CO-64
< ON-VEHICLE REPAIR >[K9K]
COOLING FAN
COOLING FAN
Exploded ViewINFOID:0000000001381594
Removal and InstallationINFOID:0000000001381595
REMOVAL
1. Remove engine undercover using power tool.
2. Drain engine coolant. Refer to CO-58, "
Draining".
3. Remove air duct (inlet). Refer to EM-269, "
Exploded View".
4. Disconnect reservoir tank hoses and remove reservoir tank.
5. Remove radiator hose (upper). Refer to CO-62, "
Exploded View".
6. Disconnect harness connector for cooling fan control module and fan motor, and move harness aside.
7. Remove cooling fan assembly.
CAUTION:
Be careful not to damage or scratch on radiator core.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Only use genuine parts for fan shroud bolt and observe the specified torque (to prevent radiator from
being damaged).
NOTE:
Cooling fan is controlled by ECM. For details, refer to CO-52, "
EngineCoolingSystem".
1. Fan shroud 2. Cooling fan control module 3. Fan motor
4. Cooling fan
A. Reverse screw
: Vehicle front
ALBIA0424GB
Page 546 of 5883
COOLING FAN
CO-65
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
CO
N
P O
Disassembly and AssemblyINFOID:0000000001381596
DISASSEMBLY
1. Remove cooling fan control module from fan shroud.
CAUTION:
Handle carefully to avoid dropping and shocks.
2. Remove cooling fan mounting nut, and then remove the cooling fan.
CAUTION:
Reverse nut is used for the fan attachment. When removing or attaching, turn the nut the opposite
direction from a normal nut.
3. Remove fan motor.
ASSEMBLY
Assembly is in the reverse order of disassembly.
Apply thread locking sealant on fan motor shaft.
InspectionINFOID:0000000001381597
INSPECTION AFTER DISASSEMBLY
Cooling Fan
Inspect cooling fan for crack or unusual bend.
If anything is found, replace cooling fan.
Page 547 of 5883
![NISSAN TIIDA 2007 Service Repair Manual CO-66
< ON-VEHICLE REPAIR >[K9K]
WATER PUMP
WATER PUMP
Exploded ViewINFOID:0000000001381598
Removal and InstallationINFOID:0000000001381599
WARNING:
Never remove the radiator cap when the engine is ho NISSAN TIIDA 2007 Service Repair Manual CO-66
< ON-VEHICLE REPAIR >[K9K]
WATER PUMP
WATER PUMP
Exploded ViewINFOID:0000000001381598
Removal and InstallationINFOID:0000000001381599
WARNING:
Never remove the radiator cap when the engine is ho](/manual-img/5/57395/w960_57395-546.png)
CO-66
< ON-VEHICLE REPAIR >[K9K]
WATER PUMP
WATER PUMP
Exploded ViewINFOID:0000000001381598
Removal and InstallationINFOID:0000000001381599
WARNING:
Never remove the radiator cap when the engine is hot. Serious burns could occur from high pressure
coolant escaping from the radiator.
REMOVAL
1. Remove the following parts.
Battery ground cable
Engine undercover
RH front wheel
2. Remove fender protector RH. Refer to EXT-22, "
Removal and Installation".
3. Drain engine coolant. Refer to CO-58, "
Draining".
CAUTION:
Perform when engine is cold.
4. Remove drive belt. Refer to EM-263, "
Removal and Installation".
5. Remove timing belt and inner cover. Refer to EM-291, "
Removal and Installation".
6. Remove the water pump.
Coolant will leak from the cylinder block, so have a receptacle ready below.
CAUTION:
Handle the water pump vane so that it does not contact any other parts.
Water pump cannot be disassembled and should be replaced as a unit.
INSTALLATION
Installation is in the reverse order of removal.
InspectionINFOID:0000000001381600
INSPECTION AFTER REMOVAL
1. Water pump 2. Gasket 3. Cylinder block
E1BIA0026GB
Page 548 of 5883
WATER PUMP
CO-67
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
CO
N
P O
Visually make sure there is no significant dirt or rusting on the
water pump body and vane.
Make sure there is no looseness in the vane shaft, and that it turns
smoothly when rotated by hand.
If there are any defects, replace the water pump assembly.
INSPECTION AFTER INSTALLATION
Check for engine coolant leaks using suitable tools. Refer to CO-58, "Inspection".
MBIB0546E
Page 549 of 5883
![NISSAN TIIDA 2007 Service Repair Manual CO-68
< ON-VEHICLE REPAIR >[K9K]
WATER OUTLET AND THERMOSTAT ASSEMBLY
WATER OUTLET AND THERMOSTAT ASSEMBLY
Exploded ViewINFOID:0000000001381601
Removal and InstallationINFOID:0000000001381602
REMOVAL
NISSAN TIIDA 2007 Service Repair Manual CO-68
< ON-VEHICLE REPAIR >[K9K]
WATER OUTLET AND THERMOSTAT ASSEMBLY
WATER OUTLET AND THERMOSTAT ASSEMBLY
Exploded ViewINFOID:0000000001381601
Removal and InstallationINFOID:0000000001381602
REMOVAL](/manual-img/5/57395/w960_57395-548.png)
CO-68
< ON-VEHICLE REPAIR >[K9K]
WATER OUTLET AND THERMOSTAT ASSEMBLY
WATER OUTLET AND THERMOSTAT ASSEMBLY
Exploded ViewINFOID:0000000001381601
Removal and InstallationINFOID:0000000001381602
REMOVAL
1. Remove battery.
2. Remove engine undercover using power tool.
3. Drain engine coolant. Refer to CO-58, "
Draining".
CAUTION:
Perform when engine is cold.
4. Remove engine cover.
5. Remove air cleaner and air duct assembly. Refer to EM-269, "
Removal and Installation".
6. Remove rear engine slinger. Refer to EM-314, "
Exploded View".
7. Remove vacuum hose.
8. Remove vacuum pump. Refer to EM-280, "
Removal and Installation".
9. Remove radiator upper hose. Refer to CO-62, "
Exploded View".
10. Remove heater hose.
11. Disconnect reservoir tank hose.
12. Remove water outlet.
INSTALLATION
Installation is in the reverse order of removal.
InspectionINFOID:0000000001381603
INSPECTION AFTER REMOVAL
1. O-ring 2. EGR cooler cover 3. Clamp
4. Water pipe 5. Heater hose 6. Clamp
7. Engine coolant temperature sensor 8. O-ring 9. Lock plate
10. Clamp 11. Gasket 12. Water outlet and thermostat assembly
13. Air relief plug
A. To EGR volume control valve housing B. To radiator hose (upper) C. To heater core
E1BIA0027GB
Page 550 of 5883
WATER OUTLET AND THERMOSTAT ASSEMBLY
CO-69
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
CO
N
P O
Place a thread so that it is caught in the valves of the thermostat.
Immerse fully in a container filled with water. Heat while stirring.
(The example shows the thermostat.)
The valve opening temperature is the temperature at which the
valve opens and falls from the thread.
Continue heating. Check the full-open lift amount.
After checking the full-open lift amount, lower the water tempera-
ture and check the valve closing temperature.
If the measured value is out of the standard value or unusual valve
seating condition is found, replace water inlet and thermostat
assembly.
INSPECTION AFTER INSTALLATION
Check for engine coolant leaks using suitable tools. Refer to CO-58, "Inspection".
E1BIA0038ZZ
Temperature °C (°F)
Start of opening 89 (192)
End of opening 97 - 101 (207 - 214)
Page 551 of 5883
CO-70
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Periodical Maintenance SpecificationINFOID:0000000001381604
ENGINE COOLANT CAPACITY (APPROXIMATE)
Unit: (Imp qt)
RadiatorINFOID:0000000001381605
Unit: kPa (kg/cm2, psi, bar)
ThermostatINFOID:0000000001381606
Unit: °C (°F)
Engine coolant capacity [With reservoir tank (“MAX” level)] 7.0 (6-1/8)
Reservoir tank engine coolant capacity (At “MAX” level) 0.8 (3/4)
Reservoir tank cap relief pressure 130 - 150 (1.33 - 1.53, 18.9 - 21.8, 1.3 - 1.5)
Leakage testing pressure 10 (0.10, 1.5, 0.1)
Temperature of start opening 89 (192)
Temperature of end opening 97 - 101 (207 - 214)
Page 552 of 5883

DEF-1
DRIVER CONTROLS
C
D
E
F
G
H
I
J
K
M
SECTION DEF
A
B
DEF
N
O
P
CONTENTS
DEFOGGER
BASIC INSPECTION ....................................3
DIAGNOSIS AND REPAIR WORKFLOW ..........3
Work Flow .................................................................3
FUNCTION DIAGNOSIS ...............................6
REAR WINDOW DEFOGGER SYSTEM .............6
System Diagram ........................................................6
System Description ...................................................6
Component Parts Location ........................................7
Component Description .............................................7
DIAGNOSIS SYSTEM (BCM) .............................9
COMMON ITEM ...........................................................9
COMMON ITEM : CONSULT-III Function (BCM -
COMMON ITEM) .......................................................
9
REAR WINDOW DEFOGGER .....................................9
REAR WINDOW DEFOGGER : CONSULT-III
Function (BCM - REAR DEFOGGER) ......................
9
CAN COMMUNICATION ....................................10
System Description .................................................10
COMPONENT DIAGNOSIS .........................11
REAR WINDOW DEFOGGER SWITCH ............11
Description ..............................................................11
Component Function Check ....................................11
Diagnosis Procedure ...............................................11
REAR WINDOW DEFOGGER RELAY ..............12
Description ..............................................................12
Component Function Check ....................................12
Diagnosis Procedure ...............................................12
Component Inspection ............................................13
REAR WINDOW DEFOGGER POWER SUP-
PLY AND GROUND CIRCUIT ............................
14
Description ..............................................................14
Component Function Check ....................................14
Diagnosis Procedure ...............................................14
Component Inspection .............................................15
DRIVER SIDE DOOR MIRROR DEFOGGER ...16
Description ...............................................................16
Component Function Check ....................................16
Diagnosis Procedure ...............................................16
Component Inspection .............................................17
PASSENGER SIDE DOOR MIRROR DEFOG-
GER ...................................................................
18
Description ...............................................................18
Component Function Check ....................................18
Diagnosis Procedure ...............................................18
Component Inspection .............................................19
ECU DIAGNOSIS .........................................20
BCM (BODY CONTROL MODULE) .................20
Reference Value ......................................................20
Wiring Diagram ........................................................21
SYMPTOM DIAGNOSIS ..............................29
REAR WINDOW DEFOGGER AND DOOR
MIRROR DEFOGGER DO NOT OPERATE. ....
29
Diagnosis Procedure ...............................................29
REAR WINDOW DEFOGGER DOES NOT
OPERATE BUT BOTH OF DOOR MIRROR
DEFOGGER OPERATE. ...................................
30
Diagnosis Procedure ...............................................30
BOTH DOORS MIRROR DEFOGGER DON’T
OPERATE BUT REAR WINDOW DEFOG-
GER OPERATES ..............................................
31
Diagnosis Procedure ...............................................31
DRIVER SIDE DOOR MIRROR DEFOGGER
DOES NOT OPERATE. .....................................
32
Diagnosis Procedure ...............................................32
