Page 889 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-300 < COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK] DOOR SWITCH REAR LH : Description INFOID:0000000001530283 Detects door open/closed condition. REAR LH : Component Function CheckINFOID:00000000

Page 890 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR SWITCH DLK-301 < COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK] C D E F G H I J L MA B DLK N O P 2. Check continuity between BCM connector (A) M19 terminal 59 and rear door switch LH connector (B

Page 891 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-302 < COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK] DOOR SWITCH REAR RH : Description INFOID:0000000001530287 Detects door open/close condition. REAR RH : Component Function CheckINFOID:000000000

Page 892 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR SWITCH DLK-303 < COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK] C D E F G H I J L MA B DLK N O P 2. Check continuity between BCM connector (A) M19 terminal 60 and rear door switch RH connector (B

Page 893 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-304 < COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK] DOOR SWITCH BACK DOOR : Description INFOID:0000000001530291 Detects back door open condition. BACK DOOR : Component Function CheckINFOID:000000

Page 894 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR SWITCH DLK-305 < COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK] C D E F G H I J L MA B DLK N O P 2. Check continuity between BCM connector (A) M18 terminal 10 and back door lock assembly (door sw

Page 895 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-306 < COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK] DOOR SWITCH 2. Check voltage between BCM connector and ground. Is the inspection result normal? YES >> GO TO 5. NO >> GO TO 6. 5.CHECK BACK DOO

Page 896 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR SWITCH DLK-307 < COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK] C D E F G H I J L MA B DLK N O P YES >> Back door lock assembly (door switch) is OK. NO >> Replace back door lock assembly (door sw
