Page 5249 of 5883

NISSAN TIIDA 2007 Service Repair Manual ASSEMBLY TM-303 < DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)] C E F G H I J K L MA B TM N O P Assembly (2)INFOID:0000000001730998 1. Remove paper rolled around bearing retainer. 2. Install thrus

Page 5250 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-304 < DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)] ASSEMBLY 6. Install overrun clutch hub (1) into forward clutch drum. CAUTION: Align teeth of overrun clutch drive plates before installing. 7

Page 5251 of 5883

NISSAN TIIDA 2007 Service Repair Manual ASSEMBLY TM-305 < DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)] C E F G H I J K L MA B TM N O P 11. Install rear sun gear on rear planetary carrier. CAUTION: Be careful with the direction of rear

Page 5252 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-306 < DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)] ASSEMBLY 17. Install snap ring into transaxle case using suitable tool. 18. Install needle bearing (1) on front sun gear (2). CAUTION: Be car

Page 5253 of 5883

NISSAN TIIDA 2007 Service Repair Manual ASSEMBLY TM-307 < DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)] C E F G H I J K L MA B TM N O P 22. Install needle bearing on high clutch hub. CAUTION: Be careful with the direction of needle bear

Page 5254 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-308 < DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)] ASSEMBLY  Measure clearance between reverse clutch drum and needle bear- ing for oil pump cover.  Select proper thickness of bearing race s

Page 5255 of 5883

NISSAN TIIDA 2007 Service Repair Manual ASSEMBLY TM-309 < DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)] C E F G H I J K L MA B TM N O P b. Measure dimension “M”. c. Measure thickness of straightedge “t”. 3. Adjust total end play

Page 5256 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-310 < DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)] ASSEMBLY a. Place thrust washer on reverse clutch drum. b. Measure dimension “O”. c. Measure dimension “P”. d. Calculate dimension
