REAR PARCEL SHELF FINISHER
REAR PARCEL SHELF FINISHER
Removal and InstallationINFOID:0000000001329053
REMOVAL
1. Remove rear seat. Refer to SE-18, "Removal and Installation".
2. Remove rear pillar finisher. Refer to INT-20, "
Removal and Installation".
3. Remove high mounted stop lamp and disconnect connector.
4. Remove rear parcel shelf finisher.
INSTALLATION
Installation is in the reverse order of removal.
LIIA2923E
1. Rear seat belt shoulder anchor cover 2. Child anchor cover 3. Child anchor cover base
4. High mounted stop lamp 5. Rear parcel shelf finisher⇐Vehicle front
Page 3706 of 5883
FLOOR TRIM
INT-27
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
INT
N
O
P
FLOOR TRIM
Removal and InstallationINFOID:0000000001329054
LHD Shown, RHD Similar
REMOVAL
1. Disconnect both the negative and positive battery cables, then wait at least 3 minutes.
2. Remove front seat assembly RH/LH and rear seat cushion. Refer to SE-14, "
Removal and Installation"
and SE-18, "Removal and Installation".
3. Remove center console and floor bracket. Refer to IP-11, "
Removal and Installation".
4. Remove instrument lower cover. Refer to IP-11, "
Removal and Installation".
5. Remove front kicking plate inner RH/LH, center pillar lower garnish RH/LH, and rear kicking plate inner
RH/LH. Refer to INT-20, "
Removal and Installation".
LIIA2575E
1. Clip C101 2. Steering column shaft cover 3. Floor carpet hook
4. Front floor spacer 5. Rear floor spacer 6. Floor trim
Metal clip Clip CF110⇐Vehicle front
Page 3707 of 5883
INT-28
< ON-VEHICLE REPAIR >
FLOOR TRIM
6. Disconnect floor harness connector.
7. Remove diagnosis sensor unit. Refer to SR-15, "
Removal and
Installation".
8. Remove key interlock cable. Refer to TM-206, "
Removal and
Installation".
9. Remove floor carpet hook.
10. Cut floor trim using a blade knife first between openings (1),
