Page 5377 of 5883

NISSAN TIIDA 2007 Service Repair Manual SYSTEM SYMPTOM
TM-431
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Improper Shift TimingToo high a gear
change point from D
1
to D
2, from D2 to D3,
from D
3 to D4.O

Page 5378 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-432
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
No Down ShiftFailure to change
gear from D
4 to D3.ON vehicle1. A/T fluid levelXX-XX, "*****"
2. Accelerator pedal position sensorEC

Page 5379 of 5883

NISSAN TIIDA 2007 Service Repair Manual SYSTEM SYMPTOM
TM-433
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
No Up ShiftFailure to change
gear from D
1 to D2.ON vehicle1. Control cable adjustmentXX-XX, "*****"

Page 5380 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-434
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
Slips/Will Not EngageVehicle will not run in
“R” position (but runs
in “D”, “2” and “1” po-
sitions). Clutch slips.

Page 5381 of 5883

NISSAN TIIDA 2007 Service Repair Manual SYSTEM SYMPTOM
TM-435
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Slips/Will Not EngageVehicle will not run in
“D”, “1”, “2” positions
(but runs in R pos

Page 5382 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-436
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
Slips/Will Not EngageAlmost no shock or
slipping in changing
from D
2 to D3.ON vehicle1. A/T fluid levelXX-XX, "*****"
2. Accelerat

Page 5383 of 5883

NISSAN TIIDA 2007 Service Repair Manual SYSTEM SYMPTOM
TM-437
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Slips/Will Not EngageRaces extremely fast
or slips in changing
from D
3 to D2 when
depressing acce

Page 5384 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-438
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
OthersTransaxle noise in“ P”
and “N” positions.ON vehicle1. A/T fluid levelXX-XX, "*****"
2. Line pressure testTM-178
3. Acc

TM-438
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
OthersTransaxle noise in“ P”
and “N” positions.ON vehicle1. A/T fluid levelXX-XX, "*****"
2. Line pressure testTM-178
3. Accelerator pedal position sensorEC-583
4. Vehicle speed sensor·A/T (Revolution sensor)
and vehicle speed sensor·MTRXX-XX, "*****"
and XX-XX,
"*****"
OFF vehicle5. Oil pumpXX-XX, "*****"6. Torque converterXX-XX, "*****"
Vehicle moves when
changing into “P” po-
sition or parking gear
does not disengage
when shifted out of “P”
position.ON vehicle 1. Control cable adjustmentXX-XX, "*****"
OFF vehicle 2. Parking componentsXX-XX, "*****"
Vehicle runs in “N” po-
sition.
XX-XX, "*****"
ON vehicle 1. Control cable adjustmentXX-XX, "*****"
OFF vehicle2. Forward clutchXX-XX, "*****"3. Reverse clutchXX-XX, "*****"
4. Overrun clutchXX-XX, "*****"
Vehicle braked when
shifting into “R” posi-
tion.ON vehicle1. A/T fluid levelXX-XX, "*****"
2. Control cable adjustmentXX-XX, "*****"
3. Line pressure testTM-178
4. Line pressure solenoid valveXX-XX, "*****"
5. Control valve assemblyXX-XX, "*****"
OFF vehicle6. High clutchXX-XX, "*****"7. Brake band XX-XX, "*****"
8. Forward clutchXX-XX, "*****"
9. Overrun clutchXX-XX, "*****"
Excessive creep. ON vehicle 1. Engine idling speedEC-389
Engine stops when
shifting lever into “R”,
“D”, “2” and “1” posi-
tions.ON vehicle1. Engine idling speedEC-3892. A/T fluid levelXX-XX, "*****"
3. Torque converter clutch solenoid valveXX-XX, "*****"
4. Control valve assemblyXX-XX, "*****"
OFF vehicle 5. Torque converterXX-XX, "*****"
Vehicle braked by
gear change from D
1
to D
2.ON vehicle 1. A/T fluid levelXX-XX, "*****"OFF vehicle2. Reverse clutchXX-XX, "*****"3. Low & reverse brakeXX-XX, "*****"
4. High clutchXX-XX, "*****"
5. Low one-way clutchXX-XX, "*****"
Vehicle braked by
gear change from D
2
to D
3.ON vehicle 1. A/T fluid levelXX-XX, "*****"OFF vehicle 2. Brake bandXX-XX, "*****"
Items Symptom Condition Diagnostic item Reference page
