Page 585 of 5883
DEF-34
< SYMPTOM DIAGNOSIS >
REAR WINDOW DEFOGGER SWITCH DOES NOT LIGHT, BUT REAR WINDOW
DEFOGGER OPERATES
REAR WINDOW DEFOGGER SWITCH DOES NOT LIGHT, BUT REAR WIN-
DOW DEFOGGER OPERATES
Diagnosis ProcedureINFOID:0000000001697574
1.CHECK CONTROLLER (AUTO AMP.) (REAR WINDOW DEFOGGER SWITCH)
Check that the controller (auto amp.) (rear window defogger switch) is operating normally.
OK or NG
OK >> Refer to XX-XX, "*****".
NG >> Refer to DEF-11, "
Diagnosis Procedure".
Page 586 of 5883

PRECAUTIONS
DEF-35
< PRECAUTION >
C
D
E
F
G
H
I
J
K
MA
B
DEF
N
O
P
PRECAUTION
PRECAUTIONS
Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSION-
ER"
INFOID:0000000001697575
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-
ness connectors.
Page 587 of 5883
DEF-36
< ON-VEHICLE REPAIR >
FILAMENT
ON-VEHICLE REPAIR
FILAMENT
Inspection and RepairINFOID:0000000001697576
INSPECTION
1. When measuring voltage, wrap tin foil around the top of the neg-
ative probe. Then press the foil against the wire with your finger.
2. Attach probe circuit tester (in Volt range) to middle portion of
each filament.
3. If a filament is burned out, circuit tester registers 0 or battery
voltage.
4. To locate burned out point, move probe to left and right along fil-
ament. Test needle will swing abruptly when probe passes the
point.
REPAIR
REPAIR EQUIPMENT
Conductive silver composition (Dupont No. 4817 or equivalent)
SEL122R
SEL263
SEL265
Page 588 of 5883

FILAMENT
DEF-37
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
MA
B
DEF
N
O
P
Ruler 30 cm (11.8 in) long
Drawing pen
Heat gun
Alcohol
Cloth
REPAIRING PROCEDURE
1. Wipe broken heat wire and its surrounding area clean with a
cloth dampened in alcohol.
2. Apply a small amount of conductive silver composition to tip of
drawing pen.
Shake silver composition container before use.
3. Place ruler on glass along broken line. Deposit conductive silver
composition on break with drawing pen. Slightly overlap existing
heat wire on both sides [preferably 5 mm (0.20 in)] of the break.
4. After repair has been completed, check repaired wire for conti-
nuity. This check should be conducted 10 minutes after silver
composition is deposited.
Do not touch repaired area while test is being conducted.
5. Apply a constant stream of hot air directly to the repaired area
for approximately 20 minutes with a heat gun. A minimum dis-
tance of 3 cm (1.2 in) should be kept between repaired area and
hot air outlet.
If a heat gun is not available, let the repaired area dry for 24
hours.
SPECIAL REPAIR REQUIREMENT
PIIA0215E
SEL012D
SEL013D
Page 589 of 5883
DEF-38
< ON-VEHICLE REPAIR >
CONDENSER
CONDENSER
Exploded ViewINFOID:0000000001697577
Refer to DEF-38, "Exploded View".
Removal and InstallationINFOID:0000000001697578
REMOVAL
1. Remove the rear seat cushion and the rear seat back.
Refer to XX-XX, "*****"
.
2. Remove the rear kickplate, rear wheel well garnish and the rear pillar finisher.
Refer to XX-XX, "*****"
.
3. Remove bolt (A), and then remove condenser (1) from the vehi-
cle body.
INSTALLATION
Install in the reverse order of removal.
JMLIA0013ZZ
Page 590 of 5883

DLK-1
