Page 4233 of 5883

NISSAN TIIDA 2007 Service Repair Manual LU-26 < ON-VEHICLE MAINTENANCE >[K9K] ENGINE OIL ON-VEHICLE MAINTENANCE ENGINE OIL InspectionINFOID:0000000001381537 OIL LEVEL AND MUDDINESS  Before starting the engine, check the oil level placing t

Page 4234 of 5883

NISSAN TIIDA 2007 Service Repair Manual ENGINE OIL LU-27 < ON-VEHICLE MAINTENANCE >[K9K] C D E F G H I J K L MA LU N P O DrainingINFOID:0000000001381538 WARNING:  Be careful not to burn yourself, as the engine oil is hot.  Prolonged and r

Page 4235 of 5883

NISSAN TIIDA 2007 Service Repair Manual LU-28 < ON-VEHICLE MAINTENANCE >[K9K] OIL FILTER OIL FILTER ReplacementINFOID:0000000001381540 1. Remove engine undercover using power tool. 2. Using an oil filter wrench [SST: KV113C0010 (Mot. 1329)]

Page 4236 of 5883

NISSAN TIIDA 2007 Service Repair Manual OIL FILTER BRACKET LU-29 < ON-VEHICLE REPAIR >[K9K] C D E F G H I J K L MA LU N P O ON-VEHICLE REPAIR OIL FILTER BRACKET Exploded ViewINFOID:0000000001381541 Removal and InstallationINFOID:00000000013

Page 4237 of 5883

NISSAN TIIDA 2007 Service Repair Manual LU-30 < ON-VEHICLE REPAIR >[K9K] OIL COOLER OIL COOLER Exploded ViewINFOID:0000000001381543 Removal and InstallationINFOID:0000000001381544 CAUTION:  Be careful not to get burned when the engine and

Page 4238 of 5883

NISSAN TIIDA 2007 Service Repair Manual OIL COOLER LU-31 < ON-VEHICLE REPAIR >[K9K] C D E F G H I J K L MA LU N P O 9. Disconnect oil pressure switch electrical connector. 10. Remove the oil cooler connecting stud. 11. Remove oil cooler. IN

Page 4239 of 5883

NISSAN TIIDA 2007 Service Repair Manual LU-32 < ON-VEHICLE REPAIR >[K9K] OIL PUMP OIL PUMP Exploded ViewINFOID:0000000001381546 Removal and InstallationINFOID:0000000001381547 REMOVAL 1. Remove the battery negative cable. 2. Remove the engi

Page 4240 of 5883

NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS) LU-33 < SERVICE DATA AND SPECIFICATIONS (SDS) [K9K] C D E F G H I J K L MA LU N P O SERVICE DATA AND SPECIFICATIONS (SDS) SERVICE DATA AND SPECIFICATIONS (SDS) Pe
