Page 5633 of 5883

NISSAN TIIDA 2007 Service Repair Manual TRANSAXLE ASSEMBLY TM-687 < DISASSEMBLY AND ASSEMBLY >[6MT: RS6F94R] C E F G H I J K L MA B TM N O P FINAL DRIVE 1. Reverse fork rod 2. Selector 3. Retaining pin 4. 5th-6th shift fork 5. 3rd-4th shif

Page 5634 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-688 < DISASSEMBLY AND ASSEMBLY >[6MT: RS6F94R] TRANSAXLE ASSEMBLY Disassembly INFOID:0000000001381646 1. Drain the oil from the transaxle. Refer to TM-672, "Draining". 2. Remove filler plug and gas

Page 5635 of 5883

NISSAN TIIDA 2007 Service Repair Manual TRANSAXLE ASSEMBLY TM-689 < DISASSEMBLY AND ASSEMBLY >[6MT: RS6F94R] C E F G H I J K L MA B TM N O P 5. Remove the bolts as shown. 6. Remove reverse idler shaft bolt and seal washer. 7. Remove transax

Page 5636 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-690 < DISASSEMBLY AND ASSEMBLY >[6MT: RS6F94R] TRANSAXLE ASSEMBLY 11. Remove retaining pin from 5th-6th shift fork using a pin punch. 12. Remove 3rd-4th and 5th-6th fork rod (1) assembly according

Page 5637 of 5883

NISSAN TIIDA 2007 Service Repair Manual TRANSAXLE ASSEMBLY TM-691 < DISASSEMBLY AND ASSEMBLY >[6MT: RS6F94R] C E F G H I J K L MA B TM N O P 18. Remove differential side oil seals (1) from clutch housing and transaxle case using suitable to

Page 5638 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-692 < DISASSEMBLY AND ASSEMBLY >[6MT: RS6F94R] TRANSAXLE ASSEMBLY 24. Remove selector lever oil seal and bushings from transaxle case using suitable tool. 25. Remove oil gutter (1) from transaxle c

Page 5639 of 5883

NISSAN TIIDA 2007 Service Repair Manual TRANSAXLE ASSEMBLY TM-693 < DISASSEMBLY AND ASSEMBLY >[6MT: RS6F94R] C E F G H I J K L MA B TM N O P 29. Remove snap ring (1) and oil channel (2) from transaxle case. 30. Remove input shaft oil seal (

Page 5640 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-694 < DISASSEMBLY AND ASSEMBLY >[6MT: RS6F94R] TRANSAXLE ASSEMBLY 34. Remove pinion gear (1) and pinion shaft (2) from clutch housing. AssemblyINFOID:0000000001381647 1. Install pinion gear (1) and
