Page 4993 of 5883

NISSAN TIIDA 2007 Service Repair Manual DTC P0705 PARK/NEUTRAL POSITION (PNP) SWITCH
TM-47
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
1. Check continuity between PNP switch harness connector termi-
nals.

Page 4994 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-48
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
DTC P0710 A/T FLUID TEMPERATURE SENSOR CIRCUIT
DTC P0710 A/T FLUID TEMPERATURE SENSOR CIRCUIT
DescriptionINFOID:0000000001694291
The A/T fluid temp

TM-48
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
DTC P0710 A/T FLUID TEMPERATURE SENSOR CIRCUIT
DTC P0710 A/T FLUID TEMPERATURE SENSOR CIRCUIT
DescriptionINFOID:0000000001694291
The A/T fluid temperature sensor detects the A/T fluid temperature and sends a signal to the TCM.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001694292
Remarks: Specification data are reference values.
On Board Diagnosis LogicINFOID:0000000001694293
This is an OBD self-diagnostic item.
Diagnostic trouble code “P0710 ATF TEMP SEN/CIRC” with CONSULT-III is detected when TCM receives
an excessively low or high voltage from the sensor.
Possible CauseINFOID:0000000001694294
Harness or connector
(The sensor circuit is open or shorted.)
A/T fluid temperature sensor
DTC Confirmation ProcedureINFOID:0000000001694295
CAUTION:
Always drive vehicle at a safe speed.
If performing this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait at
least 10 seconds before continuing.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON and select “DATA MONITOR” mode for “A/T” with CONSULT-III.
2. Touch “START”.
3. Start engine and maintain the following conditions for at least 10 minutes (Total). (It is not necessary to
maintain continuously.)
ENGINE SPEED: 450 rpm or more
VEHICLE SPEED: 10 km/h (6 MPH) or more
THROTTLE POSI: More than 1.0/8
SLCT LVR POSI: “D” position
4. If the check result is NG, go to TM-48, "
Diagnosis Procedure".
WITH GST
Follow the procedure “With CONSULT-III”.
Diagnosis ProcedureINFOID:0000000001694297
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Start engine.
2. Select “TCM INPUT SIGNALS” in “DATA MONITOR” mode for “A/T” with CONSULT-III.
3. Read out the value of “FLUID TEMP SE”.
Item name Condition Display value (Approx.)
FLUID TEMP SEWhen A/T fluid temperature is 20°C (68°F). 1.5V
When A/T fluid temperature is 80°C (176°F). 0.5V
Item name ConditionDisplay value
(Approx.)
FLUID TEMP
SEWhen A/T fluid temperature is 20°C (68°F). 1.5V
When A/T fluid temperature is 80°C (176°F). 0.5V

Page 4995 of 5883

NISSAN TIIDA 2007 Service Repair Manual DTC P0710 A/T FLUID TEMPERATURE SENSOR CIRCUIT
TM-49
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Without CONSULT-III
1. Start engine.
2. Check voltage TCM connector

Page 4996 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-50
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
DTC P0710 A/T FLUID TEMPERATURE SENSOR CIRCUIT
OK or NG
OK >> GO TO 5.
NG >> Repair open circuit or short to ground or short to power in harness or

Page 4997 of 5883

NISSAN TIIDA 2007 Service Repair Manual DTC P0710 A/T FLUID TEMPERATURE SENSOR CIRCUIT
TM-51
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Remove oil pan. Refer to TM-191, "Control Valve Assembly and
Accum

Page 4998 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-52
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
DTC P0720 VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR)
DTC P0720 VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR)
DescriptionINFOID:0000000001694299

TM-52
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
DTC P0720 VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR)
DTC P0720 VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR)
DescriptionINFOID:0000000001694299
The revolution sensor detects the revolution of the idler gear parking pawl lock gear and emits a pulse signal.
The pulse signal is sent to the TCM which converts it into vehicle speed.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001694300
Remarks: Specification data are reference values.
On Board Diagnosis LogicINFOID:0000000001694301
This is an OBD self-diagnostic item.
Diagnostic trouble code “P0720 VHCL SPEED SEN-AT” with CONSULT-III or 1st judgement flicker without
CONSULT-III is detected when TCM does not receive the proper voltage signal from the sensor.
Possible CauseINFOID:0000000001694302
Harness or connector
(The sensor circuit is open or shorted.)
Revolution sensor
DTC Confirmation ProcedureINFOID:0000000001694303
CAUTION:
Always drive vehicle at a safe speed.
Be careful not to rev engine into the red zone on the tachometer.
If performing this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait at
least 10 seconds before continuing.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON and select “DATA MONITOR” mode for “A/T” with CONSULT-III.
2. Touch “START”.
3. Drive vehicle and check for an increase of “VHCL/S SE-MTR” value.
If the check result is NG, go to TM-53, "
Diagnosis Procedure".
If the check result is OK, go to following step.
4. Select “DATA MONITOR” mode for “A/T” with CONSULT-III.
5. Touch “START”.
6. Start engine and maintain the following conditions for at least 5 consecutive seconds.
VEHICLE SPEED: 30 km/h (19 MPH) or more
THROTTLE POSI: More than 1.0/8
SLCT LVR POSI: “D” position
Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving
conditions required for this test.
If the check result is NG, go to TM-53, "
Diagnosis Procedure".
If the check result is OK, go to following step.
7. Maintain the following conditions for at least 5 consecutive seconds.
ENGINE SPEED: 3,500 rpm or more
THROTTLE POSI: More than 1.0/8
SLCT LVR POSI: “D” position
Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving
conditions required for this test.
WITH GST
Follow the procedure “WITH CONSULT-III”.
WITHOUT CONSULT-III
1. Start engine.
Item name Condition Display value
VHCL/S SE-A/T During driving Approximately matches the speedometer reading.

Page 4999 of 5883

NISSAN TIIDA 2007 Service Repair Manual DTC P0720 VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR)
TM-53
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2. Drive vehicle under the following conditions for more th

Page 5000 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-54
< COMPONENT DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
DTC P0720 VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR)
4. Check voltage between revolution sensor harness connector
terminals.
5. Check voltage be
