EC-596
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
COOLING FAN
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace cooling fan motor.
Te r m i n a l s
Operation
(+) (–)
14
Cooling fan operates at low speed.
23
1 and 2 3 and 4 Cooling fan operates at high speed.
Page 1946 of 5883
![NISSAN TIIDA 2007 Service Repair Manual ELECTRICAL LOAD SIGNAL
EC-597
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000001693428
The electrical load signal (H NISSAN TIIDA 2007 Service Repair Manual ELECTRICAL LOAD SIGNAL
EC-597
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000001693428
The electrical load signal (H](/manual-img/5/57395/w960_57395-1945.png)
ELECTRICAL LOAD SIGNAL
EC-597
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000001693428
The electrical load signal (Headlamp switch signal, rear window defogger switch signal, etc.) is transferred
through the CAN communication line from BCM to ECM via IPDM E/R.
Component Function CheckINFOID:0000000001693429
1.CHECK REAR WINDOW DEFOGGER SWITCH FUNCTION
1. Turn ignition switch ON.
2. Connect CONSULT-III and select “DATA MONITOR” mode.
3. Select “LOAD SIGNAL” and check indication under the following conditions.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Go to EC-597, "
Diagnosis Procedure".
2.CHECK LIGHTING SWITCH FUNCTION
Check “LOAD SIGNAL” indication under the following conditions.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Go to EC-597, "
Diagnosis Procedure".
3.CHECK HEATER FAN CONTROL SWITCH FUNCTION
Select “HEATER FAN SW” and check indication under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-597, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001693430
1.INSPECTION START
Confirm the malfunctioning circuit (rear window defogger, headlamp or heater fan). Refer to EC-597, "
Compo-
nent Function Check".
Which circuit is related to the incident?
Rear window defogger>>GO TO 2
Headlamp>>GO TO 3.
Heater fan>>GO TO 4.
2.CHECK REAR WINDOW DEFOGGER SYSTEM
Refer to DEF-6, "
System Diagram".
Monitor item Condition Indication
LOAD SIGNAL Rear window defogger switchON ON
OFF OFF
Monitor item Condition Indication
LOAD SIGNAL Lighting switchON at 2nd position ON
OFF OFF
Monitor item Condition Indication
HEATER FAN SW Heater fan control switchON ON
OFF OFF
Page 1947 of 5883
EC-598
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
ELECTRICAL LOAD SIGNAL
>> INSPECTION END
3.CHECK HEADLAMP SYSTEM
Refer to EXL-10, "
System Diagram" (XENON TYPE) or EXL-8, "System Diagram" (HALOGEN TYPE).
>> INSPECTION END
4.CHECK HEATER FAN CONTROL SYSTEM
Refer to HAC-118, "
System Description" (without NAVI system) or HAC-232, "System Description" (with NAVI
system).
>> INSPECTION END
Page 1948 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
EC-599
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
Descriptio NISSAN TIIDA 2007 Service Repair Manual EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
EC-599
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
Descriptio](/manual-img/5/57395/w960_57395-1947.png)
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
EC-599
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
DescriptionINFOID:0000000001697487
The EVAP canister purge volume control solenoid valve uses a ON/
OFF duty to control the flow rate of fuel vapor from the EVAP canis-
ter. The EVAP canister purge volume control solenoid valve is
moved by ON/OFF pulses from the ECM. The longer the ON pulse,
the greater the amount of fuel vapor that will flow through the valve.
Component Function CheckINFOID:0000000001697488
1.CHECK EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE FUNCTION
With CONSULT-III
1. Turn ignition switch OFF.
2. Disconnect the EVAP purge hose from EVAP canister purge volume control solenoid valve (EVAP canis-
ter side).
3. Start engine and let it idle.
4. Select “PURG VOL CONT/V” in “ACTIVE TEST” mode wit CONSULT-III.
5. Touch “Qu” and “Qd” on CONSULT-III screen to adjust “PURG VOL CONT/V” and check vacuum exist-
ence under the following conditions.
Without CONSULT-III
1. Turn ignition switch OFF.
2. Disconnect the EVAP purge hose from EVAP canister purge volume control solenoid valve (EVAP canis-
ter side).
3. Start engine and let it idle for at least 100 seconds.
4. Check vacuum existence under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-599, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001697489
1.CHECK EVAP CANISTER
Refer to EC-683, "
Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace.
2.CHECK EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect EVAP canister purge volume control solenoid valve harness connector.
PBIA9215J
PURG VOL CONT/V Vacuum
100% Existed
0 % Not existed
Condition Vacuum
At idle Not existed
About 2,000 rpm Existed
Page 1949 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-600
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
3. Turn ignition switch ON.
4. Check the voltage between EVAP canister purge volume control NISSAN TIIDA 2007 Service Repair Manual EC-600
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
3. Turn ignition switch ON.
4. Check the voltage between EVAP canister purge volume control](/manual-img/5/57395/w960_57395-1948.png)
EC-600
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
3. Turn ignition switch ON.
4. Check the voltage between EVAP canister purge volume control solenoid valve harness connector and
ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.DETECT MALFUNCTIONING PART
Check the following.
Harness connectors E7, F121
Harness for open or short between EVAP canister purge volume control solenoid valve and IPDM E/R
Harness for open or short between EVAP canister purge volume control solenoid valve and ECM
>> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE OUTPUT SIGNAL CIRCUIT
FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between EVAP canister purge volume control solenoid valve harness connector and
ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES-1 >> With CONSULT-III: GO TO 5.
YES-2 >> Without CONSULT-III: GO TO 6.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE OPERATION
With CONSULT-III
1. Reconnect all harness connectors disconnected.
2. Start engine.
3. Perform “PURG VOL CONT/V” in “ACTIVE TEST” mode with CONSULT-III. Check that engine speed var-
ies according to the valve opening.
Does engine speed vary according to the valve opening?
YES >> GO TO 7.
NO >> GO TO 6.
6.CHECK EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
Refer to EC-601, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace EVAP canister purge volume control solenoid valve.
7.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
EVAP canister purge volume control solenoid valve
Ground Voltage
Connector Terminal
F32 1 Ground Battery voltage
EVAP canister purge volume control solenoid valve ECM
Continuity
Connector Terminal Connector Terminal
F32 2 F7 9 Existed
Page 1950 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
EC-601
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Component InspectionINFOID:0000000001697490
1.CHECK EVAP CAN NISSAN TIIDA 2007 Service Repair Manual EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
EC-601
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Component InspectionINFOID:0000000001697490
1.CHECK EVAP CAN](/manual-img/5/57395/w960_57395-1949.png)
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
EC-601
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Component InspectionINFOID:0000000001697490
1.CHECK EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
With CONSULT-III
1. Turn ignition switch OFF.
2. Reconnect all harness connectors disconnected.
3. Disconnect EVAP purge hoses connected to EVAP canister purge volume control solenoid valve.
4. Turn ignition switch ON.
5. Select “PURG VOL CONT/V” in “ACTIVE TEST” mode with CONSULT-III.
6. Touch “Qd” and “Qu” on CONSULT-III screen to adjust “PURG
VOL CONT/V” opening and check air passage continuity of
EVAP canister purge volume control solenoid valve under the
following conditions.
Without CONSULT-III
1. Turn ignition switch OFF.
2. Disconnect EVAP canister purge volume control solenoid valve harness connector.
3. Disconnect EVAP purge hoses connected to EVAP canister purge volume control solenoid valve.
4. Check air passage continuity of EVAP canister purge volume control solenoid valve under the following
conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace EVAP canister purge volume control solenoid valve
Condition
(PURG VOL CONT/V value)Air passage continuity
between (A) and (B)
100% Existed
0% Not existed
PBIA9668J
ConditionAir passage continuity
between (A) and (B)
12V direct current supply between
terminals 1 and 2Existed
No supply Not existed
Page 1951 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-602
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
FUEL INJECTOR
FUEL INJECTOR
DescriptionINFOID:0000000001693431
The fuel injector is a small, precise solenoid valve. When the ECM
supplies a g NISSAN TIIDA 2007 Service Repair Manual EC-602
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
FUEL INJECTOR
FUEL INJECTOR
DescriptionINFOID:0000000001693431
The fuel injector is a small, precise solenoid valve. When the ECM
supplies a g](/manual-img/5/57395/w960_57395-1950.png)
EC-602
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
FUEL INJECTOR
FUEL INJECTOR
DescriptionINFOID:0000000001693431
The fuel injector is a small, precise solenoid valve. When the ECM
supplies a ground to the fuel injector circuit, the coil in the fuel injec-
tor is energized. The energized coil pulls the ball valve back and
allows fuel to flow through the fuel injector into the intake manifold.
The amount of fuel injected depends upon the injection pulse dura-
tion. Pulse duration is the length of time the fuel injector remains
open. The ECM controls the injection pulse duration based on
engine fuel needs.
Component Function CheckINFOID:0000000001693432
1.INSPECTION START
Turn ignition switch to START.
Is any cylinder ignited?
YES >> GO TO 2.
NO >> Go to EC-602, "
Diagnosis Procedure".
2.CHECK FUEL INJECTOR FUNCTION
With CONSULT-III
1. Start engine.
2. Perform “POWER BALANCE” in “ACTIVE TEST” mode with CONSULT-III.
3. Make sure that each circuit produces a momentary engine speed drop.
Without CONSULT-III
1. Let engine idle.
2. Listen to each fuel injector operating sound.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-602, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001693433
1.CHECK FUEL INJECTOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect fuel injector harness connector.
3. Turn ignition switch ON.
4. Check the voltage between fuel injector harness connector and ground.
PBIA9664J
Clicking noise should be heard.
PBIB3332E
Page 1952 of 5883
![NISSAN TIIDA 2007 Service Repair Manual FUEL INJECTOR
EC-603
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Che NISSAN TIIDA 2007 Service Repair Manual FUEL INJECTOR
EC-603
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Che](/manual-img/5/57395/w960_57395-1951.png)
FUEL INJECTOR
EC-603
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
Harness connectors F8, E8
10A fuse (No. 55)
Harness for open or short between fuel injector and fuse
>> Repair open circuit or short to ground or short to power in harness or connectors.
3.CHECK FUEL INJECTOR OUTPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between fuel injector harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK FUEL INJECTOR
Refer to EC-603, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace malfunctioning fuel injector.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000001693434
1.CHECK FUEL INJECTOR
1. Turn ignition switch OFF.
2. Disconnect fuel injector harness connector.
3. Check resistance between fuel injector terminals as follows.
Fuel injector
Ground Voltage
Cylinder Connector Terminal
1F17 1
Ground Battery voltage 2F18 1
3F19 1
4F20 1
Fuel injector ECM
Continuity
Cylinder Connector Terminal Connector Terminal
1F17 2
F1031
Existed 2F18 2 30
3F19 2 29
4F20 2 25
