NISSAN TIIDA 2007 Service Repair Manual EM-186
< ON-VEHICLE REPAIR >[MR18DE]
CAMSHAFT
CAMSHAFT
ComponentINFOID:0000000001337797
Removal and InstallationINFOID:0000000001337798
REMOVAL
WARNING:
Put a “CAUTION: FLAMMABLE” sign in the wo

Page 2834 of 5883

NISSAN TIIDA 2007 Service Repair Manual CAMSHAFT
EM-187
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Fuel tube and fuel injector assembly; Refer to EM-162.
Front cover, timing chain and related parts; Refer to EM-176
.

Page 2835 of 5883

NISSAN TIIDA 2007 Service Repair Manual EM-188
< ON-VEHICLE REPAIR >[MR18DE]
CAMSHAFT
13. Remove valve lifters.
NOTE:
Identify installed positions, and store them without mixing them up.
INSPECTION AFTER REMOVAL
Camshaft Runout
1. Put V-bl

Page 2836 of 5883

NISSAN TIIDA 2007 Service Repair Manual CAMSHAFT
EM-189
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Measure the inner diameter of camshaft bracket with a bore gauge
(A).
CAMSHAFT JOURNAL OIL CLEARANCE
(Oil clearance) =

Page 2837 of 5883

NISSAN TIIDA 2007 Service Repair Manual EM-190
< ON-VEHICLE REPAIR >[MR18DE]
CAMSHAFT
2. Measure the camshaft sprocket runout with a dial indicator (A).
(Total indicator reading)
If it exceeds the limit, replace camshaft sprocket.
Valve L

Page 2838 of 5883

NISSAN TIIDA 2007 Service Repair Manual CAMSHAFT
EM-191
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Clean camshaft journal to remove any foreign material.
Distinguish between the intake and the exhaust by looking at
th

Page 2839 of 5883

NISSAN TIIDA 2007 Service Repair Manual EM-192
< ON-VEHICLE REPAIR >[MR18DE]
CAMSHAFT
5. Install camshaft bracket bolts in three stage in numerical order
as shown in numerical order as shown.
There are two types of bolts. Refer to the fol

Page 2840 of 5883

NISSAN TIIDA 2007 Service Repair Manual CAMSHAFT
EM-193
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
10. Install camshaft sprocket (EXH) (2).
NOTE:
Secure the hexagonal part (A) of camshaft (EXH) using wrench
to tighten bol

CAMSHAFT
EM-193
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
10. Install camshaft sprocket (EXH) (2).
NOTE:
Secure the hexagonal part (A) of camshaft (EXH) using wrench
to tighten bolt.
11. Install timing chain and related parts. Refer to EM-176
.
12. Inspect and adjust valve clearance. Refer to EM-148, "
Valve Clearance".
13. Installation of the remaining components is in the reverse order of removal.
INSPECTION AFTER INSTALLATION
The following are procedures for checking fluids leak, lubricates leak.
Before starting engine, check oil/fluid levels including engine coolant and engine oil. If less than required
quantity, fill to the specified level. Refer to GI-27, "
Recommended Chemical Products and Sealants".
Use procedure below to check for fuel leakage.
- Turn ignition switch “ON” (with engine stopped). With fuel pressure applied to fuel piping, check for fuel leak-
age at connection points.
- Start engine. With engine speed increased, check again for fuel leakage at connection points.
Run engine to check for unusual noise and vibration.
NOTE:
If hydraulic pressure inside timing chain tensioner drops after removal/installation, slack in the guide may
generate a pounding noise during and just after engine start. However, this is normal. Noise will stop after
hydraulic pressure rises.
Warm up engine thoroughly to make sure there is no leakage of fuel, or any oil/fluids including engine oil and
engine coolant.
Bleed air from lines and hoses of applicable lines, such as in cooling system.
After cooling down engine, again check oil/fluid levels including engine oil and engine coolant. Refill to the
specified level, if necessary.
Summary of the inspection items:
* Transmission/transaxle/CVT fluid, power steering fluid, brake fluid, etc.
Inspection of Camshaft Sprocket (INT) Oil Groove
CAUTION:
Perform this inspection only when DTC P0011 is detected in self-diagnostic results of CONSULT-III
and it is directed according to inspection procedure of EC section. Refer to EC-796, "
Diagnosis Pro-
cedure".
Check when engine is cold so as to prevent burns from the splashing engine oil.
1. Check engine oil level. Refer to LU-15, "
Inspection".
2. Perform the following procedure so as to prevent the engine from being unintentionally started while
checking.
a. Remove intake manifold. Refer to EM-156, "
Component".
b. Disconnect ignition coil and injector harness connectors.
3. Remove intake valve timing control solenoid valve. Refer to EM-176, "
Component".
1 : Camshaft sprocket (INT)
Camshaft sprocket
bolt (EXH): 88.2 N·m (9.0 kg-m, 65 ft-lb)
PBIC3454J
Item Before starting engine Engine running After engine stopped
Engine coolant Level Leakage Level
Engine oil Level Leakage Level
Other oils and fluid* Level Leakage Level
Fuel Leakage Leakage Leakage
Exhaust gases — Leakage —
