TORQUE CONVERTER CLUTCH SOLENOID VALVE
TM-375
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
4.CHECK VALVE RESISTANCE
1. Turn ignition switch OFF.
2. Disconnect terminal cord assembly connector in engine room.
3. Check resistance between terminal cord assembly harness con-
nector terminal and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair or replace damaged parts.
5.CHECK DTC
Perform TM-373, "
DTC Confirmation Procedure".
OK or NG
OK >>INSPECTION END
NG >> GO TO 6.
6.CHECK TCM
1. Check TCM input/output signals. Refer to XX-XX, "*****"
.
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Component InspectionINFOID:0000000001713033
TORQUE CONVERTER CLUTCH SOLENOID VALVE
For removal, refer to XX-XX, "*****".
Resistance Check
Check resistance between terminal and ground.
Operation Check
Check solenoid valve by listening for its operating sound while
applying battery voltage to the terminal and ground.
Solenoid valve Connector Terminal Resistance (Approx.)
Torque converter clutch
solenoid valveF30 5 - Ground 5 - 20 Ω
SCIA4946E
Solenoid valve TerminalResistance (Ap-
prox.)
Torque converter
clutch solenoid
valve5 Ground 5 - 20 Ω
SCIA2063E
SCIA2066E
Page 5322 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TM-376
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POW-
ER SOURCE)
BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM
POWER SOURCE NISSAN TIIDA 2007 Service Repair Manual TM-376
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POW-
ER SOURCE)
BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM
POWER SOURCE](/manual-img/5/57395/w960_57395-5321.png)
TM-376
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POW-
ER SOURCE)
BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM
POWER SOURCE)
DescriptionINFOID:0000000001713034
The A/T fluid temperature sensor detects the A/T fluid temperature and sends the signal to the TCM.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001713035
Remarks: Specification data are reference values.
On Board Diagnosis LogicINFOID:0000000001713036
Diagnostic trouble code “BATT/FLUID TEMP SEN” with CONSULT-III or 8th judgement flicker without CON-
SULT-III is detected when TCM receives an excessively low or high voltage from the sensor.
Possible CauseINFOID:0000000001713037
Harness or connector
(Sensor circuit is open or shorted.)
A/T fluid temperature sensor
DTC Confirmation ProcedureINFOID:0000000001713038
CAUTION:
Always drive vehicle at a safe speed.
If performing this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait at
least 10 seconds before continuing.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Start engine.
2. Select “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Touch “START”.
4. Drive vehicle under the following conditions.
SLCT LVR POSI: “D” position
VEHICLE SPEED: Higher than 20 km/h (12 MPH)
5. If the check result is NG, go to TM-376, "
Diagnosis Procedure".
WITHOUT CONSULT-III
1. Start engine.
2. Drive vehicle under the following conditions.
Selector lever position: “D” position
Vehicle speed: Higher than 20 km/h (12 MPH)
3. Perform self-diagnosis. Refer to TM-350, "
Diagnosis Procedure without CONSULT-III".
4. If the check result is NG, go to TM-376, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001713040
1.CHECK TCM POWER SOURCE
1. Turn ignition switch ON. (Do not start engine.)
Item name Condition Display value (Approx.)
FLUID TEMP SE When A/T fluid temperature is 20°C (68°F). 1.5V
When A/T fluid temperature is 80°C (176°F). 0.5V
Page 5323 of 5883
![NISSAN TIIDA 2007 Service Repair Manual BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POW-
ER SOURCE)
TM-377
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2. Check voltage between TCM connector NISSAN TIIDA 2007 Service Repair Manual BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POW-
ER SOURCE)
TM-377
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2. Check voltage between TCM connector](/manual-img/5/57395/w960_57395-5322.png)
BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POW-
ER SOURCE)
TM-377
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2. Check voltage between TCM connector terminal and ground.
3. Turn ignition switch OFF.
4. Check voltage between TCM connector terminal and ground.
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2.DETECT MALFUNCTIONING ITEM
Check the following items:
Harness for short or open between ignition switch and TCM terminals 10, 19
Harness for short or open between battery and TCM terminal 28
10A fuse (No.13, located in the fuse block) and 10A fuse (No.49, located in the IPDM E/R)
Ignition switch.
OK or NG
OK >> GO TO 9.
NG >> Repair or replace damaged parts.
3.CHECK INPUT SIGNAL OF A/T FLUID TEMPERATURE SENSOR
With CONSULT-III
1. Start engine.
2. Select “TCM INPUT SIGNALS” in “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Read out the value of “FLUID TEMP SE”.
Without CONSULT-III
1. Start engine.
Item Connector TerminalJudgement standard (Ap-
prox.)
Power supply E3110 Battery voltage
19 Battery voltage
Power supply
(memory back-up)E32 28 Battery voltage
SCIA2656E
Item Connector Terminal Judgement standard (Approx.)
Power supply E3110 0V
19 0V
Power supply
(memory back-up)E32 28 Battery voltage
SCIA2657E
Item name ConditionDisplay value
(Approx.)
FLUID TEMP
SEWhen A/T fluid temperature is 20°C (68°F). 1.5V
When A/T fluid temperature is 80°C (176°F). 0.5V
Page 5324 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TM-378
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POW-
ER SOURCE)
2. Check voltage TCM connector terminals while warming up A/T.
OK or NG NISSAN TIIDA 2007 Service Repair Manual TM-378
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POW-
ER SOURCE)
2. Check voltage TCM connector terminals while warming up A/T.
OK or NG](/manual-img/5/57395/w960_57395-5323.png)
TM-378
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POW-
ER SOURCE)
2. Check voltage TCM connector terminals while warming up A/T.
OK or NG
OK >> GO TO 9.
NG >> GO TO 4.
4.DETECT MALFUNCTIONING ITEM
Check the following items:
Harness for short or open between TCM, ECM and terminal cord assembly
Ground circuit for ECM.
OK or NG
OK >> GO TO 5.
NG >> Repair or replace damaged parts.
5. CHECK FLUID TEMPERATURE SENSOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the TCM connector.
3. Check resistance between TCM connector terminals.
OK or NG
OK >> GO TO 9.
NG >> GO TO 6.
6. CHECK HARNESS BETWEEN TCM AND TERMINAL CORD ASSEMBLY HARNESS CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect terminal cord assembly harness connector and TCM connector.
3. Check continuity between terminal cord assembly harness con-
nector terminals and TCM connector terminals.
4. If OK, check harness for short to ground and short to power.
5. If OK, check continuity between ground and transaxle assembly.
6. Reinstall any part removed.
OK or NG
OK >> GO TO 7.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
Item Connector Terminal ConditionJudgement
standard
(Approx.)
A/T fluid
temperature
sensorE32 47 - 42When A/T fluid tempera-
ture is 20°C (68°F).1.5V
When A/T fluid tempera-
ture is 80°C (176°F).0.5V
SCIA2658E
Item Connector TerminalTe m p e r a -
ture °C (°F)Resistance
(Approx.)
A/T fluid
temperature
sensorE32 47 - 4220 (68) 2.5 kΩ
80 (176) 0.3 kΩ
SCIA4947E
Item Connector Terminal Continuity
TCM E32 42
Ye s
Terminal cord assembly
harness connectorF30 7
TCM E32 47
Ye s
Terminal cord assembly
harness connectorF30 6
SCIA2660E
Page 5325 of 5883
![NISSAN TIIDA 2007 Service Repair Manual BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POW-
ER SOURCE)
TM-379
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
7.CHECK A/T FLUID TEMPERATURE SENSOR WI NISSAN TIIDA 2007 Service Repair Manual BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POW-
ER SOURCE)
TM-379
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
7.CHECK A/T FLUID TEMPERATURE SENSOR WI](/manual-img/5/57395/w960_57395-5324.png)
BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POW-
ER SOURCE)
TM-379
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
7.CHECK A/T FLUID TEMPERATURE SENSOR WITH TERMINAL CORD ASSEMBLY
1. Turn ignition switch OFF.
2. Disconnect terminal cord assembly connector in engine room.
3. Check resistance between terminal cord assembly harness con-
nector terminals.
4. Reinstall any part removed.
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
8.DETECT MALFUNCTIONING ITEM
1. Remove oil pan. Refer to XX-XX, "*****"
.
2. Check the following items:
- A/T fluid temperature sensor
Check resistance between terminal cord assembly harness con-
nector terminals while changing temperature as shown.
- Harness of terminal cord assembly for short or open
OK or NG
OK >> GO TO 9.
NG >> Repair or replace damaged parts.
9.CHECK DTC
Perform TM-376, "
DTC Confirmation Procedure".
OK or NG
OK >>INSPECTION END
NG >> GO TO 10.
10.CHECK TCM
1. Check TCM input/output signal. Refer to XX-XX, "*****"
.
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Component InspectionINFOID:0000000001713041
A/T FLUID TEMPERATURE SENSOR
Temperature °C (°F) Resistance (Approx.)
20 (68) 2.5 kΩ
80 (176) 0.3 kΩ
SCIA4948E
Temperature [°C (°F)] Resistance (Approx.)
20 (68) 2.5 kΩ
80 (176) 0.3 kΩ
SAT298F
Page 5326 of 5883
TM-380
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POW-
ER SOURCE)
For removal, refer to XX-XX, "*****".
Check resistance between terminal cord assembly harness con-
nector terminals while changing temperature as shown.
Temperature [°C (°F)] Resistance (Approx.)
20 (68) 2.5 kΩ
80 (176) 0.3 kΩ
SAT298F
Page 5327 of 5883
![NISSAN TIIDA 2007 Service Repair Manual ENGINE SPEED SIGNAL
TM-381
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
ENGINE SPEED SIGNAL
DescriptionINFOID:0000000001713042
The engine speed signal is sent from th NISSAN TIIDA 2007 Service Repair Manual ENGINE SPEED SIGNAL
TM-381
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
ENGINE SPEED SIGNAL
DescriptionINFOID:0000000001713042
The engine speed signal is sent from th](/manual-img/5/57395/w960_57395-5326.png)
ENGINE SPEED SIGNAL
TM-381
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
ENGINE SPEED SIGNAL
DescriptionINFOID:0000000001713042
The engine speed signal is sent from the ECM to the TCM.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001713043
Remarks: Specification data are reference values.
On Board Diagnosis LogicINFOID:0000000001713044
Diagnostic trouble code “ENGINE SPEED SIG” with CONSULT-III or 9th judgement flicker without CONSULT-
III is detected when TCM does not receive the proper voltage signal from ECM.
Possible CauseINFOID:0000000001713045
Harness or connector
(Circuit is open or shorted.)
DTC Confirmation ProcedureINFOID:0000000001713046
CAUTION:
Always drive vehicle at a safe speed.
If performing this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait at
least 10 seconds before continuing.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON and select “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
2. Touch “START”.
3. Start engine and maintain the following conditions for at least 10 consecutive seconds.
VEHICLE SPEED: 10 km/h (6 MPH) or more
THROTTLE POSI: More than 1.0/8
SLCT LVR POSI: “D” position
4. If the check result is NG, go to TM-381, "
Diagnosis Procedure".
WITHOUT CONSULT-III
1. Start engine.
2. Drive vehicle under the following conditions for more than 10 seconds.
Selector lever position: “D” position
Vehicle speed: Higher than 10 km/h (6 MPH)
Throttle position: Greater than 1.0/8 of the full throttle position
3. Perform self-diagnosis. Refer to TM-350, "
Diagnosis Procedure without CONSULT-III".
4. If the check result is NG, go to TM-381, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001713048
1.CHECK DTC WITH ECM
Check DTC with CONSULT-III “ENGINE”.
Turn ignition switch ON and select “SELF-DIAGNOSTIC RESULTS” mode for “ENGINE” with CONSULT-III.
Refer to XX-XX, "*****"
.
OK or NG
OK >> GO TO 2.
NG >> Check ignition signal circuit for engine control. Refer to XX-XX, "*****"
.
2.CHECK INPUT SIGNAL
With CONSULT-III
1. Start engine.
Item name Condition Display value
ENGINE SPEED Engine running Approximately matches the tachometer reading.
Page 5328 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TM-382
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
ENGINE SPEED SIGNAL
2. Select “TCM INPUT SIGNALS” in “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-II.
3. Read out the value of NISSAN TIIDA 2007 Service Repair Manual TM-382
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
ENGINE SPEED SIGNAL
2. Select “TCM INPUT SIGNALS” in “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-II.
3. Read out the value of](/manual-img/5/57395/w960_57395-5327.png)
TM-382
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
ENGINE SPEED SIGNAL
2. Select “TCM INPUT SIGNALS” in “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-II.
3. Read out the value of “ENGINE SPEED”. Check engine speed changes according to throttle position.
Without CONSULT-III
1. Start engine.
2. Check voltage between TCM harness connector terminal and
ground.
OK or NG
OK >> GO TO 4.
NG >> GO TO 3.
3. CHECK HARNESS BETWEEN TCM AND ECM
1. Turn ignition switch OFF.
2. Disconnect ECM connector and TCM connector.
3. Check continuity between ECM connector and TCM connector.
4. If OK, check harness for short to ground and short to power.
5. If OK, check continuity between body ground and transaxle
assembly.
6. Reinstall any part removed.
OK or NG
OK >> GO TO 4.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK DTC
Perform TM-381, "
DTC Confirmation Procedure".
OK or NG
OK >>INSPECTION END
NG >> GO TO 5.
5.CHECK TCM
1. Check TCM input/output signal. Refer to XX-XX, "*****"
.
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Item name Condition Display value
ENGINE
SPEED Engine runningApproximately matches the ta-
chometer reading.
ItemConnec-
torTerminal ConditionJudgement standard (Ap-
prox.)
Engine
speed signalE3239 -
Ground
and Refer to XX-XX, "*****"
.
SCIA3265E
Item Connector Terminal Continuity
TCM E32 39
Ye s
ECM F10 13
SCIA7173E
