Page 4801 of 5883

NISSAN TIIDA 2007 Service Repair Manual SRC-32 < COMPONENT DIAGNOSIS > B1145 – B1148 SIDE CURTAIN AIR BAG MODULE RH Replace the air bag diagnosis sensor unit. Refer to SR-15, "Removal and Installation". >> GO TO 5 5.RELATED HARNESS Repla

Page 4802 of 5883

NISSAN TIIDA 2007 Service Repair Manual B1086 – B1089 SEAT BELT PRE-TENSIONER LH SRC-33 < COMPONENT DIAGNOSIS > C D E F G I J K L MA B SRC N O P B1086 – B1089 SEAT BELT PRE-TENSIONER LH DescriptionINFOID:0000000001396383 DTC B1086 – B

Page 4803 of 5883

NISSAN TIIDA 2007 Service Repair Manual SRC-34 < COMPONENT DIAGNOSIS > B1086 – B1089 SEAT BELT PRE-TENSIONER LH DTC CONFIRMATION PROCEDURE (Without CONSULT-lll) NOTE: SRS will not enter diagnosis mode if no malfunction is detected in user

Page 4804 of 5883

NISSAN TIIDA 2007 Service Repair Manual B1086 – B1089 SEAT BELT PRE-TENSIONER LH SRC-35 < COMPONENT DIAGNOSIS > C D E F G I J K L MA B SRC N O P Replace the air bag diagnosis sensor unit. Refer to SR-15, "Removal and Installation". >> GO

Page 4805 of 5883

NISSAN TIIDA 2007 Service Repair Manual SRC-36 < COMPONENT DIAGNOSIS > B1182 - B1185 LAP SEAT BELT PRE-TENSIONER B1182 - B1185 LAP SEAT BELT PRE-TENSIONER DescriptionINFOID:0000000001404240 DTC B1182 – B1185 LAP SEAT BELT PRE-TENSIONER Th

Page 4806 of 5883

NISSAN TIIDA 2007 Service Repair Manual B1182 - B1185 LAP SEAT BELT PRE-TENSIONER SRC-37 < COMPONENT DIAGNOSIS > C D E F G I J K L MA B SRC N O P DTC CONFIRMATION PROCEDURE (Without CONSULT-lll) NOTE: SRS will not enter diagnosis mode if no

Page 4807 of 5883

NISSAN TIIDA 2007 Service Repair Manual SRC-38 < COMPONENT DIAGNOSIS > B1182 - B1185 LAP SEAT BELT PRE-TENSIONER Replace the air bag diagnosis sensor unit. Refer to SR-15, "Removal and Installation". >> GO TO 5 5.RELATED HARNESS Replace th

Page 4808 of 5883

NISSAN TIIDA 2007 Service Repair Manual B1081 – B1084 SEAT BELT PRE-TENSIONER RH SRC-39 < COMPONENT DIAGNOSIS > C D E F G I J K L MA B SRC N O P B1081 – B1084 SEAT BELT PRE-TENSIONER RH DescriptionINFOID:0000000001396386 DTC B1081 – B
