NISSAN TIIDA 2007 Service Repair Manual SYSTEM SYMPTOM
TM-135
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Slips/Will Not EngageRaces extremely fast
or slips in changing
from D
3 to D2 when
depressing acce

Page 5082 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-136
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
SYSTEM SYMPTOM
OthersTransaxle noise in“ P”
and “N” positions.ON vehicle1. A/T fluid levelTM-171
2. Line pressure testTM-178
3. Accelerator

Page 5083 of 5883

NISSAN TIIDA 2007 Service Repair Manual SYSTEM SYMPTOM
TM-137
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
OthersVehicle braked by
gear change from D
3
to D
4.ON vehicle 1. A/T fluid levelTM-171OFF vehicle2

Page 5084 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-138
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
SYSTEM SYMPTOM
OD OFF Indicator Lamp Does Not Come On
INFOID:0000000001696242
SYMPTOM:
OD OFF indicator lamp does not come on for about 2 seconds wh

Page 5085 of 5883

NISSAN TIIDA 2007 Service Repair Manual SYSTEM SYMPTOM
TM-139
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
.
3. Turn ignition switch OFF.
4. Check voltage between TCM connector terminals and ground.
OK or NG

Page 5086 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-140
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
SYSTEM SYMPTOM
Check again. Refer to TM-180, "Check Before Engine Is Started".
OK or NG
OK >>INSPECTION END
NG >> GO TO 7.
7.CHECK TCM
1. Check TCM

TM-140
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
SYSTEM SYMPTOM
Check again. Refer to TM-180, "Check Before Engine Is Started".
OK or NG
OK >>INSPECTION END
NG >> GO TO 7.
7.CHECK TCM
1. Check TCM input/output. Refer to TM-119, "
Reference Value" (Type 1) or TM-422, "Reference Value"
(Type 2).
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Engine Cannot Be Started in "P" and "N" PositionINFOID:0000000001696243
SYMPTOM:
Engine cannot be started with selector lever in “P” or “N” position.
Engine can be started with selector lever in “D”, “2”, “1” or “R” position.
1.CHECK SELF-DIAGNOSIS RESULTS
Perform self-diagnosis. Refer to TM-35, "
CONSULT-III Function (TRANSMISSION)" or TM-38, "Diagnosis
Procedure without CONSULT-III".
Is any malfunction detected by self-diagnostic results?
YES >> Check the malfunctioning system. Refer to TM-35, "CONSULT-III Function (TRANSMISSION)" or
TM-38, "
Diagnosis Procedure without CONSULT-III".
NO >> GO TO 2.
2.CHECK PNP SWITCH
Check continuity between PNP switch harness connector terminals.
OK or NG
OK >> GO TO 4.
NG >> GO TO 3.
3.CHECK CONTROL CABLE ADJUSTMENT
Check PNP switch again with control cable disconnected from manual shaft of A/T assembly. Refer to test
group 2.
OK or NG
OK >> Adjust control cable. Refer to TM-204, "Adjustment of A/T Position".
NG >> 1. Check PNP switch (Refer to test group 2.) again after adjusting PNP switch (Refer to TM-46
).
- If OK, INSPECTION END
- If NG, repair or replace PNP switch. Refer to TM-195, "
Park/Neutral Position (PNP) Switch".
4.CHECK STARTING SYSTEM
Check starting system. Refer to STR-6, "
System Description".
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
In "P" Position, Vehicle Moves Forward or Backward When PushedINFOID:0000000001696244
SYMPTOM:
Vehicle moves when it is pushed forward or backward with selector lever in “P” position.
Selector lever position Connector terminal Continuity
“P”, “N”
F25 1 - 2Ye s
Other positions No
SCIA5606E

Page 5087 of 5883

NISSAN TIIDA 2007 Service Repair Manual SYSTEM SYMPTOM
TM-141
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
1.CHECK A/T POSITION
Check A/T position. Refer to TM-204, "
Checking of A/T Position".
OK or NG
OK >>

Page 5088 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-142
< SYMPTOM DIAGNOSIS >[TYPE 1 (4AT: RE4F03B)]
SYSTEM SYMPTOM
NG >> GO TO 6.
6.CHECK TCM
1. Check TCM input/output signals. Refer to TM-22, "
Input/Output Signal of TCM".
2. If NG, recheck TCM pi
