Page 649 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-60 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] POWER SUPPLY AND GROUND CIRCUIT Check continuity between Intelligent Key unit harness connector and ground. Is the inspection result norm

Page 650 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR LOCK AND UNLOCK SWITCH DLK-61 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] C D E F G H I J L MA B DLK N O P DOOR LOCK AND UNLOCK SWITCH DescriptionINFOID:0000000001396520 Transmits doo

Page 651 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-62 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] DOOR LOCK AND UNLOCK SWITCH 2.CHECK DOOR LOCK AND UNLOCK SWITCH CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect BCM connector. 3. Chec

Page 652 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR LOCK AND UNLOCK SWITCH DLK-63 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] C D E F G H I J L MA B DLK N O P 2. Check signal between BCM connector and ground. Is the inspection result n

Page 653 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-64 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] DOOR LOCK AND UNLOCK SWITCH Is the inspection result normal? YES >> Main power window and door lock/unlock switch is OK. NO >> Replace ma

Page 654 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR SWITCH DLK-65 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] C D E F G H I J L MA B DLK N O P DOOR SWITCH DRIVER SIDE DRIVER SIDE : DescriptionINFOID:0000000001396536 Detects door open/c

Page 655 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-66 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] DOOR SWITCH 1. Disconnect BCM and driver door switch connectors. 2. Check continuity between BCM connector (A) M18 terminal 29 and door s

Page 656 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR SWITCH DLK-67 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] C D E F G H I J L MA B DLK N O P PASSENGER SIDE : DescriptionINFOID:0000000001396540 Detects door open/closed condition. PASS
