INL-6
< FUNCTION DIAGNOSIS >
INTERIOR ROOM LAMP CONTROL SYSTEM
a signal is received from an Intelligent Key or main power window and door lock/unlock switch, or when the
front door LH lock assembly (key cylinder switch) is locked or unlocked
a door is opened or closed
the Intelligent Key is removed from or inserted into the key slot.
The Interior lamp battery saver control time period can be changed with the function setting of CONSULT-III.
Component Parts LocationINFOID:0000000001728856
Component DescriptionINFOID:0000000001728857
1. BCM M18, M19, M20 (view with
glove box removed)2. Key switch and key lock solenoid
M273. Front door switch
Driver side B34
Passenger side B27
4. Rear door switch
Driver side B53
Passenger side B715. Front door key cylinder switch 6. Back door lock assembly D405
(hatchback)
7. Trunk lid opener switch B61 (sedan)
LIIA2942E
Part name Description
BCMProvides power and ground and controls timer functions for the
interior room lamps, step lamps and cargo lamp.
Intelligent key unitTransmits the lock/unlock signal to the BCM via CAN communi-
cation.
Key switch and ignition knob switch (with I-Key)
Provides key in ignition status to the BCM.
Key switch and lock solenoid (without I-Key)
Door switches Provides door OPEN/CLOSED status to the BCM.
Page 3658 of 5883
INTERIOR ROOM LAMP CONTROL SYSTEM
INL-7
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
INL
N
O
P
Back door lock assembly (hatchback)
Provides back door OPEN/CLOSED status to the BCM.
Back door opener switch (hatchback)
Trunk lid opener switch (sedan) Provides trunk lid OPEN/CLOSED status to the BCM.
Main power window and door lock/unlock switch [front door lock
assembly LH (key cylinder switch)]. Provides door lock/unlock position switch LH status to the BCM.
Page 3659 of 5883

INL-8
< FUNCTION DIAGNOSIS >
ILLUMINATION CONTROL SYSTEM
ILLUMINATION CONTROL SYSTEM
System DiagramINFOID:0000000001730918
System DescriptionINFOID:0000000001730919
The illumination lamps operation is dependent upon the position of the lighting switch (combination switch).
When the lighting switch is placed in the 1ST or 2ND position (or if the auto light system is activated) the BCM
(body control module) receives input requesting the parking lamps to illuminate. This input is communicated to
the IPDM E/R (intelligent power distribution module engine room) via the CAN communication lines. The CPU
(central processing unit) of the IPDM E/R controls the tail lamp relay coil. When energized, this relay directs
power to the parking and illumination lamps, which then illuminate.
BATTERY SAVER CONTROL
When the lighting switch (combination switch) is in the 1ST or 2ND position and the ignition switch is turned
from ON or ACC to OFF, the battery saver control feature is activated. Under this condition, the illumination
lamps remain illuminated for 30 minutes unless the lighting switch position is changed. If the lighting switch
position is changed, then the illumination lamps are turned off after a 30 second delay. When the lighting
switch is turned from OFF to 1ST or 2ND position (or if auto light system is activated) after illumination lamps
have been turned off by the battery saver control, the illumination lamps illuminate again.
Component Parts LocationINFOID:0000000001730920
ALNIA0894GB
WKIA5674E
Page 3660 of 5883
ILLUMINATION CONTROL SYSTEM
INL-9
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
INL
N
O
P
Component DescriptionINFOID:0000000001730921
1. IPDM E/R E46, E47, E48 2. BCM M18, M19, M20 (view with glove
box removed)3. Combination switch M28
4. Combination meter
Part name Description
BCMThe BCM monitors the lighting switch position with the combina-
tion switch reading function. The BCM requests, via CAN com-
munication, that the IPDM E/R activate the tail lamp relay.
IPDM E/RThe IPDM E/R activates the tail lamp relay based on inputs re-
ceived from the BCM via the CAN communication network.
Combination switchThe combination switch provides input to the BCM about the light-
ing switch position.
Page 3661 of 5883

INL-10
< FUNCTION DIAGNOSIS >
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Function (BCM - COMMON ITEM)INFOID:0000000001728866
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
INT LAMP
INT LAMP : CONSULT-III Function (BCM - INT LAMP)INFOID:0000000001728867
WORK SUPPORT
Diagnosis mode Function Description
WORK SUPPORT Changes the setting for each system function.
SELF-DIAG RESULTS Displays the diagnosis results judged by BCM. Refer to XX-XX, "*****"
.
CAN DIAG SUPPORT MNTR Monitors the reception status of CAN communication viewed from BCM.
DATA MONITOR The BCM input/output signals are displayed.
ACTIVE TEST The signals used to activate each device are forcibly supplied from BCM.
ECU IDENTIFICATION The BCM part number is displayed.
CONFIGURATION Enables to read and save the vehicle specification.
Enables to write the vehicle specification when replacing BCM.
JPLIA0093GB
Service item Setting item Setting
ROOM LAMP TIMER SETMODE 1 0 sec.
Sets the interior room lamp ON time. (Timer operating time) MODE 2 7.5 sec.
MODE 3* 15 sec.
MODE 4 30 sec.
SET I/L D-UNLCK INTCONON* With the interior room lamp timer function
OFF Without the interior room lamp timer function
Page 3662 of 5883

DIAGNOSIS SYSTEM (BCM)
INL-11
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
INL
N
O
P
*: Initial setting
DATA MONITOR
ROOM LAMP ON TIME SETMODE 1 0.5 sec.
Sets the interior room lamp gradual brightening time. MODE 2* 1 sec.
MODE 3 2 sec.
MODE 4 3 sec.
MODE 5 4 sec.
MODE 6 5 sec.
MODE 7 0 sec.
ROOM LAMP OFF TIME SETMODE 1 0.5 sec.
Sets the interior room lamp gradual dimming time. MODE 2* 1 sec.
MODE 3 2 sec.
MODE 4 3 sec.
MODE 5 4 sec.
MODE 6 5 sec.
MODE 7 0 sec.
R LAMP TIMER LOGIC SETMODE 1* Interior room lamp timer activates with synchronizing all doors.
MODE 2Interior room lamp timer activates with synchronizing the driver door
only. Service item Setting item Setting
Monitor item
[Unit]Description
IGN ON SW
[ON/OFF]Ignition switch (ON) status judges from IGN signal (ignition power supply)
ACC SW
[ON/OFF]Ignition switch (ACC) status judges from ACC signal (ACC power supply)
KEY ON SW
[ON/OFF]The switch status input from key switch
PUSH SW
[ON/OFF]Push switch status received from Intelligent Key unit by CAN communication
DOOR SW-DR
[ON/OFF]The switch status input from front door switch (driver side)
DOOR SW-AS
[ON/OFF]The switch status input from front door switch (passenger side)
DOOR SW-RR
[ON/OFF]The switch status input from rear door switch RH
DOOR SW- RL
[ON/OFF]The switch status input from rear door switch LH
BACK DOOR SW
[ON/OFF]The switch status input from back door switch
CDL LOCK SW
[ON/OFF]Lock switch status input from door lock and unlock switch
CDL UNLOCK SW
[ON/OFF]Unlock switch status input from door lock and unlock switch
I-KEY LOCK
[ON/OFF]Lock signal status received from Intelligent Key unit by CAN communication
I-KEY UNLOCK
[ON/OFF]Unlock signal status received from Intelligent Key unit by CAN communication
Page 3663 of 5883

INL-12
< FUNCTION DIAGNOSIS >
DIAGNOSIS SYSTEM (BCM)
ACTIVE TEST
BATTERY SAVER
BATTERY SAVER : CONSULT-III Function (BCM - BATTERY SAVER)INFOID:0000000001728868
WORK SUPPORT
*: Initial setting
DATA MONITOR
KEYLESS LOCK
[ON/OFF]Lock signal status received from remote keyless entry receiver (integrated in the
BCM)
KEYLESS UNLOCK
[ON/OFF]Unlock signal status received from remote keyless entry receiver (integrated in the
BCM) Monitor item
[Unit]Description
Test item Operation Description
INT LAMPONOutputs the interior room lamp control signal to turn the interior room lamps ON.
[Map lamp, personal lamp, room lamp, luggage room lamp (when applicable lamps
switch is in DOOR position.)]
OFF Stops the interior room lamp control signal to turn the interior room lamps.
Service item Setting item Setting
ROOM LAMP TIMER SETMODE 1* 30 min.
Sets the interior room lamp battery saver timer operating
time.
MODE 2 60 min.
Monitor item
[Unit]Description
IGN ON SW
[ON/OFF]Ignition switch (ON) status judges from IGN signal (ignition power supply)
ACC SW
[ON/OFF]Ignition switch (ACC) status judges from ACC signal (ACC power supply)
KEY ON SW
[ON/OFF]The switch status input from key switch
PUSH SW
[ON/OFF]Push switch status received from Intelligent Key unit by CAN communication
DOOR SW-DR
[ON/OFF]The switch status input from front door switch (driver side)
DOOR SW-AS
[ON/OFF]The switch status input from front door switch (passenger side)
DOOR SW-RR
[ON/OFF]The switch status input from rear door switch RH
DOOR SW- RL
[ON/OFF]The switch status input from rear door switch LH
BACK DOOR SW
[ON/OFF]The switch status input from back door switch
CDL LOCK SW
[ON/OFF]Lock switch status input from door lock and unlock switch
CDL UNLOCK SW
[ON/OFF]Unlock switch status input from door lock and unlock switch
I-KEY LOCK
[ON/OFF]Lock signal status received from Intelligent Key unit by CAN communication
Page 3664 of 5883
DIAGNOSIS SYSTEM (BCM)
INL-13
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
INL
N
O
P
ACTIVE TEST
*: Each lamp switch is in ON position.I-KEY UNLOCK
[ON/OFF]Unlock signal status received from Intelligent Key unit by CAN communication
KEYLESS LOCK
[ON/OFF]Lock signal status received from remote keyless entry receiver (integrated in the
BCM)
KEYLESS UNLOCK
[ON/OFF]Unlock signal status received from remote keyless entry receiver (integrated in the
BCM) Monitor item
[Unit]Description
Test item Operation Description
BATTERY SAVEROFF Cuts the interior room lamp power supply to turn interior room lamps OFF.
ON Outputs the interior room lamp power supply to turn interior room lamps ON.*
