NISSAN TIIDA 2007 Service Repair Manual KEY INTERLOCK CABLE TM-207 < ON-VEHICLE REPAIR >[TYPE 1 (4AT: RE4F03B)] C E F G H I J K L MA B TM N O P 7. Remove steering column cover (upper and lower) and instru- ment lower finisher. Refer to IP-1

Page 5154 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-208 < ON-VEHICLE REPAIR >[TYPE 1 (4AT: RE4F03B)] KEY INTERLOCK CABLE 8. Slide the slider (A) toward the key interlock rod (D) while press- ing the pull lock (B) down to securely connect the adjust

Page 5155 of 5883

NISSAN TIIDA 2007 Service Repair Manual AIR BREATHER HOSE TM-209 < ON-VEHICLE REPAIR >[TYPE 1 (4AT: RE4F03B)] C E F G H I J K L MA B TM N O P AIR BREATHER HOSE Removal and InstallationINFOID:0000000001731381 COMPONENTS REMOVAL 1. Remove air

Page 5156 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-210 < REMOVAL AND INSTALLATION >[TYPE 1 (4AT: RE4F03B)] TRANSAXLE ASSEMBLY REMOVAL AND INSTALLATION TRANSAXLE ASSEMBLY Exploded ViewINFOID:0000000001731386 Removal and InstallationINFOID:0000000001

Page 5157 of 5883

NISSAN TIIDA 2007 Service Repair Manual TRANSAXLE ASSEMBLY TM-211 < REMOVAL AND INSTALLATION >[TYPE 1 (4AT: RE4F03B)] C E F G H I J K L MA B TM N O P 2. Disconnect the following connectors and remove the wire har- ness.  Turbine revolution

Page 5158 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-212 < REMOVAL AND INSTALLATION >[TYPE 1 (4AT: RE4F03B)] TRANSAXLE ASSEMBLY When installing the torque converter to the transaxle measure dis- tance A. INSTALLATION Installation is in the reverse or

Page 5159 of 5883

NISSAN TIIDA 2007 Service Repair Manual OVERHAUL TM-213 < DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)] C E F G H I J K L MA B TM N O P DISASSEMBLY AND ASSEMBLY OVERHAUL ComponentINFOID:0000000001730978 SCIA7177E

Page 5160 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-214 < DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)] OVERHAUL 1. Pinion mate gear thrust washer 2. Pinion mate gear 3. Pinion mate shaft 4. Lock pin 5. Side gear 6. Side gear thrust washer 7. Di
