagnosis display items?
YES >> Print out the self-diagnostic results, and refer to BRC-86, "Work Flow".
NO >> Connector terminal is loose, damaged, open, or shorted.
Special Repair RequirementINFOID:0000000001731179
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the steering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-90, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replacing the ABS actuator and electric unit (control unit).
Refer to BRC-91, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
DTC Display item Malfunction detected condition Possible cause
U1000 CAN COMM CIRCUITWhen ABS actuator and electric unit (control unit) is not
transmitting or receiving CAN communication signal for 2
seconds or more. CAN communication line
ABS actuator and electric unit
(control unit)
Page 387 of 5883
![NISSAN TIIDA 2007 Service Repair Manual BRC-154
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
VDC OFF SWITCH
VDC OFF SWITCH
DescriptionINFOID:0000000001731180
VDC OFF switch can deactivate (turn OFF) the VDC/TCS function by pressing the VDC OFF swit NISSAN TIIDA 2007 Service Repair Manual BRC-154
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
VDC OFF SWITCH
VDC OFF SWITCH
DescriptionINFOID:0000000001731180
VDC OFF switch can deactivate (turn OFF) the VDC/TCS function by pressing the VDC OFF swit](/manual-img/5/57395/w960_57395-386.png)
BRC-154
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
VDC OFF SWITCH
VDC OFF SWITCH
DescriptionINFOID:0000000001731180
VDC OFF switch can deactivate (turn OFF) the VDC/TCS function by pressing the VDC OFF switch.
Component Function CheckINFOID:0000000001731181
1.CHECK VDC OFF SWITCH OPERATION
Turn ON/OFF the VDC OFF switch and check that the VDC OFF indicator lamp in the combination meter turns
ON/OFF correctly.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to diagnosis procedure. Refer to BRC-154, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001731182
1.CHECK VDC OFF SWITCH
1. Turn ignition switch OFF.
2. Disconnect VDC OFF switch connector.
3. Check continuity between VDC OFF switch terminals.
Is the inspection result normal?
YES >> GO TO 2
NO >> Replace VDC OFF switch.
2.CHECK VDC OFF SWITCH HARNESS
1. Disconnect ABS actuator and electric unit (control unit) connec-
tor.
2. Check continuity between ABS actuator and electric unit (control
unit) connector E125 (A) and VDC OFF switch connector M257
(B).
3. Check continuity between ABS actuator and electric unit (control
unit) connector E125 (A) and ground.
Is the inspection result normal?
YES >> GO TO 3
Condition VDC OFF indicator lamp illumination status
VDC OFF switch: ON ON
VDC OFF switch: OFF OFF
VDC OFF switch
Condition Continuity
Te r m i n a l
1 − 2When VDC OFF switch is pressed. Yes
When VDC OFF switch is released. No
PFIA0307E
ABS actuator and electric unit
(control unit)VDC OFF switch
Continuity
Connector Terminal Connector Terminal
A: E125 38 B: M257 1 Yes
ABS actuator and electric unit (control unit)
— Continuity
Connector Terminal
A: E125 38 Ground No
AWFIA0030ZZ
Page 388 of 5883
![NISSAN TIIDA 2007 Service Repair Manual VDC OFF SWITCH
BRC-155
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
NO >> Repair or replace harness.
3.CHECK VDC OFF SWITCH GROUND
Check continuity between VDC OFF switch conn NISSAN TIIDA 2007 Service Repair Manual VDC OFF SWITCH
BRC-155
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
NO >> Repair or replace harness.
3.CHECK VDC OFF SWITCH GROUND
Check continuity between VDC OFF switch conn](/manual-img/5/57395/w960_57395-387.png)
VDC OFF SWITCH
BRC-155
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
NO >> Repair or replace harness.
3.CHECK VDC OFF SWITCH GROUND
Check continuity between VDC OFF switch connector M257 and
ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace harness.
4.CHECK COMBINATION METER
Check if the indication and operation of combination meter are normal. Refer to MWI-21, "
Diagnosis Descrip-
tion".
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-184, "Removal and Installa-
tion".
NO >> Replace combination meter. Refer to MWI-94, "
Removal and Installation".
Component InspectionINFOID:0000000001731183
INSPECTION PROCEDURE
1.CHECK VDC OFF SWITCH
1. Turn ignition switch OFF.
2. Disconnect VDC OFF switch connector.
3. Check continuity between VDC OFF switch terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace VDC OFF switch.
VDC OFF switch
—Continuity
Connector Terminal
M257 2 Ground Yes
AWFIA0031ZZ
VDC OFF switch
Condition Continuity
Te r m i n a l
1 − 2When VDC OFF switch is pressed. Yes
When VDC OFF switch is released. No
PFIA0307E
Page 389 of 5883
![NISSAN TIIDA 2007 Service Repair Manual BRC-156
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
ABS WARNING LAMP
ABS WARNING LAMP
DescriptionINFOID:0000000001731184
×: ON –: OFF
Component Function CheckINFOID:0000000001731185
1.CHECK ABS WARNING LA NISSAN TIIDA 2007 Service Repair Manual BRC-156
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
ABS WARNING LAMP
ABS WARNING LAMP
DescriptionINFOID:0000000001731184
×: ON –: OFF
Component Function CheckINFOID:0000000001731185
1.CHECK ABS WARNING LA](/manual-img/5/57395/w960_57395-388.png)
BRC-156
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
ABS WARNING LAMP
ABS WARNING LAMP
DescriptionINFOID:0000000001731184
×: ON –: OFF
Component Function CheckINFOID:0000000001731185
1.CHECK ABS WARNING LAMP OPERATION
Check that the lamp illuminates for approximately 1 second after the ignition switch is turned ON.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to diagnosis procedure. Refer to BRC-60, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001731186
1.CHECK SELF-DIAGNOSIS
Perform ABS actuator and electric unit (control unit) self-diagnosis. Refer to BRC-25, "
CONSULT-III Function
(ABS)".
Is the inspection result normal?
YES >> GO TO 2
NO >> Check items displayed by self-diagnosis.
2.CHECK COMBINATION METER
Check if the indication and operation of combination meter are normal. Refer to MWI-21, "
Diagnosis Descrip-
tion".
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-184, "Removal and Installa-
tion".
NO >> Replace combination meter. Refer to MWI-94, "
Removal and Installation".
Condition ABS warning lamp
Ignition switch OFF–
For 1 second after turning ON ignition switch×
1 second later after turning ON ignition switch –
ABS function is malfunctioning.×
EBD function is malfunctioning.×
Page 390 of 5883
![NISSAN TIIDA 2007 Service Repair Manual BRAKE WARNING LAMP
BRC-157
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
BRAKE WARNING LAMP
DescriptionINFOID:0000000001731187
×: ON –: OFF
NOTE:
1: Brake warning lamp wil NISSAN TIIDA 2007 Service Repair Manual BRAKE WARNING LAMP
BRC-157
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
BRAKE WARNING LAMP
DescriptionINFOID:0000000001731187
×: ON –: OFF
NOTE:
1: Brake warning lamp wil](/manual-img/5/57395/w960_57395-389.png)
BRAKE WARNING LAMP
BRC-157
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
BRAKE WARNING LAMP
DescriptionINFOID:0000000001731187
×: ON –: OFF
NOTE:
1: Brake warning lamp will turn on in case of parking brake operation (when switch is ON) or of brake fluid level switch operation
(when brake fluid is insufficient).
2: After starting engine, brake warning lamp is turned off.
Component Function CheckINFOID:0000000001731188
1.BRAKE WARNING LAMP OPERATION CHECK
Check that the lamp illuminates for approximately 1 second after the ignition switch is turned ON.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to diagnosis procedure. Refer to BRC-61, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001731189
1.CHECK SELF-DIAGNOSIS
Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is the inspection result normal?
YES >> GO TO 2
NO >> Check items displayed by self-diagnosis.
2.CHECK COMBINATION METER
Check if the indication and operation of combination meter are normal. Refer to MWI-21, "
Diagnosis Descrip-
tion".
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-184, "Removal and Installa-
tion".
NO >> Replace combination meter. Refer to MWI-94, "
Removal and Installation".
Condition Brake warning lamp (Note 1)
Ignition switch OFF–
For 1 second after turning ON ignition switch× (Note 2)
1 second later after turning ON ignition switch× (Note 2)
EBD function is malfunctioning.×
Page 391 of 5883
![NISSAN TIIDA 2007 Service Repair Manual BRC-158
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
VDC OFF INDICATOR LAMP
VDC OFF INDICATOR LAMP
DescriptionINFOID:0000000001731190
×: ON –: OFF
Component Function CheckINFOID:0000000001731191
1.VDC OFF NISSAN TIIDA 2007 Service Repair Manual BRC-158
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
VDC OFF INDICATOR LAMP
VDC OFF INDICATOR LAMP
DescriptionINFOID:0000000001731190
×: ON –: OFF
Component Function CheckINFOID:0000000001731191
1.VDC OFF](/manual-img/5/57395/w960_57395-390.png)
BRC-158
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
VDC OFF INDICATOR LAMP
VDC OFF INDICATOR LAMP
DescriptionINFOID:0000000001731190
×: ON –: OFF
Component Function CheckINFOID:0000000001731191
1.VDC OFF INDICATOR LAMP OPERATION CHECK 1
Check that the lamp illuminates for approximately 1 second after the ignition switch is turned ON.
Is the inspection result normal?
YES >> GO TO 2
NO >> Go to diagnosis procedure. Refer to BRC-158, "
Diagnosis Procedure".
2.VDC OFF INDICATOR LAMP OPERATION CHECK 2
Check that the VDC OFF indicator lamp in the combination meter turns ON/OFF correctly when operating the
VDC OFF switch.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Check VDC OFF switch. Refer to BRC-154, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001731192
1.CHECK VDC OFF SWITCH
Check that the VDC OFF indicator lamp in the combination meter turns ON/OFF correctly when operating the
VDC OFF switch.
Is the inspection result normal?
YES >> GO TO 2
NO >> Check VDC OFF switch. Refer to BRC-154, "
Diagnosis Procedure".
2.CHECK SELF-DIAGNOSIS
Perform ABS actuator and electric unit (control unit) self-diagnosis. Refer to BRC-25, "
CONSULT-III Function
(ABS)".
Is the inspection result normal?
YES >> GO TO 3
NO >> Check items displayed by self-diagnosis.
3.CHECK COMBINATION METER
Check if the indication and operation of combination meter are normal. Refer to MWI-21, "
Diagnosis Descrip-
tion".
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-184, "Removal and Installa-
tion".
NO >> Replace combination meter. Refer to MWI-94, "
Removal and Installation".
Condition VDC OFF indicator lamp
Ignition switch OFF–
For 1 second after turning ON ignition switch×
1 second later after turning ON ignition switch –
VDC OFF switch turned ON. (VDC function is OFF.)×
VDC/TCS function is malfunctioning.×
ABS function is malfunctioning.×
EBD function is malfunctioning.×
Page 392 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SLIP INDICATOR LAMP
BRC-159
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
SLIP INDICATOR LAMP
DescriptionINFOID:0000000001731193
×: ON –: OFF
Component Function CheckINFOID: NISSAN TIIDA 2007 Service Repair Manual SLIP INDICATOR LAMP
BRC-159
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
SLIP INDICATOR LAMP
DescriptionINFOID:0000000001731193
×: ON –: OFF
Component Function CheckINFOID:](/manual-img/5/57395/w960_57395-391.png)
SLIP INDICATOR LAMP
BRC-159
< COMPONENT DIAGNOSIS >[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
SLIP INDICATOR LAMP
DescriptionINFOID:0000000001731193
×: ON –: OFF
Component Function CheckINFOID:0000000001731194
1.CHECK SLIP INDICATOR LAMP OPERATION
Check that the lamp illuminates for approximately 1 second after the ignition switch is turned ON.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to diagnosis procedure. Refer to BRC-159, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001731195
1.CHECK SELF-DIAGNOSIS
Perform ABS actuator and electric unit (control unit) self-diagnosis. Refer to BRC-25, "
CONSULT-III Function
(ABS)".
Is the inspection result normal?
YES >> GO TO 2
NO >> Check items displayed by self-diagnosis.
2.CHECK COMBINATION METER
Check if the indication and operation of combination meter are normal. Refer to MWI-21, "
Diagnosis Descrip-
tion".
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-184, "Removal and Installa-
tion".
NO >> Replace combination meter. Refer to MWI-94, "
Removal and Installation".
Condition SLIP indicator lamp
Ignition switch OFF–
For 1 second after turning ON ignition switch×
1 second later after turning ON ignition switch –
VDC/TCS function is malfunctioning.×
ABS function is malfunctioning.×
EBD function is malfunctioning.×
