DLK-676
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
DOOR LOCK ACTUATOR
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK BACK DOOR LOCK ACTUATOR HARNESS
1. Disconnect BCM and back door lock assembly.
2. Check continuity between BCM connector (A) M20 terminal 68
and back door lock assembly connector (B) D405 terminal 1.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BACK DOOR LOCK ACTUATOR GROUND CIRCUIT
Check continuity between back door lock assembly connector D405
terminal 2 and ground.
Is the inspection result normal?
YES >> Replace back door lock assembly.
NO >> Repair or replace harness.
4.CHECK DOOR LOCK ACTUATOR HARNESS
1. Disconnect BCM and back door lock actuator.
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M20 68 Ground Door lock opener switch is pressed 0 → Battery voltage → 0
ALKIA0780ZZ
BCM connector TerminalBack door lock assembly
connectorTerminal Continuity
M20 68 D405 1 Yes
Terminals Continuity
2 Ground Yes
ALKIA0781ZZ
Page 1266 of 5883
DOOR LOCK ACTUATOR
DLK-677
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between BCM connector M20 terminals 68 and
ground.
Is the inspection result normal?
YES >> Harness is OK. Refer to DLK-677, "BACK DOOR : Component Inspection".
NO >> Repair or replace harness.
BACK DOOR : Component InspectionINFOID:0000000001530812
1.CHECK TRUNK LAMP SWITCH
Momentarilly, connect battery power supply to back door lock
assembly terminals and check for actuator operation.
Is the inspection result normal?
YES >> Replace BCM. Refer to XX-XX, "*****".
NO >> Replace back door lock assembly.
Terminals Continuity
68 Ground No
ALKIA0782ZZ
ALKIA0779ZZ
Te r m i n a l
Back door condition
Back door lock assembly (actuator)
1 BAT (+) 2 BAT (-) Actuator operates
Page 1267 of 5883
![NISSAN TIIDA 2007 Service Repair Manual DLK-678
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
SUPER LOCK ACTUATOR
SUPER LOCK ACTUATOR
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000001530817
The super lock system is controlled NISSAN TIIDA 2007 Service Repair Manual DLK-678
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
SUPER LOCK ACTUATOR
SUPER LOCK ACTUATOR
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000001530817
The super lock system is controlled](/manual-img/5/57395/w960_57395-1266.png)
DLK-678
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
SUPER LOCK ACTUATOR
SUPER LOCK ACTUATOR
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000001530817
The super lock system is controlled by the BCM.
DRIVER SIDE : Component Function CheckINFOID:0000000001530818
1.CHECK FUNCTION
1. Use CONSULT-III to perform Active Test "SUPER LOCK".
2. Touch “LOCK” or “UNLOCK” to check that it works normally.
Is the inspection result normal?
YES >> Front super lock actuator (driver side) is OK.
NO >> Refer to DLK-678, "
DRIVER SIDE : Diagnosis Procedure".
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000001530819
1.CHECK DOOR LOCK ACTUATOR SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between BCM connector M20 terminals 75, 76
and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK SUPER LOCK ACTUATOR HARNESS
1. Disconnect BCM and front door lock actuator (driver side).
ALKIA0822ZZ
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M2075
GroundDriver door lock/unlock switch is
turned to LOCK0 → Battery voltage→ 0
76Driver door lock/unlock switch is
turned to UNLOCK0 → Battery voltage → 0
Page 1268 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SUPER LOCK ACTUATOR
DLK-679
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between BCM connector (A) M20 terminals 75,
76 and front door l NISSAN TIIDA 2007 Service Repair Manual SUPER LOCK ACTUATOR
DLK-679
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between BCM connector (A) M20 terminals 75,
76 and front door l](/manual-img/5/57395/w960_57395-1267.png)
SUPER LOCK ACTUATOR
DLK-679
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between BCM connector (A) M20 terminals 75,
76 and front door lock actuator (driver side) connector (B) D14
terminals 1, 2.
Is the inspection result normal?
YES >> Replace super lock actuator (driver side).
NO >> Repair or replace harness.
3.CHECK SUPER LOCK ACTUATOR HARNESS
1. Disconnect BCM and front door lock actuator (driver side).
2. Check continuity between BCM connector M20 terminals 75, 76
and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to XX-XX, "*****".
NO >> Repair or replace harness.
PASSENGER SIDE
PASSENGER SIDE : DescriptionINFOID:0000000001530820
The super lock system is controlled by the BCM.
PASSENGER SIDE : Component Function CheckINFOID:0000000001530821
1.CHECK FUNCTION
1. Use CONSULT-III to perform Active Test DOOR LOCK.
2. Touch “LOCK” or “UNLOCK” to check that it works normally.
Is the inspection result normal?
YES >> Front super lock actuator (passenger side) is OK.
NO >> Refer to DLK-679, "
PASSENGER SIDE : Diagnosis Procedure".
PASSENGER SIDE : Diagnosis ProcedureINFOID:0000000001530822
1.CHECK FRONT DOOR LOCK ACTUATOR (PASSENGER SIDE) SIGNAL
1. Turn ignition switch OFF.
Connector Terminals Connector Terminals Continuity
M2075
D141Yes
76 2 Yes
ALKIA0823ZZ
Connector Terminals Continuity
M2075
GroundNo
76 No
ALKIA0824ZZ
Page 1269 of 5883
![NISSAN TIIDA 2007 Service Repair Manual DLK-680
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
SUPER LOCK ACTUATOR
2. Check voltage between BCM connector M20 terminals 67, 75
and ground.
Is the inspection result normal?
YES >> GO T NISSAN TIIDA 2007 Service Repair Manual DLK-680
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
SUPER LOCK ACTUATOR
2. Check voltage between BCM connector M20 terminals 67, 75
and ground.
Is the inspection result normal?
YES >> GO T](/manual-img/5/57395/w960_57395-1268.png)
DLK-680
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
SUPER LOCK ACTUATOR
2. Check voltage between BCM connector M20 terminals 67, 75
and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK SUPER LOCK ACTUATOR HARNESS
1. Disconnect BCM and front door lock actuator (passenger side).
2. Check continuity between BCM connector (A) M20 terminals 67,
75 and front door lock actuator (passenger side) (B) D114 termi-
nals 1, 2.
Is the inspection result normal?
YES >> Replace super lock actuator (passenger side). Refer to XX-XX, "*****".
NO >> Repair or replace harness.
3.CHECK SUPER LOCK ACTUATOR HARNESS
1. Disconnect BCM and front door lock actuator (passenger side).
ALKIA0825ZZ
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M2075
GroundDoor lock/unlock switch is turned to LOCK 0 → Battery voltage → 0
67 Door lock/unlock switch is turned to UNLOCK 0 → Battery voltage → 0
ALKIA0826ZZ
BCM connector TerminalFront door lock actuator
(passenger side) connectorTerminal Continuity
M2067
D1142
Ye s
75 1
Page 1270 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SUPER LOCK ACTUATOR
DLK-681
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between BCM connector M19 terminals 67, 75
and ground.
Is the i NISSAN TIIDA 2007 Service Repair Manual SUPER LOCK ACTUATOR
DLK-681
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between BCM connector M19 terminals 67, 75
and ground.
Is the i](/manual-img/5/57395/w960_57395-1269.png)
SUPER LOCK ACTUATOR
DLK-681
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between BCM connector M19 terminals 67, 75
and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to XX-XX, "*****".
NO >> Repair or replace harness.
REAR LH
REAR LH : DescriptionINFOID:0000000001530823
Locks/unlocks the door with the signal from BCM.
REAR LH : Component Function CheckINFOID:0000000001530824
1.CHECK FUNCTION
1. Use CONSULT-III to perform Active Test "DOOR LOCK".
2. Touch “LOCK” or “UNLOCK” to check that it works normally.
Is the inspection result normal?
YES >> Rear super lock actuator LH is OK.
NO >> Refer to DLK-681, "
REAR LH : Diagnosis Procedure".
REAR LH : Diagnosis ProcedureINFOID:0000000001530825
1.CHECK DOOR LOCK ACTUATOR SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between BCM connector M20 terminals 67, 75
and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
BCM connector Terminals Continuity
M2067
Ground No
75
ALKIA0827ZZ
ALKIA0825ZZ
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M2075
GroundDoor lock/unlock switch is turned to LOCK 0 → Battery voltage → 0
67 Door lock/unlock switch is turned to UNLOCK 0 → Battery voltage → 0
Page 1271 of 5883
![NISSAN TIIDA 2007 Service Repair Manual DLK-682
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
SUPER LOCK ACTUATOR
2.CHECK SUPER LOCK ACTUATOR HARNESS
1. Disconnect BCM and rear door lock actuator LH.
2. Check continuity between BC NISSAN TIIDA 2007 Service Repair Manual DLK-682
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
SUPER LOCK ACTUATOR
2.CHECK SUPER LOCK ACTUATOR HARNESS
1. Disconnect BCM and rear door lock actuator LH.
2. Check continuity between BC](/manual-img/5/57395/w960_57395-1270.png)
DLK-682
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
SUPER LOCK ACTUATOR
2.CHECK SUPER LOCK ACTUATOR HARNESS
1. Disconnect BCM and rear door lock actuator LH.
2. Check continuity between BCM connector (A) M20 terminals 67,
75 and rear door lock actuator LH connector (B) D205 terminals
1, 2.
Is the inspection result normal?
YES >> Replace rear super lock actuator LH.
NO >> Repair or replace harness.
3.CHECK SUPER LOCK ACTUATOR HARNESS
1. Disconnect BCM and each door lock actuator.
2. Check continuity between BCM connector M20 terminals 67, 75
and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to XX-XX, "*****".
NO >> Repair or replace harness.
REAR RH
REAR RH : DescriptionINFOID:0000000001530826
Locks/unlocks the door with the signal from BCM.
REAR RH : Component Function CheckINFOID:0000000001530827
1.CHECK FUNCTION
1. Use CONSULT-III to perform Active Test "DOOR LOCK".
2. Touch “LOCK” or “UNLOCK” to check that it works normally.
Is the inspection result normal?
YES >> Rear super lock actuator RH is OK.
NO >> Refer to XX-XX, "*****"
.
ALKIA0828ZZ
BCM connector TerminalRear door lock actuator LH
connectorTerminal Continuity
M2067
D2052
Ye s
75 1
BCM connector Terminals Continuity
M2067
Ground No
75
ALKIA0827ZZ
Page 1272 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SUPER LOCK ACTUATOR
DLK-683
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
REAR RH : Diagnosis ProcedureINFOID:0000000001530828
1.CHECK DOOR LOCK ACTUATOR SIG NISSAN TIIDA 2007 Service Repair Manual SUPER LOCK ACTUATOR
DLK-683
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
REAR RH : Diagnosis ProcedureINFOID:0000000001530828
1.CHECK DOOR LOCK ACTUATOR SIG](/manual-img/5/57395/w960_57395-1271.png)
SUPER LOCK ACTUATOR
DLK-683
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
REAR RH : Diagnosis ProcedureINFOID:0000000001530828
1.CHECK DOOR LOCK ACTUATOR SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between BCM connector M20 terminals 67, 75
and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK SUPER LOCK ACTUATOR HARNESS
1. Disconnect BCM and rear door lock actuator RH.
2. Check continuity between BCM connector (A) M20 terminals 67,
75 and rear door lock actuator RH connector (B) D305 terminals
2, 1.
Is the inspection result normal?
YES >> Replace rear super lock actuator RH.
NO >> Repair or replace harness.
3.CHECK SUPER LOCK ACTUATOR HARNESS
1. Disconnect BCM and rear door lock actuator RH.
ALKIA0825ZZ
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M2075
GroundDoor lock/unlock switch is turned to LOCK 0 → Battery voltage → 0
67 Door lock/unlock switch is turned to UNLOCK 0 → Battery voltage → 0
ALKIA0826ZZ
BCM connector TerminalRear door lock actuator RH
connectorTerminal Continuity
M2067
D3052
Ye s
75 1
