1. Remove forward clutch hub from rear internal gear.
2. Remove end bearing (1) from rear internal gear (2).
3. Remove thrust washer from rear internal gear.
4. Remove end bearing (2) from forward one-way clutch (3).
(1): Forward clutch hub
5. Remove forward one-way clutch from forward clutch hub.
SAT251D
SCIA7028E
SCIA3691E
SCIA7026E
SAT255D
Page 5226 of 5883
TM-280
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
REPAIR FOR COMPONENT PARTS
INSPECTION
Rear Internal Gear and Forward Clutch Hub
Check rubbing surfaces for wear or damage. Replace if necessary.
(1): Rear internal gear
(2): Forward clutch hub
End Bearings and Forward One-way Clutch
Check end bearings (1) for deformation and damage. Replace if
necessary.
Check forward one-way clutch (2) for wear and damage. Replace if
necessary.
ASSEMBLY
1. Install forward one-way clutch on forward clutch hub.
CAUTION:
Be careful with the direction of forward one-way clutch.
2. Install end bearing (2) on forward one-way clutch (3).
(1): Forward clutch hub
SCIA5881J
SCIA7027E
SAT976H
SCIA7026E
Page 5227 of 5883
REPAIR FOR COMPONENT PARTS
TM-281
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
3. Install thrust washer on rear internal gear.
CAUTION:
Align pawls of thrust washer with holes of rear internal
gear.
4. Install end bearing (1) on rear internal gear (2).
5. Install forward clutch hub on rear internal gear.
CAUTION:
Check operation of forward one-way clutch.
Hold rear internal gear and turn forward clutch hub.
Check forward clutch hub for correct locking and unlock-
ing directions.
If not as shown, check the installation direction of forward
one-way clutch.
Output Shaft, Output Gear, Idler Gear, Reduction Pinion Gear and Bearing Retainer
INFOID:0000000001730993
COMPONENTS
SCIA3690E
SCIA7028E
AAT426
Page 5228 of 5883
TM-282
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
REPAIR FOR COMPONENT PARTS
DISASSEMBLY
1. Remove seal rings from output shaft and bearing retainer.
1. Idler gear 2. Idler gear bearing 3. Reduction pinion gear adjusting
shim
4. Reduction pinion gear bearing 5. Reduction pinion gear 6. Output shaft bearing
7. Seal ring 8. Bearing retainer 9. Output shaft
10. Seal ring 11. Output gear adjusting spacer 12. Output gear bearing
13. Output gear 14. Lock nut
SCIA5883J
SAT666D
Page 5229 of 5883
![NISSAN TIIDA 2007 Service Repair Manual REPAIR FOR COMPONENT PARTS
TM-283
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2. Remove output shaft bearing according to the following proce-
dures.
a. Set out NISSAN TIIDA 2007 Service Repair Manual REPAIR FOR COMPONENT PARTS
TM-283
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2. Remove output shaft bearing according to the following proce-
dures.
a. Set out](/manual-img/5/57395/w960_57395-5228.png)
REPAIR FOR COMPONENT PARTS
TM-283
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2. Remove output shaft bearing according to the following proce-
dures.
a. Set output shaft bearing inner race (1) on suitable tool (A), and
set a suitable tool (B) on output shaft (2), and press output shaft
(2) to remove output shaft bearing inner race (1).
CAUTION:
Set a drift (A) on output shaft bearing inner race (1).
b. Set Tool on output shaft bearing outer race, and remove output
shaft bearing outer race from bearing retainer.
3. Remove output gear bearing according to the following proce-
dures.
a. Insert suitable tool (A) between the mating surfaces of output
gear (1) and output gear bearing inner race (2), and enlarge the
gap.
CAUTION:
Do not damage output gear (1).
b. Set a suitable tool (B) on output gear (1), and remove output
gear bearing inner race (2) using suitable tool (C).
c. Set Tool (A) on output gear bearing outer race (1), and remove
output gear bearing outer race (1) from bearing retainer (2).
4. Remove idler gear bearing according to the following proce-
dures.
a. Insert suitable tool (A) between the mating surfaces of idler gear
(1) and idler gear bearing inner race (2), and enlarge the gap.
CAUTION:
Do not damage idler gear (1).
b. Set suitable tool (B), on idler gear (1), and remove idler gear
bearing inner race (2) using suitable tool (C).
SCIA7041E
SAT168K
SCIA7042E
Tool number: KV381054S0
SCIA7043E
SCIA7044E
Page 5230 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TM-284
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
REPAIR FOR COMPONENT PARTS
c. Set Tool on idler gear bearing outer race, and remove idler gear
bearing outer race from transaxle case.
5. Rem NISSAN TIIDA 2007 Service Repair Manual TM-284
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
REPAIR FOR COMPONENT PARTS
c. Set Tool on idler gear bearing outer race, and remove idler gear
bearing outer race from transaxle case.
5. Rem](/manual-img/5/57395/w960_57395-5229.png)
TM-284
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
REPAIR FOR COMPONENT PARTS
c. Set Tool on idler gear bearing outer race, and remove idler gear
bearing outer race from transaxle case.
5. Remove reduction pinion gear bearing according to the following
