NISSAN TIIDA 2007 Service Repair Manual SYSTEM SYMPTOM
TM-439
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
OthersVehicle braked by
gear change from D
3
to D
4.ON vehicle 1. A/T fluid levelXX-XX, "*****"OFF

Page 5386 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-440
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
OD OFF Indicator Lamp Does Not Come On
INFOID:0000000001714346
SYMPTOM:
OD OFF indicator lamp does not come on for about 2 seconds wh

Page 5387 of 5883

NISSAN TIIDA 2007 Service Repair Manual SYSTEM SYMPTOM
TM-441
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
.
3. Turn ignition switch OFF.
4. Check voltage between TCM connector terminals and ground.
OK or NG

Page 5388 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-442
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
Check again. Refer to TM-180, "Check Before Engine Is Started".
OK or NG
OK >>INSPECTION END
NG >> GO TO 7.
7.CHECK TCM
1. Check TCM

TM-442
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
Check again. Refer to TM-180, "Check Before Engine Is Started".
OK or NG
OK >>INSPECTION END
NG >> GO TO 7.
7.CHECK TCM
1. Check TCM input/output. Refer to XX-XX, "*****"
(Type 1) or TM-422, "Reference Value" (Type 2).
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Engine Cannot Be Started in "P" and "N" PositionINFOID:0000000001714347
SYMPTOM:
Engine cannot be started with selector lever in “P” or “N” position.
Engine can be started with selector lever in “D”, “2”, “1” or “R” position.
1.CHECK SELF-DIAGNOSIS RESULTS
Perform self-diagnosis. Refer to XX-XX, "*****"
or XX-XX, "*****".
Is any malfunction detected by self-diagnostic results?
YES >> Check the malfunctioning system. Refer to XX-XX, "*****" or XX-XX, "*****".
NO >> GO TO 2.
2.CHECK PNP SWITCH
Check continuity between PNP switch harness connector terminals.
OK or NG
OK >> GO TO 4.
NG >> GO TO 3.
3.CHECK CONTROL CABLE ADJUSTMENT
Check PNP switch again with control cable disconnected from manual shaft of A/T assembly. Refer to test
group 2.
OK or NG
OK >> Adjust control cable. Refer to TM-204, "Adjustment of A/T Position".
NG >> 1. Check PNP switch (Refer to test group 2.) again after adjusting PNP switch (Refer to TM-46
).
- If OK, INSPECTION END
- If NG, repair or replace PNP switch. Refer to TM-195, "
Park/Neutral Position (PNP) Switch".
4.CHECK STARTING SYSTEM
Check starting system. Refer to STR-6, "
System Description".
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
In "P" Position, Vehicle Moves Forward or Backward When PushedINFOID:0000000001714348
SYMPTOM:
Vehicle moves when it is pushed forward or backward with selector lever in “P” position.
1.CHECK A/T POSITION
Check A/T position. Refer to TM-204, "
Checking of A/T Position".
Selector lever position Connector terminal Continuity
“P”, “N”
F25 1 - 2Ye s
Other positions No
SCIA5606E

Page 5389 of 5883

NISSAN TIIDA 2007 Service Repair Manual SYSTEM SYMPTOM
TM-443
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
OK or NG
OK >> GO TO 2.
NG >> Adjust A/T position. Refer to TM-204, "
Adjustment of A/T Position".
2.

Page 5390 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-444
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
1. Check TCM input/output signals. Refer to TM-22, "Input/Output Signal of TCM".
2. If NG, recheck TCM pin terminals for damage or lo

TM-444
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
1. Check TCM input/output signals. Refer to TM-22, "Input/Output Signal of TCM".
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Large Shock "N" → "R" PositionINFOID:0000000001714350
SYMPTOM:
There is a large shock when changing from “N” to “R” position.
1.CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis. Refer to TM-35, "
CONSULT-III Function (TRANSMISSION)" or TM-38, "Diagnosis
Procedure without CONSULT-III".
Is any malfunction detected by self-diagnostic results?
YES >> Check the malfunctioning system. Refer to TM-38, "Diagnosis Procedure without CONSULT-III".
NO >> GO TO 2.
2.CHECK LINE PRESSURE
Check line pressure at idle with selector lever in “D” position. Refer to TM-178, "
Inspection and Judgment".
OK or NG
OK >> GO TO 4.
NG >> GO TO 3.
3.DETECT MALFUNCTIONING ITEM
1. Remove control valve assembly. Refer to TM-191, "
Control Valve Assembly and Accumulators".
2. Check the following items:
- Valves to control line pressure (Pressure regulator valve, pressure modifier valve, pilot valve and pilot fil-
ter)
- Line pressure solenoid valve
- Oil pump assembly. Refer to TM-240, "
Oil Pump".
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4.CHECK SYMPTOM
Check again. Refer to TM-181, "
Check at Idle".
OK or NG
OK >>INSPECTION END
NG >> GO TO 5.
5.CHECK TCM
1. Check TCM input/output signals. Refer to TM-22, "
Input/Output Signal of TCM".
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Vehicle Does Not Creep Backward in "R" PositionINFOID:0000000001714351
SYMPTOM:
Vehicle does not creep backward when selecting “R” position.
1.CHECK A/T FLUID LEVEL
Check A/T fluid level. Refer to TM-171, "
Checking A/T Fluid".
OK or NG
OK >> GO TO 2.
NG >> Refill ATF.

Page 5391 of 5883

NISSAN TIIDA 2007 Service Repair Manual SYSTEM SYMPTOM
TM-445
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2.CHECK LINE PRESSURE
Check line pressure at idle with selector lever in “R” position. Refer to T

SYSTEM SYMPTOM
TM-445
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2.CHECK LINE PRESSURE
Check line pressure at idle with selector lever in “R” position. Refer to TM-178, "
Inspection and Judgment".
OK or NG
OK >> GO TO 4.
NG >> GO TO 3.
3.DETECT MALFUNCTIONING ITEM
1. Remove control valve assembly. Refer to TM-191, "
Control Valve Assembly and Accumulators".
2. Check the following items:
- Valves to control line pressure (Pressure regulator valve, pressure modifier valve, pilot valve and pilot fil-
ter)
- Line pressure solenoid valve
3. Disassemble A/T. Refer to TM-222, "
Disassembly".
4. Check the following item:
- Oil pump assembly. Refer to TM-240, "
Oil Pump".
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4.CHECK STALL REVOLUTION
Check stall revolution with selector lever in “1” and “R” positions. Refer to TM-175, "
Inspection and Judgment".
OK or NG
OK >> GO TO 6.
OK in “1” position, NG in “R” position>>GO TO 5.
NG in both “1” and “R” positions>>GO TO 7.
5.DETECT MALFUNCTIONING ITEM
1. Disassemble A/T. Refer to TM-222, "
Disassembly".
2. Check the following items:
- Low & reverse brake assembly. Refer to TM-273, "
Low & Reverse Brake".
- Reverse clutch assembly. Refer to TM-258, "
Reverse Clutch".
OK or NG
OK >> GO TO 6.
NG >> Repair or replace damaged parts.
6.CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to TM-213, "
Component".
2. Check A/T fluid condition. Refer to TM-171, "
Checking A/T Fluid".
OK or NG
OK >> GO TO 8.
NG >> GO TO 7.
7.DETECT MALFUNCTIONING ITEM
1. Disassemble A/T. Refer to TM-222, "
Disassembly".
2. Check the following items:
- Reverse clutch assembly. Refer to TM-258, "
Reverse Clutch".
- High clutch assembly. Refer to TM-262, "
High Clutch".
- Low & reverse brake assembly. Refer to TM-273, "
Low & Reverse Brake".
- Forward clutch assembly. Refer to TM-267, "
Forward and Overrun Clutches".
- Overrun clutch assembly. Refer to TM-267, "
Forward and Overrun Clutches".
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
8.CHECK SYMPTOM
Check again. Refer to TM-181, "
Check at Idle".
OK or NG

Page 5392 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-446
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
OK >>INSPECTION END
NG >> GO TO 9.
9.CHECK TCM
1. Check TCM input/output signals. Refer to TM-22, "
Input/Output Signal of TCM".
2. I

TM-446
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
OK >>INSPECTION END
NG >> GO TO 9.
9.CHECK TCM
1. Check TCM input/output signals. Refer to TM-22, "
Input/Output Signal of TCM".
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Vehicle Does Not Creep Forward in "D", "2" or "1" PositionINFOID:0000000001714352
SYMPTOM:
Vehicle does not creep forward when selecting “D”, “2” or “1” position.
1.CHECK A/T FLUID LEVEL
Check A/T fluid level. Refer to TM-171, "
Checking A/T Fluid".
OK or NG
OK >> GO TO 2.
NG >> Refill ATF.
2.CHECK LINE PRESSURE
Check line pressure at idle with selector lever in “D” position. Refer to TM-178, "
Inspection and Judgment".
OK or NG
OK >> GO TO 4.
NG >> GO TO 3.
3.DETECT MALFUNCTIONING ITEM
1. Remove control valve assembly. Refer to TM-191, "
Control Valve Assembly and Accumulators".
2. Check the following items:
- Valves to control line pressure (Pressure regulator valve, pressure modifier valve, pilot valve and pilot fil-
ter)
- Line pressure solenoid valve
3. Disassemble A/T. Refer to TM-222, "
Disassembly".
4. Check the following item:
- Oil pump assembly. Refer to TM-240, "
Oil Pump".
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4.CHECK STALL REVOLUTION
Check stall revolution with selector lever in “D” position. Refer to TM-175, "
Inspection and Judgment".
OK or NG
OK >> GO TO 6.
NG >> GO TO 5.
5.DETECT MALFUNCTIONING ITEM
1. Disassemble A/T. Refer to TM-222, "
Disassembly".
2. Check the following items:
- Oil pump assembly. Refer to TM-240, "
Oil Pump".
- Forward clutch assembly. Refer to TM-267, "
Forward and Overrun Clutches".
- Forward one-way clutch. Refer to TM-278, "
Rear Internal Gear and Forward Clutch Hub".
- Low one-way clutch. Refer to TM-222, "
Disassembly".
- Torque converter. Refer to TM-222, "
Disassembly".
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
6.CHECK A/T FLUID CONDITION
