Page 2273 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-924
< COMPONENT DIAGNOSIS >[MR18DE]
P1225 TP SENSOR
P1225 TP SENSOR
DescriptionINFOID:0000000001161899
Electric throttle control actuator consists of throttle control motor,
throttle position senso NISSAN TIIDA 2007 Service Repair Manual EC-924
< COMPONENT DIAGNOSIS >[MR18DE]
P1225 TP SENSOR
P1225 TP SENSOR
DescriptionINFOID:0000000001161899
Electric throttle control actuator consists of throttle control motor,
throttle position senso](/manual-img/5/57395/w960_57395-2272.png)
EC-924
< COMPONENT DIAGNOSIS >[MR18DE]
P1225 TP SENSOR
P1225 TP SENSOR
DescriptionINFOID:0000000001161899
Electric throttle control actuator consists of throttle control motor,
throttle position sensor, etc. The throttle position sensor responds to
the throttle valve movement.
The throttle position sensor has two sensors. These sensors are a
kind of potentiometers which transform the throttle valve position into
output voltage, and emit the voltage signal to the ECM. In addition,
these sensors detect the opening and closing speed of the throttle
valve and feed the voltage signals to the ECM. The ECM judges the
current opening angle of the throttle valve from these signals and the
ECM controls the throttle control motor to make the throttle valve
opening angle properly in response to driving condition.
DTC LogicINFOID:0000000001161900
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 10V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-924, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001161901
1.CHECK ELECTRIC THROTTLE CONTROL ACTUATOR VISUALLY
1. Turn ignition switch OFF.
2. Remove the intake air duct.
PBIB0145E
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1225Closed throttle position
learning performanceClosed throttle position learning value is exces-
sively low. Electric throttle control actuator
(TP sensor 1 and 2)
Page 2274 of 5883
P1225 TP SENSOR
EC-925
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
3. Check if foreign matter is caught between the throttle valve (1)
and the housing.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Remove the foreign matter and clean the electric throttle
control actuator inside.
2.REPLACE ELECTRIC THROTTLE CONTROL ACTUATOR
1. Replace electric throttle control actuator.
2. Go to EC-925, "
Special Repair Requirement".
>> INSPECTION END
Special Repair RequirementINFOID:0000000001161902
1.PERFORM THROTTLE VALVE CLOSED POSITION LEARNING
Refer to EC-694, "
THROTTLE VALVE CLOSED POSITION LEARNING : Special Repair Requirement"
>> GO TO 2.
2.PERFORM IDLE AIR VOLUME LEARNING
Refer to EC-694, "
IDLE AIR VOLUME LEARNING : Special Repair Requirement"
>> END
2. Electric throttle control actuator
JMBIA0447ZZ
Page 2275 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-926
< COMPONENT DIAGNOSIS >[MR18DE]
P1226 TP SENSOR
P1226 TP SENSOR
DescriptionINFOID:0000000001161903
Electric throttle control actuator consists of throttle control motor,
throttle position senso NISSAN TIIDA 2007 Service Repair Manual EC-926
< COMPONENT DIAGNOSIS >[MR18DE]
P1226 TP SENSOR
P1226 TP SENSOR
DescriptionINFOID:0000000001161903
Electric throttle control actuator consists of throttle control motor,
throttle position senso](/manual-img/5/57395/w960_57395-2274.png)
EC-926
< COMPONENT DIAGNOSIS >[MR18DE]
P1226 TP SENSOR
P1226 TP SENSOR
DescriptionINFOID:0000000001161903
Electric throttle control actuator consists of throttle control motor,
throttle position sensor, etc. The throttle position sensor responds to
the throttle valve movement.
The throttle position sensor has two sensors. These sensors are a
kind of potentiometers which transform the throttle valve position into
output voltage, and emit the voltage signal to the ECM. In addition,
these sensors detect the opening and closing speed of the throttle
valve and feed the voltage signals to the ECM. The ECM judges the
current opening angle of the throttle valve from these signals and the
ECM controls the throttle control motor to make the throttle valve
opening angle properly in response to driving condition.
DTC LogicINFOID:0000000001161904
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 10V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Turn ignition switch OFF, wait at least 10 seconds.
3. Turn ignition switch ON.
4. Repeat steps 2 and 3 for 32 times.
5. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-926, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001161905
1.CHECK ELECTRIC THROTTLE CONTROL ACTUATOR VISUALLY
1. Turn ignition switch OFF.
2. Remove the intake air duct.
PBIB0145E
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1226Closed throttle position
learning performanceClosed throttle position learning is not per-
formed successfully, repeatedly. Electric throttle control actuator
(TP sensor 1 and 2)
Page 2276 of 5883
P1226 TP SENSOR
EC-927
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
3. Check if foreign matter is caught between the throttle valve (1)
and the housing.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Remove the foreign matter and clean the electric throttle
control actuator inside.
2.REPLACE ELECTRIC THROTTLE CONTROL ACTUATOR
1. Replace electric throttle control actuator.
2. Go to EC-925, "
Special Repair Requirement".
>> INSPECTION END
Special Repair RequirementINFOID:0000000001161906
1.PERFORM THROTTLE VALVE CLOSED POSITION LEARNING
Refer to EC-694, "
THROTTLE VALVE CLOSED POSITION LEARNING : Special Repair Requirement"
>> GO TO 2.
2.PERFORM IDLE AIR VOLUME LEARNING
Refer to EC-694, "
IDLE AIR VOLUME LEARNING : Special Repair Requirement"
>> END
2. Electric throttle control actuator
JMBIA0447ZZ
Page 2277 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-928
< COMPONENT DIAGNOSIS >[MR18DE]
P1229 SENSOR POWER SUPPLY
P1229 SENSOR POWER SUPPLY
DTC LogicINFOID:0000000001161907
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Conf NISSAN TIIDA 2007 Service Repair Manual EC-928
< COMPONENT DIAGNOSIS >[MR18DE]
P1229 SENSOR POWER SUPPLY
P1229 SENSOR POWER SUPPLY
DTC LogicINFOID:0000000001161907
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Conf](/manual-img/5/57395/w960_57395-2276.png)
EC-928
< COMPONENT DIAGNOSIS >[MR18DE]
P1229 SENSOR POWER SUPPLY
P1229 SENSOR POWER SUPPLY
DTC LogicINFOID:0000000001161907
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 10V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-928, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001161908
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground Inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK ACCELERATOR PEDAL POSITION SENSOR 1 POWER SUPPLY CIRCUIT
1. Disconnect accelerator pedal position (APP) sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between APP sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 3.
3.CHECK SENSOR POWER SUPPLY CIRCUITS
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
P1229Sensor power supply
circuit shortECM detects a voltage of power source for
sensor is excessively low or high. Harness or connectors
(APP sensor 1 circuit is shorted.)
(TP sensor circuit is shorted.)
[Camshaft position sensor (PHASE) circuit is
shorted.]
Accelerator pedal position sensor 1 (APPS 1)
Throttle position sensor
Camshaft position sensor (PHASE)
APP sensor
Ground Voltage
Connector Terminal
E12 (LHD models)
M204 (RHD models)4 Ground Approx. 5V
Page 2278 of 5883
![NISSAN TIIDA 2007 Service Repair Manual P1229 SENSOR POWER SUPPLY
EC-929
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Check harness for short to power and short to ground, between the following terminals.
Is the inspectio NISSAN TIIDA 2007 Service Repair Manual P1229 SENSOR POWER SUPPLY
EC-929
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Check harness for short to power and short to ground, between the following terminals.
Is the inspectio](/manual-img/5/57395/w960_57395-2277.png)
P1229 SENSOR POWER SUPPLY
EC-929
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Check harness for short to power and short to ground, between the following terminals.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair short to ground or short to power in harness or connectors.
4.CHECK COMSHAFT PSITION SENSOR
Refer to EC-868, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace malfunctioning component.
5.CHECK TP SENSOR
Refer to EC-958, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 8.
6.REPLACE ELECTRIC THROTTLE CONTROL ACTUATOR
1. Replace electric throttle control actuator.
2. Go to EC-958, "
Component Inspection".
>> INSPECTION END
7.CHECK APP SENSOR
Refer to EC-950, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 8.
8.REPLACE ACCELERATOR PEDAL ASSEMBLY
1. Replace accelerator pedal assembly.
2. Go to EC-693, "
ACCELERATOR PEDAL RELEASED POSITION LEARNING : Special Repair Require-
ment".
>> INSPECTION END
9.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
ECM Sensor
Connector Terminal Item Connector Terminal
F1172 Electric throttle control actuator F7 2
78 CMP sensor (PHASE) F21 1
E16 106 APP sensorE12 (LHD models)
M204 (RHD models)4
Page 2279 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-930
< COMPONENT DIAGNOSIS >[MR18DE]
P1564 ASCD STEERING SWITCH
P1564 ASCD STEERING SWITCH
DescriptionINFOID:0000000001161909
ASCD steering switch has variant values of electrical resistance for eac NISSAN TIIDA 2007 Service Repair Manual EC-930
< COMPONENT DIAGNOSIS >[MR18DE]
P1564 ASCD STEERING SWITCH
P1564 ASCD STEERING SWITCH
DescriptionINFOID:0000000001161909
ASCD steering switch has variant values of electrical resistance for eac](/manual-img/5/57395/w960_57395-2278.png)
EC-930
< COMPONENT DIAGNOSIS >[MR18DE]
P1564 ASCD STEERING SWITCH
P1564 ASCD STEERING SWITCH
DescriptionINFOID:0000000001161909
ASCD steering switch has variant values of electrical resistance for each button. ECM reads voltage variation
of switch, and determines which button is operated.
Refer to EC-728, "
System Description" for the ASCD function.
DTC LogicINFOID:0000000001161910
DTC DETECTION LOGIC
NOTE:
If DTC P1564 is displayed with DTC P0605, first perform the trouble diagnosis for DTC P0605. Refer to
EC-880, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Wait at least 10 seconds.
3. Press MAIN switch for at least 10 seconds, then release it and wait at least 10 seconds.
4. Press CANCEL switch for at least 10 seconds, then release it and wait at least 10 seconds.
5. Press RESUME/ACCELERATE switch for at least 10 seconds, then release it and wait at least 10 sec-
onds.
6. Press SET/COAST switch for at least 10 seconds, then release it and wait at least 10 seconds.
7. Check DTC.
Is DTC detected?
YES >> Go to EC-930, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001161911
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground Inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YS >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK ASCD STEERING SWITCH CIRCUIT
With CONSULT-III
1. Turn ignition switch ON.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
P1564 ASCD steering switch An excessively high voltage signal from the
ASCD steering switch is sent to ECM.
ECM detects that input signal from the
ASCD steering switch is out of the specified
range.
ECM detects that the ASCD steering switch
is stuck ON. Harness or connectors
(The switch circuit is open or shorted.)
ASCD steering switch
ECM
Page 2280 of 5883
![NISSAN TIIDA 2007 Service Repair Manual P1564 ASCD STEERING SWITCH
EC-931
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
2. Select “MAIN SW”, “CANCEL SW”, “RESUME/ACC SW” and “SET SW” in “DATA MONITOR” m NISSAN TIIDA 2007 Service Repair Manual P1564 ASCD STEERING SWITCH
EC-931
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
2. Select “MAIN SW”, “CANCEL SW”, “RESUME/ACC SW” and “SET SW” in “DATA MONITOR” m](/manual-img/5/57395/w960_57395-2279.png)
P1564 ASCD STEERING SWITCH
EC-931
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
2. Select “MAIN SW”, “CANCEL SW”, “RESUME/ACC SW” and “SET SW” in “DATA MONITOR” mode with
CONSULT-III.
3. Check each item indication under the following conditions.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector terminals as follows.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 3.
3.CHECK ASCD STEERING SWITCH GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Disconnect combination switch harness connector M30.
4. Check the continuity between combination switch and ECM harness connector.
5. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Check the following.
Harness connectors M69, E7
Combination switch (spiral cable)
Harness for open and short between ECM and combination switch
>> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK ASCD STEERING SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
Monitor item Condition Indication
MAIN SW MAIN switchPressed ON
Released OFF
CANCEL SW CANCEL switchPressed ON
Released OFF
RESUME/ACC SW RESUME/ACCELERATE switchPressed ON
Released OFF
SET SW SET/COAST switchPressed ON
Released OFF
(+) (–)
Condition Voltage
Connector Terminal Connector Terminal
E1694
(ASCD steering switch signal)E16 95MAIN switch: Pressed Approx. 0V
CANSEL switch: Pressed Approx. 1V
SET/COAST switch: Pressed Approx. 2V
RESUME/ACCELERATE switch: Pressed Approx. 3V
All ASCD steering switches: Released Approx. 4V
Combination switch ECM
Continuity
Terminal Connector Terminal
15 E16 95 Existed
