Page 1897 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-548
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
P1225 TP SENSOR
3. Check if foreign matter is caught between the throttle valve (1)
and the housing.
Is the inspection result normal?
YES >> G

Page 1898 of 5883

NISSAN TIIDA 2007 Service Repair Manual P1226 TP SENSOR
EC-549
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1226 TP SENSOR
DescriptionINFOID:0000000001693369
Electric throttle control actuator consists

Page 1899 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-550
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
P1226 TP SENSOR
3. Check if foreign matter is caught between the throttle valve (1)
and the housing.
Is the inspection result normal?
YES >> G

Page 1900 of 5883

NISSAN TIIDA 2007 Service Repair Manual P1229 SENSOR POWER SUPPLY
EC-551
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1229 SENSOR POWER SUPPLY
DTC LogicINFOID:0000000001693373
DTC DETECTION LOGIC
DTC C

Page 1901 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-552
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
P1229 SENSOR POWER SUPPLY
3.CHECK SENSOR POWER SUPPLY CIRCUITS
Check harness for short to power and short to ground, between the following ter

Page 1902 of 5883

NISSAN TIIDA 2007 Service Repair Manual P1564 ASCD STEERING SWITCH
EC-553
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1564 ASCD STEERING SWITCH
DescriptionINFOID:0000000001693375
ASCD steering switch

P1564 ASCD STEERING SWITCH
EC-553
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1564 ASCD STEERING SWITCH
DescriptionINFOID:0000000001693375
ASCD steering switch has variant values of electrical resistance for each button. ECM reads voltage variation
of switch, and determines which button is operated.
Refer to EC-424, "
System Diagram" for the ASCD function.
DTC LogicINFOID:0000000001693376
DTC DETECTION LOGIC
NOTE:
If DTC P1564 is displayed with DTC P0605, first perform the trouble diagnosis for DTC P0605. Refer to
EC-524, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Wait at least 10 seconds.
3. Press MAIN switch for at least 10 seconds, then release it and wait at least 10 seconds.
4. Press CANCEL switch for at least 10 seconds, then release it and wait at least 10 seconds.
5. Press RESUME/ACCELERATE switch for at least 10 seconds, then release it and wait at least 10 sec-
onds.
6. Press SET/COAST switch for at least 10 seconds, then release it and wait at least 10 seconds.
7. Check DTC.
Is DTC detected?
YES >> Go to EC-553, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001693377
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground Inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YS >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK ASCD STEERING SWITCH CIRCUIT
With CONSULT-III
1. Turn ignition switch ON.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
P1564 ASCD steering switch An excessively high voltage signal from the
ASCD steering switch is sent to ECM.
ECM detects that input signal from the
ASCD steering switch is out of the specified
range.
ECM detects that the ASCD steering switch
is stuck ON. Harness or connectors
(The switch circuit is open or shorted.)
ASCD steering switch
ECM

Page 1903 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-554
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
P1564 ASCD STEERING SWITCH
2. Select “MAIN SW”, “CANCEL SW”, “RESUME/ACC SW” and “SET SW” in “DATA MONITOR” mode with
CONS

Page 1904 of 5883

NISSAN TIIDA 2007 Service Repair Manual P1564 ASCD STEERING SWITCH
EC-555
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
1. Check the continuity between ECM harness connector and combination switch.
2. Al

Load next 8 pages
