NISSAN TIIDA 2007 Service Repair Manual FRONT WIPER ARM WW-71 < ON-VEHICLE REPAIR > C D E F G H I J K MA B WW N O P 4. Lift the blade up and then set it down onto glass surface to set the blade center to clearance “L1” and “L2” (LHD

Page 5874 of 5883

NISSAN TIIDA 2007 Service Repair Manual WW-72 < ON-VEHICLE REPAIR > FRONT WIPER DRIVE ASSEMBLY FRONT WIPER DRIVE ASSEMBLY Exploded ViewINFOID:0000000001450763 LHD Models LKIA0786E 1. Front RH wiper blade 2. Front RH wiper arm 3. Wiper arm

Page 5875 of 5883

NISSAN TIIDA 2007 Service Repair Manual FRONT WIPER DRIVE ASSEMBLY WW-73 < ON-VEHICLE REPAIR > C D E F G H I J K MA B WW N O P RHD Models Removal and InstallationINFOID:0000000001450837 REMOVAL 1. Operate the front wiper motor, and then tur

Page 5876 of 5883

NISSAN TIIDA 2007 Service Repair Manual WW-74 < ON-VEHICLE REPAIR > FRONT WIPER DRIVE ASSEMBLY To adjust the wiper arm stop location, the wiper arm must be removed and installed. Clearance between the top edge of the cowl top cover and the

Page 5877 of 5883

NISSAN TIIDA 2007 Service Repair Manual RAIN SENSOR WW-75 < ON-VEHICLE REPAIR > C D E F G H I J K MA B WW N O P RAIN SENSOR Exploded ViewINFOID:0000000001366670 Refer to XX-XX, "*****". Removal and InstallationINFOID:0000000001366671 Refer

Page 5878 of 5883

NISSAN TIIDA 2007 Service Repair Manual WW-76 < ON-VEHICLE REPAIR > WIPER AND WASHER SWITCH WIPER AND WASHER SWITCH Exploded ViewINFOID:0000000001366672 NOTE: The LHD model shown, RHD model similar. Removal and InstallationINFOID:0000000001

Page 5879 of 5883

NISSAN TIIDA 2007 Service Repair Manual REAR WIPER MOTOR WW-77 < ON-VEHICLE REPAIR > C D E F G H I J K MA B WW N O P REAR WIPER MOTOR Exploded ViewINFOID:0000000001366674 Rear Wiper Motor, Arm and Blade Removal and InstallationINFOID:000000

Page 5880 of 5883

NISSAN TIIDA 2007 Service Repair Manual WW-78 < ON-VEHICLE REPAIR > REAR WIPER MOTOR 2. Clean pivot area as shown. This will reduce the possibility of wiper arm looseness. 3. Install wiper blade. 4. Install wiper arm so that the arm rests i
