Page 1089 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-500 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] DOOR SWITCH 1. Disconnect BCM and driver door switch connectors. 2. Check continuity between BCM connector (A) M18 terminal 29 and door swit

Page 1090 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR SWITCH DLK-501 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] C D E F G H I J L MA B DLK N O P PASSENGER SIDE : DescriptionINFOID:0000000001530626 Detects door open/closed condition. PASSENG

Page 1091 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-502 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] DOOR SWITCH 2. Check continuity between BCM connector (A) M18 terminal 30 and passenger door switch connector (B) B27 terminal 2. 3. Check c

Page 1092 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR SWITCH DLK-503 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] C D E F G H I J L MA B DLK N O P REAR LH : DescriptionINFOID:0000000001530630 Detects door open/closed condition. REAR LH : Comp

Page 1093 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-504 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] DOOR SWITCH 2. Check continuity between BCM connector (A) M19 terminal 59 and rear door switch LH connector (B) B71 terminal 1. 3. Check con

Page 1094 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR SWITCH DLK-505 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] C D E F G H I J L MA B DLK N O P REAR RH : DescriptionINFOID:0000000001530634 Detects door open/close condition. REAR RH : Compo

Page 1095 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-506 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] DOOR SWITCH 2. Check continuity between BCM connector (A) M19 terminal 60 and rear door switch RH connector (B) B53 terminal 1. 3. Check con

Page 1096 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR SWITCH DLK-507 < COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK] C D E F G H I J L MA B DLK N O P BACK DOOR : DescriptionINFOID:0000000001530638 Detects back door open condition. BACK DOOR : Co
