2007 NISSAN TIIDA Service Repair Manual

refuelling brakes oil dipstick wheel key fob fuel cap

Page 2641 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1292
< SYMPTOM DIAGNOSIS >[K9K]
EMISSION CONTROL NOT SATISFACTORY
9.CHECK HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE)
Perform the TEST 4: HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALV

Page 2642 of 5883

NISSAN TIIDA 2007 Service Repair Manual PRECAUTIONS
EC-1293
< PRECAUTION >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:000000

PRECAUTIONS
EC-1293
< PRECAUTION >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000001706108
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-
ness connectors.
Precaution for Procedure without Cowl Top CoverINFOID:0000000001162744
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
On Board Diagnostic (OBD) System of EngineINFOID:0000000001162745
The ECM has an on board diagnostic system. It will light up the malfunction indicator (MI) to warn the driver of
a malfunction causing emission deterioration.
CAUTION:
Be sure to turn the ignition switch OFF and disconnect the battery negative cable before any repair
or inspection work. The open/short circuit of related switches, sensors, solenoid valves, etc. will
cause the MI to light up.
Be sure to connect and lock the connectors securely after work. A loose (unlocked) connector will
cause the MI to light up due to the open circuit. (Be sure the connector is free from water, grease,
dirt, bent terminals, etc.)
Certain systems and components, especially those related to OBD, may use a new style slide-lock-
ing type harness connector. For description and how to disconnect, refer to XX-XX, "*****"
.
Be sure to route and secure the harnesses properly after work. The interference of the harness with
a bracket, etc. may cause the MI to light up due to the short circuit.
Be sure to connect rubber tubes properly after work. A misconnected or disconnected rubber tube
may cause the MI to light up due to the malfunction of the fuel system, etc.
Be sure to erase the unnecessary malfunction information (repairs completed) from the ECM before
returning the vehicle to the customer.
PIIB3706J

Page 2643 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1294
< PRECAUTION >[K9K]
PRECAUTIONS
General Precautions
INFOID:0000000001162746
Always use a 12 volt battery as power source.
Do not attempt to disconnect battery cables while engine is
running.

Page 2644 of 5883

NISSAN TIIDA 2007 Service Repair Manual PRECAUTIONS
EC-1295
< PRECAUTION >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
When measuring ECM signals with a circuit tester, never allow
the two tester probes to contact.
Accidental contact of probes wi

Page 2645 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1296
< PRECAUTION >[K9K]
PRECAUTIONS
Cylinder NO.1 is at the flywheel end.
-1: Crankshaft pulley
ENGINE RUNNING
No work should be carried out on the hydraulic system while engine is running.
Rem

EC-1296
< PRECAUTION >[K9K]
PRECAUTIONS
Cylinder NO.1 is at the flywheel end.
-1: Crankshaft pulley
ENGINE RUNNING
No work should be carried out on the hydraulic system while engine is running.
Remember that fuel pressure values in hydraulic circuit can reach up to 1,600 bar.
Keep hands or face (particularly eyes) out of any high pressure leak.
Recall that fuel is dangerous for health.
FUEL RAIL PRESSURE SENSOR
Under warranty, do not remove the fuel rail pressure sensor from the rail.
Do not try to measure the resistance of the fuel rail pressure sensor. This test is destructive for the
internal components.
FUEL INJECTOR
Fuel injectors are driven by over 100V.
FUEL injector electronics are polarised. In case of intervention on wiring harness, do not
invertwires. It is destructive for the piezo components.
Do not drive the fuel injectors if their body is not connected to the battery ground (risk ofelectro-
static discharge). For instance, fuel injector body have to be in contact with cylinder.
Piezo fuel injector connector must not be unplugged while engine is running. Risk of majordamage
to the engine (fuel injector could stay opened).
CleanlinessINFOID:0000000001162747
Cleanliness
RISKS ASSOCIATED WITH CONTAMINATION
The high pressure direct injection system is highly sensitive to contamination. The risks associated withcon-
tamination are:
damage to or destruction of the high pressure injection system,
components jamming,
components losing seal integrity.
All After-Sales operations must be performed under very clean conditions. This means that no impurities (par-
ticles a few microns in size) should have entered the system during dismantling.
The cleanliness principle must be applied from the filter to the fuel injectors.
What are the sources of contamination?
metal or plastic chips,
paint,
fibres:
- from cardboard,
- from brushes,
- from paper,
- from clothing,
- from cloths,
foreign bodies such as hair,
ambient air
etc.
NOTE:
Cleaning the engine using a high pressure washer is prohibited because of the risk of damaging connections.
In addition, moisture may collect in the connectors and create electrical connection malfunction.
INSTRUCTIONS TO BE FOLLOWED BEFORE CARRYING OUT ANY WORK
JMBIA0432ZZ

Page 2646 of 5883

NISSAN TIIDA 2007 Service Repair Manual PRECAUTIONS
EC-1297
< PRECAUTION >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NOTE:
Before any work is carried out on the high pressure injection system, protect:
the accessories and timing belts,
the e

PRECAUTIONS
EC-1297
< PRECAUTION >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NOTE:
Before any work is carried out on the high pressure injection system, protect:
the accessories and timing belts,
the electrical accessories, (starter, alternator, electric power assisted steering pump),
the flywheel surface, to prevent any diesel from running onto the clutch friction plate.
Check that you have plugs for the unions to be opened (set of plugs available from the Parts Department).
The plugs are single-use only. After use, they must be discarded (once used they are soiled and cleaning is
not sufficient to make them reusable). Unused plugs must be discarded.
Check that you have hermetically resealable plastic bags for storing removed parts. Stored parts will there-
fore be less subject to the risk of impurities. The bags are to be used once only, and discarded after use.
Use lint-free cleaning cloths. Using normal cloth or paper is prohibited. They are not lint-free and could con-
taminate the fuel circuit. Each cloth should only be used once.
Use fresh cleaning agent for each operation (used cleaning agent is contaminated). Pour it into an uncon-
taminated container.
For each operation, use a clean brush in good condition (the brush must not shed its bristles).
Use a brush and cleaning agent to clean the unions to be opened.
Blast compressed air over the cleaned parts (tools, workbench, the parts, unions and injection system
zones). Check that no bristles remain.
Wash your hands before and during the operation if necessary.
When wearing leather protective gloves cover them with latex gloves to prevent contamination.
INSTRUCTIONS TO BE FOLLOWED WHEN CARRYING OUT ANY WORK
As soon as the circuit is open, all openings must be plugged to prevent impurities from entering the system.
The plugs to be used are available from the Parts Department. The plugs must not be reused under any cir-
cumstances.
Seal the pouch shut, even if it has to be opened shortly afterwards. Ambient air carries contamination.
All components removed from the injection system must be stored in a hermetically sealed plastic bag once
they have been plugged.
Using a brush, cleaning agent, air gun, sponge or normal cloth is strictly prohibited once the circuit has been
opened. These items could allow contamination to enter the system.
A new component replacing an old one must not be removed from its packaging until it is to be fitted to the
vehicle.

Page 2647 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1298
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Idle SpeedINFOID:000000000116274

Page 2648 of 5883

NISSAN TIIDA 2007 Service Repair Manual EM-1
ENGINE
C
D
E
F
G
H
I
J
K
L
M
SECTION EM
A
EM
N
O
P
CONTENTS
ENGINE MECHANICAL
HR16DE
SYMPTOM DIAGNOSIS ...............................
5
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING ..

EM-1
ENGINE
C
D
E
F
G
H
I
J
K
L
M
SECTION EM
A
EM
N
O
P
CONTENTS
ENGINE MECHANICAL
HR16DE
SYMPTOM DIAGNOSIS ...............................
5
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING .............................
5
NVH Troubleshooting - Engine Noise .......................5
Use the Chart Below to Help You Find the Cause
of the Symptom .........................................................
6
PRECAUTION ...............................................7
PRECAUTIONS ...................................................7
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...................................................................
7
Precaution for Procedure without Cowl Top Cover ......7
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect .....................................
7
Precaution for Drain Coolant .....................................8
Precaution for Disconnecting Fuel Piping .................8
Precaution for Removal and Disassembly ................8
Precaution for Inspection, Repair and Replace-
ment ..........................................................................
8
Precaution for Assembly and Installation ..................8
Parts Requiring Angular Tightening ..........................8
Precaution for Liquid Gasket .....................................9
PREPARATION ...........................................11
PREPARATION ..................................................11
Special Service Tools ..............................................11
Commercial Service Tools ......................................12
ON-VEHICLE MAINTENANCE ....................15
DRIVE BELTS ....................................................15
Checking .................................................................15
Tension Adjustment ................................................15
Removal and Installation .........................................16
AIR CLEANER FILTER ......................................18
Removal and Installation .........................................18
SPARK PLUG ...................................................19
Exploded View .........................................................19
Removal and Installation .........................................19
CAMSHAFT VALVE CLEARANCE ..................21
Inspection and Adjustment ......................................21
COMPRESSION PRESSURE ...........................24
Inspection ................................................................24
ON-VEHICLE REPAIR .................................25
DRIVE BELT IDLER PULLEY ..........................25
Exploded View .........................................................25
Removal and Installation .........................................25
AIR CLEANER AND AIR DUCT .......................27
Exploded View .........................................................27
Removal and Installation .........................................27
Inspection ................................................................28
INTAKE MANIFOLD .........................................29
Exploded View .........................................................29
Removal and Installation .........................................29
EXHAUST MANIFOLD ......................................32
Exploded View .........................................................32
Removal and Installation .........................................32
FUEL INJECTOR AND FUEL TUBE ................35
Exploded View .........................................................35
Removal and Installation .........................................35
Inspection ................................................................39
OIL PAN (LOWER) ...........................................40
Exploded View .........................................................40
Removal and Installation .........................................40
Inspection ................................................................41
OIL PAN (UPPER) AND OIL STRAINER .........42
Component ..............................................................42

Load next 8 pages

Page: < prev 1-10 ... 2609-2616 2617-2624 2625-2632 2633-2640 2641-2648 2649-2656 2657-2664 2665-2672 2673-2680 ... 5888 next >

spare wheel radiator cap change wheel horn tyre pressure auxiliary battery
