Page 4609 of 5883

NISSAN TIIDA 2007 Service Repair Manual FRONT SEAT SE-13 < REMOVAL AND INSTALLATION > C D E F G H I K L MA B SE N O P REMOVAL AND INSTALLATION FRONT SEAT Exploded ViewINFOID:0000000001710927 Driver Seat 1. Headrest 2. Headrest holder (free)

Page 4610 of 5883

NISSAN TIIDA 2007 Service Repair Manual SE-14 < REMOVAL AND INSTALLATION > FRONT SEAT Removal and Installation INFOID:0000000001710898 CAUTION:  When removing and installing, use shop cloths to protect parts from damage.  Disconnect both

Page 4611 of 5883

NISSAN TIIDA 2007 Service Repair Manual FRONT SEAT SE-15 < REMOVAL AND INSTALLATION > C D E F G H I K L MA B SE N O P 1. Remove the rear leg covers. 2. Remove the front leg covers. 3. Remove the mounting bolts on the back side of the front

Page 4612 of 5883

NISSAN TIIDA 2007 Service Repair Manual SE-16 < REMOVAL AND INSTALLATION > REAR SEAT REAR SEAT Exploded ViewINFOID:0000000001710932 60:40 SPLIT FOLD DOWN SLIDING SEAT WIIA1305E 1. Headrest 2. Headrest holder (locked) 3. Headrest holder (fre

Page 4613 of 5883

NISSAN TIIDA 2007 Service Repair Manual REAR SEAT SE-17 < REMOVAL AND INSTALLATION > C D E F G H I K L MA B SE N O P 60:40 SPLIT FOLD DOWN FIXED SEAT 7. Armrest 8. Armrest insert 9. Outer hinge cover 10. Seatback hinge 11. Inner hinge cove

Page 4614 of 5883

NISSAN TIIDA 2007 Service Repair Manual SE-18 < REMOVAL AND INSTALLATION > REAR SEAT Removal and Installation INFOID:0000000001710908 CAUTION: When removing and installing, use shop cloths to protect parts from damage. 60:40 SPLIT FOLD DOWN

Page 4615 of 5883

NISSAN TIIDA 2007 Service Repair Manual REAR SEAT SE-19 < REMOVAL AND INSTALLATION > C D E F G H I K L MA B SE N O P 4. Fold the left seatback and remove the seatback mounting bolts (A) from the left rear seat back brackets. Remove the seat

Page 4616 of 5883

NISSAN TIIDA 2007 Service Repair Manual SE-20 < REMOVAL AND INSTALLATION > REAR SEAT 1. Install the rear seatback side bracket in the vehicle. 2. Temporarily tighten the seatback assembly and rear seatback side bracket. 3. Lift to fold up s
