BACK DOOR LOCK
BACK DOOR LOCK
Removal and InstallationINFOID:0000000001315857
BACK DOOR LOCK
Removal
1. Remove the back door finisher lower. Refer to INT-18, "Removal and Installation".
2. Remove the bolts, disconnect the electrical connector and sepa-
rate the lock from the door.
Installation
Installation is in the reverse order of removal.
BACK DOOR HANDLE
Removal
1. Remove the back door finisher lower. Refer to INT-18, "Removal and Installation".
2. Disconnect the harness connectors (1), remove the nuts and the
back door handle (A).
3. Release the clips and remove the switch from the housing.
Installation
Installation is in the reverse order of removal.
LIIA2607E
LIIA2669E
LIIA2609E
Page 826 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TRUNK LID
DLK-237
< REMOVAL AND INSTALLATION >[WITH I-KEY, WITHOUT SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK LID
Fitting AdjustmentINFOID:0000000001315840
Longitudinal and lateral clearance a NISSAN TIIDA 2007 Service Repair Manual TRUNK LID
DLK-237
< REMOVAL AND INSTALLATION >[WITH I-KEY, WITHOUT SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK LID
Fitting AdjustmentINFOID:0000000001315840
Longitudinal and lateral clearance a](/manual-img/5/57395/w960_57395-825.png)
TRUNK LID
DLK-237
< REMOVAL AND INSTALLATION >[WITH I-KEY, WITHOUT SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK LID
Fitting AdjustmentINFOID:0000000001315840
Longitudinal and lateral clearance adjustment
1. With the striker released, loosen the trunk lid hinge nuts and close the trunk lid.
2. Make the lateral clearance and the clearance to the rear window glass equal. Then open the trunk lid to
tighten the nuts.
Surface height adjustment
1. Loosen the striker bolts. Raise the striker to the top position, and temporarily tighten the upper bolt.
2. Close the trunk lid lightly and adjust the surface height. Then open the trunk lid and tighten the striker
bolts.
Trunk Lid AssemblyINFOID:0000000001315841
REMOVAL
1. Remove the trunk lid finisher. Refer to INT-17, "Removal and Installation" .
2. Remove the trunk lid wire harness.
1. Rear fender 2. Trunk lid 3. Rear combination lamp
4. Rear bumper fascia a. 4.0 ± 1.0 mm (0.16 ± 0.04 in) b. 3.5 ± 1.0 mm (0.14 ± 0.04 in)
c. 4.5 ± 1.7 mm (0.03 ± 0.06 in) d. 7.0 ± 2.2 mm (0.28 ± 0.09 in)
LIIA2932E
Page 827 of 5883
DLK-238
< REMOVAL AND INSTALLATION >[WITH I-KEY, WITHOUT SUPER LOCK]
TRUNK LID
3. Remove the nuts (a) and the trunk lid assembly (1).
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installing, apply touch-up paint (body color) to the head of the hinge nuts.
Trunk Lid LockINFOID:0000000001315842
REMOVAL
1. Remove the trunk lid finisher. Refer to INT-17, "Removal and Installation".
2. If equipped, disconnect the trunk lid lock cylinder rod.
3. Remove the release cable.
4. Disconnect the electrical connector (a), remove the bolts (b) and
the trunk lid lock (1).
INSTALLATION
Installation is in the reverse order of removal.
Trunk Lid StrikerINFOID:0000000001315843
REMOVAL
1. Remove the trunk rear plate and trunk rear finisher. Refer to INT-35, "Removal and Installation".
2. Remove the bolts, disconnect the electrical connector and remove the trunk lock actuator.
3. Remove the bolt and disconnect the trunk lid release cable.
LIIA2933E
LIIA2935E
Page 828 of 5883
TRUNK LID
DLK-239
< REMOVAL AND INSTALLATION >[WITH I-KEY, WITHOUT SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
4. Remove the bolts (a) and the trunk lid striker (1).
INSTALLATION
Installation is in the reverse order of removal.
LIIA2934E
Page 829 of 5883
DLK-240
< BASIC INSPECTION >[WITH I-KEY & SUPER LOCK]
DIAGNOSIS AND REPAIR WORKFLOW
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORKFLOW
Work FlowINFOID:0000000001396667
OVERALL SEQUENCE
