NISSAN TIIDA 2007 Service Repair Manual EC-148
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P0132 HO2S1
P0132 HO2S1
DescriptionINFOID:0000000001670916
The heated oxygen sensor 1 is placed into the exhaust manifold. It
detects the amount

Page 1498 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0132 HO2S1
EC-149
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to normal operating temperature.

Page 1499 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-150
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P0132 HO2S1
Check heated oxygen sensor 1 connector for water.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace harness or

Page 1500 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0132 HO2S1
EC-151
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 3.
3.CHECK HEATED OXYGEN SENSOR 1

Page 1501 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-152
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P0133 HO2S1
P0133 HO2S1
DescriptionINFOID:0000000001670920
The heated oxygen sensor 1 is placed into the exhaust manifold. It
detects the amount

Page 1502 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0133 HO2S1
EC-153
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait

P0133 HO2S1
EC-153
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Always perform at a temperature above -10°C (14°F).
Before performing the following procedure, confirm that battery voltage is more than 11V at idle.
Do you have CONSULT-III?
YES >> GO TO 2.
NO >> GO TO 3.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
With CONSULT-III
1. Start engine and warm it up to normal operating temperature.
2. Stop engine and wait at least 10 seconds.
3. Turn ignition switch ON and select “HO2S1 (B1) P0133” of “HO2S1” in “DTC WORK SUPPORT” mode
with CONSULT-III.
4. Touch “START”.
5. Start engine and let it idle for at least 3 minutes.
NOTE:
Never raise engine speed above 3,600 rpm after this step. If the engine speed limit is exceeded,
return to step 5.
6. When the following conditions are met, “TESTING” will be displayed on the CONSULT-III screen. Maintain
the conditions continuously until “TESTING” changes to “COMPLETED”. (It will take approximately 40 to
50 seconds.)
CAUTION:
Always drive vehicle at a safe speed.
If “TESTING” is not displayed after 5 minutes, retry from step 2.
7. Touch “SELF-DIAG RESULTS”.
Which displayed on COUSULT-III screen?
OK >> INSPECTION END.
NG >> Go to EC-154, "
Diagnosis Procedure".
3.PERFORM COMPONENT FUNCTION CHECK
Without CONSULT-III
1. Start engine and warm it up to normal operating temperature.
2. Set volmeter probes between ECM harness connector terminals as follows.
Is the inspection result normal?
YES >> INSPECTION END.
NO >> Go to EC-154, "
Diagnosis Procedure".
ENG SPEED 1,300 - 3,500 rpm
VHCL SPEED SE More than 80 km/h (50 MPH)
B/FUEL SCHDL 3 - 15 msec
Shift lever Suitable position
(+) (–)
Condition Voltage
Connector Terminal Connector Terminal
F1149
(HO2S1 signal)F11 56Engine speed held at
2,000 rpm constant un-
der no load. The voltage fluctuates between 0 to 0.3V and
0.6 to 1.0V more than 5 times within 10 sec-
onds.
1 time: 0 - 0.3V → 0.6 - 1.0V → 0 - 0.3V
2 times: 0 - 0.3V → 0.6 - 1.0V → 0 - 0.3V → 0.6
- 1.0V → 0 - 0.3V

Page 1503 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-154
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P0133 HO2S1
Diagnosis Procedure
INFOID:0000000001670922
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E15. Re

Page 1504 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0133 HO2S1
EC-155
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
5. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repa
