Page 3089 of 5883

NISSAN TIIDA 2007 Service Repair Manual EXL-88 < ON-VEHICLE REPAIR > HEADLAMP AIMING CONTROL HEADLAMP AIMING CONTROL Removal and Installation of Headlamp Aiming SwitchINFOID:0000000001530404 REMOVAL 1. Remove the instrument lower finisher.

Page 3090 of 5883

NISSAN TIIDA 2007 Service Repair Manual HEADLAMP AIMING CONTROL EXL-89 < ON-VEHICLE REPAIR > C D E F G H I J K MA B EXL N O P Removal and Installation of Height SensorINFOID:0000000001530540 REMOVAL 1. Disconnect the height sensor connector

Page 3091 of 5883

NISSAN TIIDA 2007 Service Repair Manual EXL-90 < ON-VEHICLE REPAIR > HEADLAMP AIMING CONTROL INSTALLATION Installation is in the reverse order of removal.  Tighten the height sensor bolt closest to the vehicle front first when installing t

Page 3092 of 5883

NISSAN TIIDA 2007 Service Repair Manual AUTO LIGHT SYSTEM EXL-91 < ON-VEHICLE REPAIR > C D E F G H I J K MA B EXL N O P AUTO LIGHT SYSTEM Removal and Installation of Light and Rain SensorINFOID:0000000001530408 REMOVAL 1. Remove the rear vi

Page 3093 of 5883

NISSAN TIIDA 2007 Service Repair Manual EXL-92 < ON-VEHICLE REPAIR > SIDE TURN SIGNAL LAMP SIDE TURN SIGNAL LAMP Bulb ReplacementINFOID:0000000001530538 1. Remove the side turn signal lamp. Refer to EXL-92, "Removal and Installation". 2. Tu

Page 3094 of 5883

NISSAN TIIDA 2007 Service Repair Manual REAR COMBINATION LAMP EXL-93 < ON-VEHICLE REPAIR > C D E F G H I J K MA B EXL N O P REAR COMBINATION LAMP Bulb ReplacementINFOID:0000000001530525 HATCHBACK 1. Remove the rear combination lamp. Refer t

Page 3095 of 5883

NISSAN TIIDA 2007 Service Repair Manual EXL-94 < ON-VEHICLE REPAIR > REAR COMBINATION LAMP Hatchback LKIA0760E 1. Rear combination lamp harness 2. Turn signal lamp bulb 3. Back-up lamp bulb 4. Stop/tail lamp bulb 5. Rear combination lamp ho

Page 3096 of 5883

NISSAN TIIDA 2007 Service Repair Manual REAR COMBINATION LAMP EXL-95 < ON-VEHICLE REPAIR > C D E F G H I J K MA B EXL N O P Sedan DISSASEMBLY 1. Remove the rear combination lamp harness. 2. Remove the bulbs from the rear combination lamp ha
