SYSTEM SYMPTOM
TM-447
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
1. Remove oil pan. Refer to TM-213, "Component".
2. Check A/T fluid condition. Refer to TM-171, "
Checking A/T Fluid".
OK or NG
OK >> GO TO 7.
NG >> GO TO 5.
7.CHECK SYMPTOM
Check again. Refer to TM-181, "
Check at Idle".
OK or NG
OK >>INSPECTION END
NG >> GO TO 8.
8.CHECK TCM
1. Check TCM input/output signals. Refer to TM-22, "
Input/Output Signal of TCM".
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Vehicle Cannot Be Started from D1INFOID:0000000001714353
SYMPTOM:
Vehicle cannot be started from D
1 on “Cruise Test — Part 1”.
1.CHECK SYMPTOM
Check symptom. Refer to TM-181, "
Check at Idle".
Is
“Vehicle Dose Not Creep Backward in “R” Position” OK?
OK >> GO TO 2.
NG >> GO TO TM-444, "
Vehicle Does Not Creep Backward in "R" Position".
2.CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis. Refer to XX-XX, "*****"
or TM-38, "Diagnosis Procedure without CONSULT-III".
Is any malfunction detected by self-diagnostic results?
YES >> Check the malfunctioning system. Refer to XX-XX, "*****" or XX-XX, "*****".
NO >> GO TO 3.
3.CHECK ACCELERATOR PEDAL POSITION SENSOR
Check accelerator pedal position sensor. Refer to XX-XX, "*****"
(type 1) or XX-XX, "*****" (type 2).
OK or NG
OK >> GO TO 4.
NG >> Repair or replace accelerator pedal position sensor.
4.CHECK LINE PRESSURE
Check line pressure at stall point with selector lever in “D” position. Refer to TM-178, "
Inspection and Judg-
ment".
OK or NG
OK >> GO TO 6.
NG >> GO TO 5.
5.DETECT MALFUNCTIONING ITEM
1. Remove control valve assembly. Refer to TM-191, "
Control Valve Assembly and Accumulators".
2. Check the following items:
- Shift valve A
- Shift valve B
- Shift solenoid valve A
- Shift solenoid valve B
- Pilot valve
- Pilot filter
Page 5394 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TM-448
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
3. Disassemble A/T. Refer to TM-222, "Disassembly".
4. Check the following items:
- Forward clutch assembly. Refer to TM-267, "
Forw NISSAN TIIDA 2007 Service Repair Manual TM-448
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
3. Disassemble A/T. Refer to TM-222, "Disassembly".
4. Check the following items:
- Forward clutch assembly. Refer to TM-267, "
Forw](/manual-img/5/57395/w960_57395-5393.png)
TM-448
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
3. Disassemble A/T. Refer to TM-222, "Disassembly".
4. Check the following items:
- Forward clutch assembly. Refer to TM-267, "
Forward and Overrun Clutches".
- Low one-way clutch. Refer to TM-222, "
Disassembly".
- Forward one-way clutch. Refer to TM-278, "
Rear Internal Gear and Forward Clutch Hub".
- High clutch assembly. Refer to TM-262, "
High Clutch".
- Torque converter. Refer to TM-222, "
Disassembly".
- Oil pump assembly. Refer to TM-240, "
Oil Pump".
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
6.CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to TM-213, "
Component".
2. Check A/T fluid condition. Refer to TM-171, "
Checking A/T Fluid".
OK or NG
OK >> GO TO 7.
NG >> GO TO 5.
7.DETECT MALFUNCTIONING ITEM
1. Remove control valve assembly. Refer to TM-191, "
Control Valve Assembly and Accumulators".
2. Check the following items:
- Shift valve A
- Shift valve B
- Shift solenoid valve A
- Shift solenoid valve B
- Pilot valve
- Pilot filter
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damage parts.
8.CHECK SYMPTOM
Check again. Refer to TM-183, "
Cruise Test - Part 1".
OK or NG
OK >>INSPECTION END
NG >> GO TO 9.
9.CHECK TCM
1. Check TCM input/output signals. Refer to TM-22, "
Input/Output Signal of TCM".
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
A/T Does Not Shift: D1→ D2or Does Not Kickdown: D4→ D2INFOID:0000000001714354
SYMPTOM:
A/T does not shift from D
1 to D2 at the specified speed on “Cruise Test — Part 1”.
A/T does not shift from D
4 to D2 when depressing accelerator pedal fully at the specified speed on
“Cruise Test — Part 2”.
1.CHECK SYMPTOM
Check symptom. Refer to TM-181, "
Check at Idle" and TM-183, "Cruise Test - Part 1".
Are
“Vehicle Dose Not Creep Forward in “D”, “2” or “1” Position” and “Vehicle Cannot Be Started from D1” OK?
YES >> GO TO 2.
NG >> GO TO TM-446, "
Vehicle Does Not Creep Forward in "D", "2" or "1" Position" and TM-447, "Vehi-
cle Cannot Be Started from D1".
