Page 4689 of 5883

NISSAN TIIDA 2007 Service Repair Manual SEC-64
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
BCM (BODY CONTROL MODULE)
ALKWA0093GB

Page 4690 of 5883

NISSAN TIIDA 2007 Service Repair Manual BCM (BODY CONTROL MODULE)
SEC-65
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
ALKIA1257GB

Page 4691 of 5883

NISSAN TIIDA 2007 Service Repair Manual SEC-66
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
BCM (BODY CONTROL MODULE)
ALKIA1258GB

Page 4692 of 5883

NISSAN TIIDA 2007 Service Repair Manual BCM (BODY CONTROL MODULE)
SEC-67
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
ALKIA1259GB

Page 4693 of 5883

NISSAN TIIDA 2007 Service Repair Manual SEC-68
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
BCM (BODY CONTROL MODULE)
Fail Safe
INFOID:0000000001404125
Fail-safe index
BCM performs fail-safe control when any DTC listed below is detected.

Page 4694 of 5883

NISSAN TIIDA 2007 Service Repair Manual BCM (BODY CONTROL MODULE)
SEC-69
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
REAR WIPER CONTROL
BCM detects a rear wiper stopping position according to a rear wiper

BCM (BODY CONTROL MODULE)
SEC-69
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
REAR WIPER CONTROL
BCM detects a rear wiper stopping position according to a rear wiper auto stop signal.
When a rear wiper auto stop signal is in the condition listed below, BCM stops power supply to rear wiper after
rear wiper is activated for five seconds.
NOTE:
The above operation is repeated when operating the rear wiper switch one minute after the stop of the rear
wiper caused by Fail-safe.
TURN SIGNAL LAMP CONTROL
BCM detects the turn signal lamp circuit status from the terminal voltage.
BCM increases the turn signal lamp blinking speed if the bulb or harness open is detected with the turn signal
lamp operating.
NOTE:
The blinking speed is normal while activating the hazard warning lamp.
LIGHT & RAIN SENSOR MALFUNCTION DETECTION FUNCTION
BCM controls the following items when LIGHT & RAIN sensor has a malfunction.
Auto Light Control
Headlamp is turned ON.
Front Wiper Control
The condition just before the activation of Fail-safe is maintained until the front wiper switch is turned OFF.
DTC Inspection Priority ChartINFOID:0000000001404126
DTC IndexINFOID:0000000001404127
NOTE:
Details of time display
CRNT: Displays when there is a malfunction now or after returning to the normal condition until turning igni-
tion switch OFF → ON again.
Display contents of CONSULT Fail-safe Cancellation
B2190: NATS ANTENNA AMP Inhibits engine cranking
Inhibits steering lock unlocking (Intelligent Key unit)
Fuel cut (ECM)Erase DTC
B2191: DIFFERENCE OF KEY Inhibits engine cranking
Inhibits steering lock unlocking (Intelligent Key unit)
Fuel cut (ECM)Erase DTC
B2192: ID DISCORD BCM-ECM Fuel cut (ECM) Erase DTC
B2193: CHAIN OF BCM-ECM Fuel cut (ECM) Erase DTC
B2194: DISCORD BCM-I-KEY Inhibits engine cranking
Inhibits steering lock unlocking (Intelligent Key unit)
Fuel cut (ECM)Erase DTC
Ignition switch Rear wiper switch Auto stop signal
ONOFFRear wiper stop position signal cannot be
input 5 seconds.
ON The signal does not change for 5 seconds.
Priority DTC
1 U1000: CAN COMM CIRCUIT
U1010: CONTROL UNIT (CAN)
2 B2190: NATS ANTENNA AMP
B2191: DIFFERNCE OF KEY
B2192: ID DISCORD BCM-ECM
B2193: CHAIN OF BCM-ECM
B2194: DISCORD BCM-I-KEY

Page 4695 of 5883

NISSAN TIIDA 2007 Service Repair Manual SEC-70
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
BCM (BODY CONTROL MODULE)
PAST: Displays when there is a malfunction that is detected in the past and stored.
1 - 39: Displayed if any previou

Page 4696 of 5883

NISSAN TIIDA 2007 Service Repair Manual INTELLIGENT KEY UNIT
SEC-71
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
INTELLIGENT KEY UNIT
Reference ValueINFOID:0000000001404128
For LHD vehicles, refer to DLK-3

INTELLIGENT KEY UNIT
SEC-71
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
INTELLIGENT KEY UNIT
Reference ValueINFOID:0000000001404128
For LHD vehicles, refer to DLK-381, "Reference Value".
For RHD vehicles, refer to DLK-151, "
Reference Value".
Fail SafeINFOID:0000000001404132
DTC Inspection Priority ChartINFOID:0000000001404133
If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.
DTC IndexINFOID:0000000001404134
NOTE:
Details of time display
CRNT: Displays when there is a malfunction now or after returning to the normal condition until turning igni-
tion switch OFF → ON again.
1 - 39: Displayed if any previous malfunction is present when current condition is normal. It increases like 1
→ 2 → 3...38 → 39 after returning to the normal condition whenever ignition switch OFF → ON. The counter
remains at 39 even if the number of cycles exceeds it. It is counted from 1 again when turning ignition switch
OFF → ON after returning to the normal condition if the malfunction is detected again.
Display contents of CONSULT-III Fail-safe Cancellation
B2013: STRG COMM 1 Inhibits steering look unlocking Erase DTC
B2552: INTELLIGENT KEY Inhibits steering look unlocking
Inhibits engine cranking
(BCM)
Fuel cut
(ECM)Erase DTC
B2590: NATS MALFUNCTION Inhibits steering look unlocking
Inhibits engine cranking
(BCM)
Fuel cut
(ECM)Erase DTC
Priority DTC
1 U1000: CAN COMM CIRCUIT
U1010: CONTROL UNIT (CAN)
B2552: INTELIGENT KEY
2 B2013: STRG COMM 1
B2590: NATS MALFUNCTION
CONSULT display Detection condition Fail-safe Diagnosis
No DTC is detected.
further testing
may be required.———
U1000: CAN COMM CIRCUITIntelligent Key unit cannot receive CAN communi-
cation signal continuously for 2 seconds or more.—Check CAN communi-
cation system.
Refer to SEC-21
U1010: CONTROL UNIT (CAN)Intelligent Key unit detects internal CAN communi-
cation circuit malfunction.—Replace Intelligent Key
unit.
B2013: STRG COMM 1The ID verification result between Intelligent key
unit and steering lock unit are NG. Or Intelligent Key
unit cannot communicate with steering lock unit.×Perform steering lock
unit ID registration with
CONSULT-III
