2007 NISSAN TIIDA Service Repair Manual

start stop button key battery ECO mode manual transmission tire type battery

Page 5049 of 5883

NISSAN TIIDA 2007 Service Repair Manual DTC BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM
POWER SOURCE)
TM-103
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Remove oil pan. Refer to TM-191, "

Page 5050 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-104
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
DTC TURBINE REVOLUTION SENSOR
DTC TURBINE REVOLUTION SENSOR
DescriptionINFOID:0000000001694401
The turbine revolution sensor (power train revoluti

TM-104
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
DTC TURBINE REVOLUTION SENSOR
DTC TURBINE REVOLUTION SENSOR
DescriptionINFOID:0000000001694401
The turbine revolution sensor (power train revolution sensor) detects forward clutch drum rpm (revolutions per
minute). It is located on the input side of the automatic transaxle. The vehicle speed sensor A/T (Revolution
sensor) is located on the output side of the automatic transaxle. With the two sensors, input and output rpms
are accurately detected. As a result, optimal shift timing during deceleration and shift quality can be improved.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001694402
Remarks: Specification data are reference values.
On Board Diagnosis LogicINFOID:0000000001694403
This is not an OBD self-diagnostic item.
Diagnostic trouble code “TURBINE SENSOR” with CONSULT-III or 10th judgement flicker without CON-
SULT-III is detected when TCM does not receive the proper voltage signal from the sensor.
Possible CauseINFOID:0000000001694404
Harness or connector
(The sensor circuit is open or shorted.)
Turbine revolution sensor (power train revolution sensor)
DTC Confirmation ProcedureINFOID:0000000001694405
CAUTION:
Always drive vehicle at a safe speed.
Be careful not to rev engine into the red zone on the tachometer.
If performing this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait at
least 10 seconds before continuing.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Start engine.
2. Select “DATA MONITOR” mode for “A/T” with CONSULT-III.
3. Touch “START”.
4. Drive vehicle under the following conditions for more than 5 seconds.
SLCT LVR POSI: “D” position
VEHICLE SPEED: Higher than 40 km/h (25 MPH)
ENGINE SPEED: Higher than 1,500 rpm
THROTTLE POSI: Greater than 1.0/8 of the full throttle position
5. If the check result is NG, go to TM-104, "
Diagnosis Procedure".
WITHOUT CONSULT-III
1. Start engine.
2. Drive vehicle under the following conditions for more than 5 seconds.
Selector lever position: “D” position
Vehicle speed: Higher than 40 km/h (25 MPH)
Engine speed: Higher than 1,500 rpm
Throttle position: 1.0/8 of the full throttle position
3. Perform self-diagnosis. Refer to TM-38, "
Diagnosis Procedure without CONSULT-III".
4. If the check result is NG, go to TM-104, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001694407
1.CHECK INPUT SIGNAL
Item name Condition Display value
TURBINE REV During driving (lock-up ON) Approximately matches the engine speed.

Page 5051 of 5883

NISSAN TIIDA 2007 Service Repair Manual DTC TURBINE REVOLUTION SENSOR
TM-105
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
With CONSULT-III
1. Start engine.
2. Select “TCM INPUT SIGNALS” in “DATA MONIT

Page 5052 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-106
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
DTC TURBINE REVOLUTION SENSOR
4. Check voltage between turbine revolution sensor (power train
revolution sensor) harness connector terminals.
5. C

TM-106
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
DTC TURBINE REVOLUTION SENSOR
4. Check voltage between turbine revolution sensor (power train
revolution sensor) harness connector terminals.
5. Check voltage between turbine revolution sensor (power train
revolution sensor) harness connector terminal and ground.
6. If OK, check harness for short to ground and short to power.
7. Reinstall any part removed.
OK or NG
OK >> GO TO 4.
NG - 1 >> Battery voltage is not supplied between terminals 1 and 3, terminals 1 and ground: GO TO 6.
NG - 2 >> Battery voltage is not supplied between terminals 1 and 3 only: GO TO 7.
4. CHECK HARNESS BETWEEN TCM AND TURBINE REVOLUTION SENSOR (POWER TRAIN REVOLU-
TION SENSOR)
1. Turn ignition switch OFF.
2. Disconnect the turbine revolution sensor (power train revolution sensor) harness connector.
3. Check continuity between TCM connector terminal and turbine
revolution sensor (power train revolution sensor) harness con-
nector terminal.
4. If OK, check harness for short to ground and short to power.
5. Reinstall any part removed.
OK or NG
OK >> GO TO 5.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK TCM
1. Check TCM input/output signal. Refer to TM-119, "
Reference Value".
2. If NG, re-check TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
6. CHECK HARNESS BETWEEN TCM AND TURBINE REVOLUTION SENSOR [(POWER TRAIN REVOLU-
TION SENSOR) POWER]
1. Turn ignition switch OFF.
2. Disconnect the turbine revolution sensor (power train revolution sensor) harness connector.
Item Connector Terminal Judgement
standard
(Approx.)
Turbine revolution sensor
(power train revolution sensor)F47 1 - 3Battery volt-
age
SCIA2770E
Item Connector Terminal Judgement
standard
(Approx.)
Turbine revolution sensor
(power train revolution sensor)F47 1 - groundBattery volt-
age
SCIA2771E
Item Connector Terminal Continuity
TCM E32 38
Ye s
Turbine revolution sensor
(power train revolution sensor)F47 2
SCIA2772E

Page 5053 of 5883

NISSAN TIIDA 2007 Service Repair Manual DTC TURBINE REVOLUTION SENSOR
TM-107
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
3. Check continuity between TCM connector terminals and turbine
revolution sensor (p

Page 5054 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-108
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
CONTROL UNIT (RAM), CONTROL UNIT (ROM)
CONTROL UNIT (RAM), CONTROL UNIT (ROM)
DescriptionINFOID:0000000001694408
The TCM consists of a microcomput

Page 5055 of 5883

NISSAN TIIDA 2007 Service Repair Manual MAIN POWER SUPPLY AND GROUND CIRCUIT
TM-109
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
MAIN POWER SUPPLY AND GROUND CIRCUIT
DescriptionINFOID:0000000001694413
When

Page 5056 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-110
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
MAIN POWER SUPPLY AND GROUND CIRCUIT
4. Check voltage between TCM connector terminals and ground.
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2.DETECT
