Page 5705 of 5883
VTL-44
< ON-VEHICLE REPAIR >[MANUAL AIR CONDITIONER]
BLOWER FAN RESISTOR
BLOWER FAN RESISTOR
Removal and InstallationINFOID:0000000001696536
REMOVAL
1. Remove the instrument lower finisher and instrument lower cover (LH) for LHD only. Refer to IP-11,
"Removal and Installation".
2. Remove the glove box assembly and instrument lower cover (RH) for RHD only. Refer to IP-11, "
Removal
and Installation".
3. Remove the console side cover. Refer to IP-10, "
Component Parts".
4. Remove the brake pedal assembly for LHD only. Refer to BR-12, "
Removal and Installation".
5. Disconnect the blower fan resistor connector.
6. Remove the blower fan resistor screws (A), then remove the
blower fan resistor (1).
INSTALLATION
Installation is in the reverse order of removal.
SJIA0656E
Page 5706 of 5883
INTAKE DOOR
VTL-45
< ON-VEHICLE REPAIR >[MANUAL AIR CONDITIONER]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
INTAKE DOOR
Intake Door Cable AdjustmentINFOID:0000000001696537
1. Remove the instrument lower finisher and instrument lower cover (LH) for LHD only. Refer to IP-11,
"Removal and Installation".
2. Remove the glove box assembly and instrument lower cover (RH) for RHD only. Refer to IP-11, "
Removal
and Installation".
3. Remove outer cable of intake door cable (1) from clamp (A).
4. Set intake door lever to REC position.
5. Push intake door link (2) in the direction shown by the arrow,
and then carefully pull outer cable to controller side, and install
clamp (A).
6. Operate intake door lever to insure that inner cable moves
smoothly.
CAUTION:
When clamping the outer cable, do not move the inner
cable.
SJIA0650E
Page 5707 of 5883
VTL-46
< ON-VEHICLE REPAIR >[MANUAL AIR CONDITIONER]
AIR MIX DOOR
AIR MIX DOOR
Air Mix Door Cable AdjustmentINFOID:0000000001696538
1. Remove steering member. Refer to ST-9, "Removal and Installation".
2. Remove outer cable of air mix door cable (1) from clamp (A).
3. Set temperature control dial to full cold position.
4. Push air mix door lever (2) in the direction shown by arrow, and
then carefully pull outer cable toward controller side, and install
clamp (A).
5. Operate temperature control dial to insure that inner cable
moves smoothly.
CAUTION:
When clamping the outer cable, do not move the inner
cable.
SJIA1150E
Page 5708 of 5883
MODE DOOR
VTL-47
< ON-VEHICLE REPAIR >[MANUAL AIR CONDITIONER]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
MODE DOOR
Mode Door Cable AdjustmentINFOID:0000000001696539
1. Remove the glove box assembly and instrument lower cover (RH) for LHD only. Refer to IP-11, "Removal
and Installation".
2. Remove the instrument lower finisher and instrument lower cover (LH) for RHD only. Refer to IP-11,
"Removal and Installation".
3. Remove outer cable of mode door cable (1) from clamp (A).
4. Set mode control dial to VENT position.
5. Push main link (2) in the direction shown by the arrow, and then
carefully pull outer cable to controller side, and install clamp (A).
6. Operate mode control dial to insure that inner cable moves
smoothly.
CAUTION:
When clamping the outer cable, do not move the inner
cable.
7. Turn mode control dial to each position.
8. Confirm that discharge air comes out according to the air distribution table. Refer to HAC-11, "
Discharge
Air Flow".
SJIA0654E
Page 5709 of 5883
VTL-48
< ON-VEHICLE REPAIR >[MANUAL AIR CONDITIONER]
DUCTS AND GRILLES
DUCTS AND GRILLES
Removal and InstallationINFOID:0000000001696540
Instrument Panel Ducts
NOTE:
A LHD model shown, RHD model similar
Floor Ducts
SJIA0657E
1. Side defroster duct (right) 2. Defroster nozzle 3. Side defroster duct (left)
4. Side defroster grille (left) 5. Instrument side panel (left) 6. Instrument panel and pad
7. Side ventilator assembly (left) 8. Cluster lid C 9. Side ventilator assembly (right)
10. Instrument finisher E 11. Instrument side panel (right) 12. Side defroster grille (right)
13. Side ventilator duct (right) 14. Center ventilator duct (right) 15. Center ventilator duct (left)
16. Side ventilator duct (left)
WJIA2198E
Page 5710 of 5883
DUCTS AND GRILLES
VTL-49
< ON-VEHICLE REPAIR >[MANUAL AIR CONDITIONER]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
CENTER VENTILATOR GRILLES
Removal
1. Remove cluster lid C. Refer to IP-10, "Component Parts".
2. Remove center ventilator grills (1) from cluster lid C using suit-
able tool (A).
Installation
Installation is in the reverse order of removal.
SIDE VENTILATOR GRILLES (LH/RH)
Removal
1. Remove side ventilator assembly (LH). Refer to IP-10, "Component Parts".
2. Remove side ventilator grille (LH) (1) using suitable tool (A).
3. Remove side ventilator assembly (RH). Refer to IP-10, "
Component Parts".
4. Remove the side ventilator grille (RH) screw.
5. Remove side ventilator grille (RH) (1) using suitable tool (A).
Installation
Installation is in the reverse order of removal.
DEFROSTER NOZZLE AND SIDE DEFROSTER DUCTS (LH/RH)
1. Front floor duct 2. Rear floor duct (left) 3. Clip
4. Rear floor duct (right)
ZJIA0661E
SJIA0658E
SJIA0659E
Page 5711 of 5883
VTL-50
< ON-VEHICLE REPAIR >[MANUAL AIR CONDITIONER]
DUCTS AND GRILLES
Removal
1. Remove instrument upper finisher. Refer to IP-10, "Component Parts".
2. Remove screws and then remove side defroster duct (RH) and side defroster duct (LH).
3. Remove screws, and then remove defroster nozzle.
Installation
Installation is in the reverse order of removal.
SIDE VENTILATOR DUCTS
Removal
1. Remove instrument panel and pad. Refer to IP-10, "Component Parts".
2. Remove screws (A), and then remove side ventilator duct (left)
(1).
3. Remove screw (A) and clip (B), and then remove side ventilator
duct (right) (1).
Installation
Installation is in the reverse order of removal.
1. Side defroster duct (RH) 2. Side defroster duct (LH) 3. Defroster nozzle
A. Side defroster duct screw B. Defroster nozzle screw
WJIA2199E
SJIA0661E
SJIA0662E
Page 5712 of 5883
DUCTS AND GRILLES
VTL-51
< ON-VEHICLE REPAIR >[MANUAL AIR CONDITIONER]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
CENTER VENTILATOR DUCTS
Removal
1. Remove instrument panel and pad. Refer to IP-10, "Component Parts".
2. Remove screws (A), and then remove center ventilator ducts
(1).
Installation
Installation is in the reverse order of removal.
SIDE FOOT DUCTS
NOTE:
The side foot ducts are part of the A/C unit assembly case.
Removal
1. Remove A/C unit assembly. Refer to VTL-37, "Removal and Installation".
2. Remove screws (A), and then remove side foot duct (LH) (1).
3. Remove screws (A), and then remove side foot duct (RH) (1).
Installation
Installation is in the reverse order of removal.
FLOOR DUCTS
Removal
1. Remove front seats and center console assembly. Refer to SE-14, "Removal and Installation" and IP-11,
"Removal and Installation".
SJIA0663E
SJIA0664E
SJIA0665E
