NISSAN TIIDA 2007 Service Repair Manual EC-1156
< COMPONENT DIAGNOSIS >[K9K]
P0381 GLOW CONTROL SYSTEM
P0381 GLOW CONTROL SYSTEM
DTC LogicINFOID:0000000001162620
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic procedure to

Page 2506 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0381 GLOW CONTROL SYSTEM
EC-1157
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
4.CHECK GLOW RELAY OUTPUT CIRCUIT FOR OPEN AND SHORT-II
1. Check the continuity between glow relay harnes

Page 2507 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1158
< COMPONENT DIAGNOSIS >[K9K]
P0409 EGR VOLUME CONTROL VALVE CONTROL POSITION SENSOR
P0409 EGR VOLUME CONTROL VALVE CONTROL POSITION SENSOR
DTC LogicINFOID:0000000001162623
DTC DETECTION LOGIC

EC-1158
< COMPONENT DIAGNOSIS >[K9K]
P0409 EGR VOLUME CONTROL VALVE CONTROL POSITION SENSOR
P0409 EGR VOLUME CONTROL VALVE CONTROL POSITION SENSOR
DTC LogicINFOID:0000000001162623
DTC DETECTION LOGIC
NOTE:
If DTC P0409 is displayed with DTC P0651, first perform trouble diagnosis for DTC P0651. Refer to
EC-1182, "
DTC Logic".
Conditions for applying the diagnostic procedure to the stored DTCs:
The DTC is declared present after the engine started.
If the DTC is present:
-Malfunction indicator (Yellow) lights up.
Diagnosis ProcedureINFOID:0000000001162624
1.CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK EGR VOLUME CONTROL VALVE CONTROL POSITION SENSOR POWER SUPPLY CIRCUIT
1. Disconnect EGR volume control valve harness connector.
2. Turn ignition switch ON.
3. Check the voltage between EGR volume control valve control position sensor connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
3.CHECK EGR VOLUME CONTROL VALVE CONTROL POSITION SENSOR GROUND CIRCUIT FOR
OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between EGR volume control valve control position sensor harness connector and
ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
DTC No. Trouble diagnosis name Possible Cause
P0409EGR VOLUME CONTROL VALVE CONTROL POSITION SEN-
SOR CIRCUIT
CO.0: Open circuit or short circuit to ground
CC.1: Short circuit to +12V Harness or connectors
(The EGR volume control valve control position
sensor circuit is open or shorted.)
EGR volume control valve control position sensor
EGR volume control valve control position sensor
Ground Voltage
Connector Terminal
F52 1 Ground Approx. 5V
EGR volume control valve control posi-
tion sensorECM
Continuity
Connector Terminal Connector Terminal
F52 3 E16 82 Existed

Page 2508 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0409 EGR VOLUME CONTROL VALVE CONTROL POSITION SENSOR
EC-1159
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
4.CHECK EGR VOLUME CONTROL VALVE CONTROL POSITION SENSOR INPUT CIRCUIT FOR O

Page 2509 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1160
< COMPONENT DIAGNOSIS >[K9K]
P0487 EGR VOLUME CONTROL VALVE
P0487 EGR VOLUME CONTROL VALVE
DTC LogicINFOID:0000000001162625
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic pr

Page 2510 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0487 EGR VOLUME CONTROL VALVE
EC-1161
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
5.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>>INSPECTION END
Component I

Page 2511 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1162
< COMPONENT DIAGNOSIS >[K9K]
P0488 EGR SYSTEM
P0488 EGR SYSTEM
DTC LogicINFOID:0000000001162628
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic procedure to the stored DTCs:

EC-1162
< COMPONENT DIAGNOSIS >[K9K]
P0488 EGR SYSTEM
P0488 EGR SYSTEM
DTC LogicINFOID:0000000001162628
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic procedure to the stored DTCs:
The DTC is declared present after the engine is started.
Special notes:
- Engine instability, possibly even stalling.
- Difficult to start engine or even impossible when cold.
- Loss of performance.
- Possible smoke emissions.
-Malfunction indicator (Red) lights up.
Diagnosis ProcedureINFOID:0000000001162629
1.CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK EGR VOLUME CONTROL VALVE INSTALLATION
Check that EGR volume control valve is installed properly.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Install EGR volume control valve properly.
3.CHECK EGR VOLUME CONTROL VALVE CONTROL POSITION SENSOR POWER SUPPLY CIRCUIT
1. Disconnect EGR volume control valve harness connector.
2. Turn ignition switch ON.
3. Check the voltage between EGR volume control valve control position sensor connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK EGR VOLUME CONTROL VALVE CONTROL POSITION SENSOR GROUND CIRCUIT FOR
DTC No. Trouble diagnosis name Possible cause
P0488EGR VOLUME CONTROL
1.DEF: Signal incoherence
2.DEF: Signal outside lower level
3.DEF: Signal outside upper level
4.DEF: Valve outside level
5.DEF: Defective sensor Harness or connectors
(The EGR volume control valve circuit is open
or shorted.)
(The EGR volume control valve control posi-
tion sensor circuit is open or shorted.)
EGR volume control valve
EGR volume control valve control position
sensor
Incorrect EGR volume control valve installa-
tion
EGR volume control valve stuck closed
EGR passage clogged
GR volume control valve control position sensor
Ground Voltage
Connector Terminal
F52 1 Ground Approx. 5V

Page 2512 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0488 EGR SYSTEM
EC-1163
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between E
